IMPORTANT SAFETY INFORMATION
DRIVER AND PASSENGER
LG250 is designed only for one driver and one passenger. The total load must be within the limit specified
on the specification label.
ROAD CONDITION
The motorcycle is designed only for driving on paved roads.
READ THIS MANUAL CAREFULLY
Pay special attention to all the sentences or paragraphs marked with WARNING in this manual.
WARNING:
Means failure to follow the instructions will cause serious injury or death.
NOTICE:
Means that if the instructions in this manual are not observed, product damage or body injury may occur.
NOTE:
Provides you with the effective method of operation.
As the manual is considered as indispensable, it should be always kept with the driver for consultation.
USER'S MANUAL
TO OUR CUSTOMER
Thanks for choosing our motorcycle, LG250. For safe and pleasant driving, a complete understanding for all the
instructions in this manual is necessary. Your safety is not only ensured by your own alertness and your understanding
of all operations but also related to your understanding of the mechanic performance of the motorcycle. Making
inspections before driving and performing periodical maintenance are basic conditions for your safety.
When periodic maintenance or repair is necessary, please consult with our local dealer.
Wish you a pleasant drive.
The manufacturer reserves the rights to make improvement of the product at any time without prior
notice and without any obligation whatever.
USER'S MANUAL
CONTENTS
Traffic safety..............................................................1
Important information for safe driving...............2
Load .............................................................................3
Parts and controls .....................................................4
Operation guide.........................................................7
Main switch ..............................................................7
Steering lock switch.................................................7
Temperature indicator..............................................8
Fuel gauge.................................................................8
Side stand indicator..................................................8
Trip reset button .......................................................8
Headlight illumination switch.................................9
Turning light switch .................................................9
Horn switch button ...................................................9
Ignition button..........................................................9
Headlight switch ......................................................9
Kill switch ................................................................9
Passing light switch.................................................9
Steering lock ..........................................................10
Rear foot pedal .......................................................10
Seat .........................................................................11
Audio control system .............................................12
USB plug................................................................12
Panel and buttons..................................................12
Main performance parameter..............................13
Output line functioning drawing ........................13
Inspection before driving .....................................14
Fuel capacity .........................................................14
Fuel tank capacity.................................................14
Checking engine oil level ....................................15
Brake ......................................................................16
Tire .........................................................................18
Starting the engine .................................................20
Driving the motorcycle..........................................21
Driving ...................................................................21
Braking ..................................................................22
Parking ...................................................................23
Anti-theft ...............................................................23
Maintenance interval.............................................24
Maintenance interval table..................................25
USER'S MANUAL
Maintenance ............................................................26
Air cleaner .............................................................26
Cooling system maintenance ..............................28
Radiator .............................................................28
Coolant type ......................................................28
Checking coolant capacity ..............................28
Engine oil...............................................................29
Recommend engine oil ....................................29
Viscosity ............................................................29
Replacing engine oil and cleaning oil screen ...30
Engine oil capacity..........................................30
Replace engine oil ...........................................30
Replace gearbox oil.........................................31
Spark plug..............................................................32
Battery....................................................................32
Replace the fuse....................................................33
Tools .......................................................................34
VIN number...........................................................35
Guideline for storage .............................................36
Technical parameter ..............................................38
Electrical diagram..................................................40
USER'S MANUAL
CONTENTS
TRAFFIC SAFETY
SAFETY CAN BE ENSURED ONLY BY DRIVER HIMSELF.
NOTICES:
A driver should always spend time on learning driving methods and technique before driving on the highway in less traffic
area.
1.Many motorcycle accidents occur due to that automobile driver cannot see the motorcycle driver. Therefore, the
motorcycle driver should make all his effort to be seen clearly by automobile driver.
For example:
Wear noticeable clothing.
Avoid driving carelessly.
2.Many accidents occur at the intersection, entrance or exit of parking lot and driveway. Therefore pay attention to the
above places.
3.Speeding is one of the main causes for many motorcycle accidents. Please obey the traffic rules and drive within the speed
limit.
4.Many motorcycle accidents occur due to insufficient experience. A new driver should comprehend each performance of
motorcycle before riding on the highway. Never lend motorcycle to inexperienced drivers.
5.Most injuries of motorcycle accidents are on head. Therefore please wear helmet and other protections, e.g. dust-tight
glasses, boots and thick coat.
6.Do not ride on the expressways. If inevitable, please be careful and drive safely.
7.Avoid driving on bumpy roads, which will result in losing control or damaging machine.
1
USER'S MANUAL
IMPORTANT INFORMATION FOR SAFE DRIVING
1.Before starting the engine, carefully inspect the motorcycle. (Refer to Page 14).
2.For safety, wear helmet as well as boots, gloves, dust-tight glasses and noticeable clothing;
3.The rear box or cargo box mounted by customer himself is for lightweight things only. If mounting cargo boxes on
two sides of motorcycles, please load equally on both and hold tightly in order not to move around when driving. For
detail, refer to page 3.
4.When driving, hold the steering handlebars and step on the footrest.
5.Practice on road in less traffic area and get familiar with motorcycle performance before driving on the roadway.
6.Turn on turn signals when turning or changing lane.
7.Do not drive on the road shoulder.
WARNING: This is a motorcycle of CVT transmission. Increase throttle ONLY after you are
ready to drive.
2
USER'S MANUAL
LOAD
WARNING:
Trunk or storage equipment etc., are for lightweight loads only.
Max. Load capacity: 331lbs.
Overload will affect the stability and controllability.
All the loads should be secured firmly.
Children or pets should not be carried on the bracket or trunk, e.g. dog or cat.
All the loads should not be oversized.
3
USER'S MANUAL
PARTS AND CONTROLS
THE ASSEMBLING POSITIONS OF CONTROLS
Panel and indicator
Audio box control system
Throttle grip
Air cleaner
Oil hole/Oil dip rod
Main stand
Floor rest
Main switch
Steering lock
VIN
The position marked with ……represents the invisible parts.
4
USER'S MANUAL
Rear Brake locking device
Left grip
Fuel tank lock
Fuel tank
Seat lock
Tool box
Coolant overflow
Radiator
VIN plate
Floor pedal
The position marked with ……represents the invisible parts.
5
USER'S MANUAL
PANEL AND INDICATOR
The controls of each indicator light and alarming light are integrated in the panel.
All the functions are instructed in the following pages.
Temperature indicator
Speedometer
Odometer
Fuel indicator
High beam indicator
Turning signal indicator (RH&LH)
Side stand parking indicator
Trip
Reset
6
