9600+ Series
Digital Delay Pulse Generators
The 9600+ series is our most affordable Digital
Delay Pulse Generator in our family of products.
Despite its low cost, this robust model offers a
full range of features, making it ideally suited
for the budget sensitive user.
- 10 ns Timing Resolution
- < 5 ns Channel to Channel Jitter
- Benchtop Design
- Easy Programming Interface
- 2, 4 or 8 Independent Channel Outputs
- Free LabVIEW Drivers
- RS232 Standard
- Full Customer Support
- 2 Year Warranty
Quantum Composers, Inc.
P.O. Box 4248
Bozeman, MT 59772
Phone (406) 582-0227
Fax (406) 582-0237
Toll Free (800) 510-6530
www.QuantumComposers.com
9600+ Series
Pulse Generator
The Model 9600+ Series Digital Delay Pulse Generator
with 2, 4 or 8 independent outputs is our most
affordable digital delay/pulse generator, it’s ideal for
applications that require moderate precision and
multi-channel capability. The delay and pulse width for
each channel are independent with 2-20 volt output
range, allowing the user to drive a wide range of load
circuitry. The instrument offers several operating
modes including continuous, burst, single shot and
external trigger/gate, allowing complete control of the
pulse outputs. With precise control of the delay
periods and quick recall of up to 6 system
configurations, the instrument is instantly ready for
use. For automated test equipment, complete control
of the instrument is provided through the standard
RS232 interface. GPIB interface is optional.
Digital Delay Output Modes
Fax Phone Line (406) 582-0237 Web www.QuantumComposers.com
with 2, 4 or 8 independent outputs is our most
pulse outputs. With precise control of the delay
SPECIFICATIONS 9600+ Series
MODELS 9612+ 2 independent channel outputs Standard Communications: RS232
9614 + 4 independent channel outputs Congurations: 6 Memory Slots
9618+ 8 independent channel outputs
PULSE GENERATION
channel modes single shot, burst, normal, duty cycle.
multiplexer combine the timing of any channel
delay 0 to 1000 s
negative delay 0 to -1000 s
pulsewidth 10 ns to 1000 s
resolution 10 ns
accuracy 10 ns + 0.0001 delay
time base 50 MHz, 50 PPM crystal oscillator
RMS jitter < 5 ns channel to channel
burst mode 1 to 1,000,000
EXTERNAL TRIGGER/GATE
rate DC to 2 MHz
threshold 500 mV to 15 V
input range 0 - 30 V
trigger slope rising or falling edge
RMS jitter < 25 ns
insertion delay < 250 ns
INTERNAL RATE GENERATOR
system modes single shot, burst, continuous, duty cycle
rate (T0 period) 200 ns to 999.99999 s (0.001 Hz to 5 MHz)
resolution 10 ns
accuracy 5 ns + 0.0001 x period
RMS jitter < 500 ps
burst mode 1 to 1,000,000 pulses
OUTPUTS
outputs adjustable 2 - 20 V
slew rate > 0.2 V/ns
overshoot < 100 mV + 10 % of pulse amplitude up to 4 independently adjustable
outputs; 8 channel units 1 & 6, 2 & 7, etc. share the same output voltage
amplitude (adjustable mode) 1 - 10 V into 50 ohm load
2 - 20 V into high impedance load
GENERAL
dimensions 7.5” x 9” x 4”
weight 6 lbs.
power 20 W, 100 - 240 VAC, 50 - 60 Hz
OPTIONS
G - GPIB Computer Interface
9600_SRM - 19” Single Rack Mount
9600_DRM - 19” Double Rack Mount
dimensions
7.5” x 9” x 4”
power
20 W, 100 - 240 VAC, 50 - 60 Hz
Fax Phone Line (406) 582-0237 Web www.QuantumComposers.com V1.0 11/4/11
