QTX Light LUX-LD30W Manual de usuario

USER MANUAL

LUX-LD30W LED MOVING HEAD

150.447UK

User Manual

– LUX LD30W 150.447UK

LUX-LD30W LED MOVING HEAD – For indoor use only

1. General Introduction :

With a powerful 30W white LED this moving head has the equivalent light output of a 150W halogen

bulb, yet uses approx. 20% of the power. It is has 5 modes of operation including 2 auto, 2

sound-to-light and DMX512. The light also features an 8 colour wheel and a choice of 7 different

gobos that can be auto rotated to create a variety of effects. Each shape or pattern can also be

strobed via DMX or as part of the internal programs. Perfect for installations in bars, nightclubs,

stage shows and concerts.

Features :

Very high power 30W white LED (50,000 hrs)

8 selectable colours

7 selectable gobos

More vivid colours than equivalent halogen fixtures

Manual focus adjustment to sharpen the image and spot over a large distance

DMX in/out connections via 3-pin XLR

10 channel DMX, colour select, gobo, select, rotation, strobe, pan, tilt, pan and tilt speed,

pan fine, tilt fine, and reset

Master and slave modes

Strobe speed adjustable

Auto/sound activated

Fan cooled

Lightweight high quality casing with special coating for extra protection

2. Package Contents :

Please check the contents to ensure that the product has been received in good condition.

Light x 1unit

User’s Guide x 1pcs

Power Cord x 1pcs

If you find any accessory is missing or the lighting has arrived with any problems, please contact

your local dealer at once. Do not try to fix this item yourself or you will lose the warranty. Please

keep the original package and invoice for any possible replacement or returned demand.

Caution! Please read this manual carefully before operating!

Damage caused by misuse is not covered by the warranty!

ranty

User Manual

– LUX LD30W 150.447UK

3. Installation :

Every person involved with the installation, operation and maintenance of this device should be

qualified and follow the instructions of this User Guide. We recommend that this product is not

used for audience scanning. When you connect to the main power supply the device will illuminate

and the light effect will change with music when in sound activated mode.

4. Caution! To prevent Mortal Electrical Risk and Long Life Operation :

For your safety, please kindly pay attention to all of the warnings listed below:

Always plug in the power plug last and disconnect from the mains, when the device is not in use

or before cleaning.

Do not install and operate the device in rain or extreme heat, moisture or dusty environments.

This device is for indoor use only and in a dry environment.

Do not switch on immediately but wait until it reaches to room temperature, if the device has

been exposed to drastic temperature fluctuations.

Do not shake the device and avoid brute force when installing or operating

Do not spread the smoke or bubble of effect machine directly to the device.

Do not use the device during thunderstorms and please disconnect the power.

Do not use solvents or aggressive detergent to clean the device. Use a soft and clean cloth.

Do not modify the device or the connected power cord without authorization.

Use appropriate safety-rope for safety.

Do not stare to the light.

The symbol determines the minimum distance from lighted objects. The minimum

distance between light-output and the illuminated surface must be more than 0.1m.

6. Connect with power supply - The ground wire must be connected :

Use the plug to connect to the main power supply as following.

Line

Connection

International signal

Brown

cathode

Blue

anode

Yellow /Cyan

Ground wire

7. Quick Trouble Shooting :

7.1 if the unit is not functional – Check if main power is on and fuse.

7.2 if the unit is not reacting to music – check the unit is in “Snon” mode on the display.

8. Replacing Fuse :

Disconnect from the main power supply first, then remove the fuse holder above the IEC Socket to

reveal the fuse. Replace the correct fuse rating as stated on lighting or user guide. Then, lock the fuse

holder cover back into place.

User Manual

– LUX LD30W 150.447UK

9. General Maintenance :

To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. Usage

and environment are contributing factors in determining frequency. As a general rule, fixtures should be

cleaned at least twice a month. Dust build-up reduces light output performance and can cause

overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure to power off

fixture before conducting maintenance.

Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust collected

on external vents and internal components. Clean all glass when fixture is cold with a mild solution to

the cloth or tissue, and drag dirt and grime to the outside of the lens. Gently polish optical surface until

they free of haze and lint.

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequently depends on the environment in which the fixtures operates:

damp, smoky or particularly dirty surroundings can require cleaning fluid. Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

10. Mounting instruction :

The fixture may be mounted in any position provided there is adequate room for ventilation.

It is important never to obstruct the fan or vents pathway. Mount the fixture using a clamp.

Adjust angle of the fixture loosening both knobs and tilting the fixture. After finding desired

position, retighten both knobs.

When selecting installation location, take into consideration lamp replacement access and

routine maintenance. Safety cables must always be used.

Never mount in places where the fixture will be exposed to rain, high humidity, extreme

temperatures changes or restricted ventilation.

User Manual

– LUX LD30W 150.447UK

11. Layout for the LUX LD-30W :

User Manual

– LUX LD30W 150.447UK

12. Digital Display Setting & Function :

User Manual

– LUX LD30W 150.447UK

13. DMX Controlling :

Function & Value

Channel 1

Colour Gobo Wheel 7 Colour

000-017 White

018-033 Red

034-050 Yellow

051-067 Cyan

068-084 Green

085-101 Orange

102-107 Purple

108-127 Blue

128-192 Colour scroll clockwise fast to slow

193-255 Colour scroll anti clockwise slow to fast

Channel 2

6 Gobo wheel + Spot

000-020 Spot

021-041 Gobo 1

042-062 Gobo 2

063-083 Gobo 3

084-104 Gobo 4

105-119 Gobo 5

120-127 Gobo 6

128-192 Gobo scroll clockwise fast – slow

193-255 Gobo scroll anti clockwise slow - fast

Channel 3

Gobo rotation

000 No rotation

001-127 Clockwise fast to slow

128-255 Anti clockwise slow to fast

Channel 4

Dimmer + Strobe

000 Closed

001-115 0-100% Dimmer

116-243 Strobe slow to fast

244-255 Open

Channel 5

Pan rotating

Channel 6

Tilt rotating

Channel 7

Pan & Tilt speed

000-255 Fast to slow

Channel 8

Pan fine 16bit

Channel 9

Tilt fine 16bit

Channel 10

Reset

000 – 149 No action

150-200 Electronic reset

14. Disposal :

User Manual

– LUX LD30W 150.447UK

Please disposal of the unserviceable device according to the current statutory requirements.

15. Technical specification :

Voltage : AC 230V 50~60Hz

LED Type : Φ10, Angle : 30°

LED : 1 x 30W White LED

LED Life: Upto 50,000 hours

Fuse : 2A

Lux: 850 @3m

Power Consumption: 54W

Beam Angle: 12 degrees

Dimensions : 345 X 340 X 435mm

Weight: 6.8kg

Note: This product conforms to Laser and LED Safety standard BSEN60825-1 2007
