QDI P4I865G Manual de usuario
Notice
The information in this document is subject to
change in order to improve reliability, design, or
function without prior notice and does not repre-
sent a commitment on the part of this company.
In no event will we be liable for direct, indirect,
special, incidental, or consequential damages
arising out of the use or the possibility of such
damages.
All trademarks are the property of their respec-
tive owners.
If you need any further information, please visit
our web-site: “www.qdigrp.com”.
This item checklist is only available for retail
market. Completely check your package, If you
discover damaged or missing items, contact
your retailer.
Item Checklist
P4I865A series mainboard
QDI Utility CD
User’s manual
IDE ribbon cable
Floppy ribbon cable
I/O shield
SATA signal cable(option)
SATA power cable(option)
Cable with bracket for USB Connectors
(option)
Cable with bracket for SPIDF Connectors
(option)
Declaration of conformity
QUANTUM DESIGNS(HK) LTD.
20th Floor, Devon House, Taikoo Place, 979 King’s Road,
Quarry Bay, Hong Kong
declares that the product
Mainboard
P4I865G /P/PEA series
is in conformity with
(reference to the specification under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
EN 55022 Limits and methods of measurements of radio disturbance
characteristics of information technology equipment
EN 50081-1 Generic emission standard Part 1:
Residential, commercial and light industry
EN 50082-1 Generic immunity standard Part 1:
Residential, commercial and light industry
European Representative:
QDI COMPUTER ( UK ) LTD QDI COMPUTER ( SCANDINAVIA ) A/S
QDI SYSTEM HANDEL GMBH QDI EUROPE B.V.
QDI COMPUTER (FRANCE) SARL QDI COMPUTER HANDELS GMBH
LEGEND QDI SPAIN S.L. QDI COMPUTER (SWEDEN) AB
Signature : Place / Date : HONG KONG/2003
Printed Name : Xu Wenge Position/ Title : Assistant President
Declaration of conformity
Trade Name: QDI Computer ( U. S . A. ) Inc.
Model Name: P4I865G/P/PEA
Responsible Party: QDI Computer ( U. S. A.) Inc.
Address: 41456 Christy Street
Fremont, CA 94538
Telephone: (510) 668-4933
Facsimile: (510) 668-4966
Equipment Classification: FCC Class B Subassembly
Type of Product: Mainboard
Manufacturer:Quantum Designs (HK) Inc.
Address: 20th Floor, Devon House, Taikoo Place
979 King’s Road, Quarry Bay, HONG
KONG
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions : (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Tested to comply with FCC standards.
Signature : Date : 2003
Chapter 1 Introduction
Introduction ...........................................................................1
Key Features ........................................................................2
Chapter 2 Installation Instructions
ExternalConnectors .............................................................7
PS/2Keyboard/MouseConnectors .......................................7
USB1, USB2 and 1394Connectors .......................................7
USB3, USB4 and LAN Connectors ........................................8
Line-in jack, Microphone-in jack, Speaker-out jack ................8
5.1-channelAudio...................................................................9
ParallelPort, Serial Port Connectors....................................10
ATX12V Power Supply Connector & Power
Switch(POWERSW) .......................................................... 11
FrontPanelConnector ........................................................12
HardDiskLEDConnector(HD_LED)....................................12
ACPILEDConnector ...........................................................12
SpeakerConnector(SPEAKER) ..........................................12
PowerLEDConnector(PWR_LED) .....................................12
Reset Switch ......................................................................12
GREENLEDConnector........................................................12
Hardware Green Connector ...............................................12
Key Lock Connector ...........................................................12
USB5,6;USB7,8 ...................................................................14
FanConnectors(CPUFAN,CHSFAN,SYSTEMFAN) .............14
Infrared Header (IrDA) ........................................................15
Wake-Up On LAN (WOL)(-L)(-K) ........................................15
AudioConnectors(CD_IN,AUX_IN) .....................................16
1394 Connector(Optional)(-F) .............................................16
Audio Interface ...................................................................17
SPDIF/6CH BRACKETConnector.......................................18
SCR(Smart Card Reader) ..................................................18
1394(Optional)andLAN(Optional) MAC Label ....................19
Serial ATA Connector..........................................................19
Diagnosis LED ....................................................................20
HYPER_Threading...............................................................20
JumperSettings ..................................................................21
ClearCMOS(JP1) ...............................................................22
BIOS-ProtectionJumper(JP2) .............................................23
Chapter 3 BIOS Description
UtilitySupport......................................................................24
AWDFLASH.EXE .................................................................24
AWARD(Phoenix)BIOSDescription ....................................25
EnteringSetup ....................................................................25
LoadOptimizedDefaults .....................................................25
StandardCMOSFeaturesSetup .........................................25
BIOSFeaturesSetup .......................................................... 29
Advanced BIOS Features Setup .........................................30
Advanced Chipset Features Setup .....................................32
IntegratedPeripherals .........................................................34
PowerManagementSetup ..................................................39
PNP/PCIConfigurationSetup ...............................................43
PCHealthStatus .................................................................44
Frequency/VoltageControl..................................................46
Password Setting ...............................................................47
Boot with BIOS defaults......................................................47
Appendix
QDIUtilityCD .......................................................................48
Norton AntiVirus .................................................................48
SpeedEasy .........................................................................49
Pro-LogoEasy .....................................................................50
Pro-StepEasy......................................................................52
Pro-UpdateEasy ..................................................................55
BootEasy ............................................................................56
BIOS-ProtectEasy ...............................................................57
QDIBootEasy(German) .......................................................58
P4I865G/P/PEA(Spanish) ....................................................59
P4I865G/P/PEA(French) ......................................................62
P4I865G/P/PEA(Italian) ........................................................66
Using4/6-ChannelAudio ....................................................69
This manual is suitable for mainboards of P4I865MA
series. Each mainboard is carefully designed for the
PC user who wants diverse features.
-6A: with onboard 6 Channel Audio
- F: with onboard 1394
- K: with onboard 1G LAN
- L: with onboard 10/100M LAN
- R: with Raid
Note:
Caution
Be sure to add some Silicone Grease between the CPU and the heatsink
to keep them fully contacted to meet the heat sink requirement.
Caution
Be sure to unplug the AC power supply before adding or removing
expansion cards or other system peripherals, especially the memory
devices, otherwise your mainboard or the system memory might be
seriously damaged.
Caution
We cannot guarantee your system running properly under overclocking.
It depends on the overclocking ability of your peripherals.
T-- This page is intentionally left blank --his
Chapter 1Chapter 1
Chapter 1Chapter 1
Chapter 1
1
P4I865G/P/PEA User’S Manual
IntroductionIntroduction
IntroductionIntroduction
Introduction
Chapter 1
Introduction
P4I865G/P/PEA series of mainboards utilize ( Intel®865G/P/PE
+ICH5/5R)chipset, providing a fully compatible, high performance
and cost-effective ATX platform. The new integrated technologies,
together with AC’97 audio, onboard VGA connector(supported on
P4I865GA only), integrated LAN(optional), 4 USB 2.0 ports
(Expanded capabilities for eight USB 2.0 ports), ATA100/66/33
and SATA, give customers an advanced, multimedia solution at
reasonable price. It provides 400/533/800MHz(supported on
P4I865G/PEA only) host bus speed to support Intel®Pentium®4
socket 478 processors and the largest DDR memory capacity is
up to 4GB. It also provides advanced features such as Wake up
by USB devices, Wake-on-LAN, ACPI function. Suspend to RAM,
the optimal implementation of the Advanced Configuration and
Power Interface (ACPI) specification, makes the PC’s power con-
sumption drop to the lowest possible level and enable quick wake
up.
2
Chapter 1Chapter 1
Chapter 1Chapter 1
Chapter 1
P4I865G/P/PEA User’S Manual
IntroductionIntroduction
IntroductionIntroduction
Introduction
Key Features
Form factor
ATX form factor of 304 mm x 243mm
Microprocessor
Supports for Intel® Pentium®4 (Northwood) socket 478 processors at
1.6/1.8/2.0/2.2/2.4GHz at 400MHz FSB and above.
Supports Intel® Celeron®Socket 478 processors at 2.0/2.1GHz at 400MHz
FSB and above.
Supports Intel® Pentium®4(Northwood) Socket 478 processors at 2.26/2.4/2.
53/2.66/2.8/3.06GHz at 533MHz FSB and above.
Supports Intel® Pentium®4((Northwood) Socket 478 processors at 2.4C/2.6
C/2.8C GHz at 800MHz FSB and above.
Supports Intel® Prescott Socket 478 processors at 3.0G/3.2GHz and above at
800MHz FSB (Supported on P4I865G/PEA Only)(Optional)
Supports Hyper-threading technology.
Chipset
P4I865G/P/PEA Family
Intel® Springdale Chipset: Intel®865G/P/PE(NorthBridge)+ICH5/5R
(SouthBridge)
System memory
Provides four 184-pin DDR DIMM Sockets
Supports for DDR266/DDR333/DDR400(Supported on P4I865G/PEA Only)
Supports for 128/256/512Mb technology up to 4GB
Supports Dual channel DDR(rise the same type DDR to DIMM1,3 or DIMM2,
4, Dual channel model transfer rate get to highest, as DDR400 the transfer
rate is 6.4MBps)
NOTES: Configured FSB800 CPU and DDR333, memory frequency is 320MHz
Onboard IDE
Supports for Independent timing of up to 4 drives
Supports for Ultra ATA 100/66/33, PIO mode
Two fast IDE interfaces supporting four IDE devices including IDE hard disks
and CD-ROM/DVD-ROM drives
Onboard Graphics (Supported on P4I865GA only)
Integrated Intel Extreme Graphics 2D/3D graphics accelerator
Integrated 350MHz RAMDAC
Provides VGA output connector
Provides 32bit true color support for high resolution texture
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Otros manuales de Placa madre de QDI
QDI
QDI J6A Manual de usuario
QDI
QDI XV915 Series Manual de usuario
QDI
QDI PlatiniX 7B Manual de usuario
QDI
QDI P6I440BX/B1S Manual de usuario
QDI
QDI Superb 4L Manual de usuario
QDI
QDI Pentium P5I430TX/IIB TITANIUM IIB Manual de usuario
QDI
QDI Superb 4 Series Manual de usuario
QDI
QDI ZillioX 9 Manual de usuario
QDI
QDI Advance 5 Manual de usuario
QDI
QDI GeniuX 4 Manual de usuario
QDI
QDI X8800 Series Manual de usuario
QDI
QDI PlatiniX 2D Manual de usuario
QDI
QDI P6I440LX/DP Manual de usuario
QDI
QDI P5I915PL Manual de usuario
QDI
QDI PlatiniX 2E/333 Manual de usuario
QDI
QDI SynactiX 5EP Manual de usuario
QDI
QDI Advance 12 Series Manual de usuario
QDI
QDI LEGEND-V Manual de usuario
QDI
QDI KinetiZ 7T Manual de usuario
QDI
QDI SynactiX 1E Manual de usuario
Manuales populares de Placa madre de otras marcas
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manual de usuario
Gigabyte
Gigabyte GA-9IVDT Manual de usuario
Texas Instruments
Texas Instruments ADS8372EVM Manual de usuario
Commell
Commell MS-C73 Manual de usuario
IBT Technologies
IBT Technologies MB860 Manual de usuario
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manual de usuario
