QDI K8V800 Manual de usuario

Notice

The information inthisdocumentissubjectto

change inordertoimprovereliability,design,or

function withoutpriornoticeand doesnotrepre-

sentacommitmenton the partofthiscompany.

Inno eventwill webe liablefordirect, indirect,

special,incidental,orconsequentialdamages

arising outofthe useorthe possibilityofsuch

damages.

All trademarks arethe propertyoftheirrespec-

tiveowners.

If you need anyfurtherinformation,pleasevisit

ourweb-site:“www.qdigrp.com”.

Thisitemchecklistisonlyavailableforretail

market. Completelycheck yourpackage,If you

discoverdamaged ormissing items,contact

yourretailer.

ItemChecklist

K8V800seriesmainboard

QDIUtilityCD

1HDribboncable

1FDDcable

User’smanual

I/Oshield(option)

USBcable(option)

CertificateofCompliance

The followingproductshavebeen tested byuswiththe listedstandardsandfound in

compliancewiththe council EMCdirective89/336/EEC.It isdemonstrativeforthe

compliancewiththisEMCDirective.

Submittor:QDITechnologyLimited

23Floor,LincolnHouse,Taikoo Place

979 King’sRoad,QuarryBay,HONGKONG

Product: MotherBoard

M/N:K8V800

þEN55022/A1:2000 Limitsand methodsofmeasurementsofradio

disturbancecharacteristics ofinformation technology

equipment

þEN61000-3-2/A14:2000 Electromagneticcompatibility(EMC)

Part3:Limits

Section 2:Limitsforharmoniccurrentemissions

(equipmentinputcurrent<=16Aperphase)

þEN61000-3-3/A1:2001 Electromagneticcompatibility(EMC)

Part3:Limits

Section 3:Limitsofvoltage fluctuationsand flickerin

low-voltage supplysystemsforequipmentwith

rated current<=16A

þEN55024/A1:2001 Information technologyequipment-Immunitycharac-

teristics limitsand methodsofmeasurement

Signature:Date:2004.02.01

Printed Name:Wang Dayong Position:GeneralManager

Thestatementisbasedon asingleevaluation ofonesampleofabovementionedproducts.Itdoesnotimply

anassessmentofthewholeproduction and doesnotpermit theuseofthetestlab.logo.

Declaration ofconformity

TradeName:QDIComputer(U.S.A.)Inc.

ModelName:K8V800

ResponsibleParty:QDIComputer(U.S.A.)Inc.

Address:41456 ChristyStreet

Fremont,CA94538

Telephone:(510)668-4933

Facsimile:(510)668-4966

EquipmentClassification:FCC Class BSubassembly

TypeofProduct: Mainboard

Manufacturer:QDITECHNOLOGY(HK)Limited

Address:23Floor,LincolnHouse,Taikoo Place

979 King’sRoad,QuarryBay,HONG

KONG

SupplementaryInformation:

Thisdevice complieswithPart15 oftheFCC Rules.Operation issubjectto

thefollowing twoconditions:(1)thisdevice maynotcauseharmfulinterfer-

ence,and (2)thisdevice mustacceptany interference received,including

interference thatmaycauseundesiredoperation.

TestedtocomplywithFCC standards.

Signature:Date:2004

CONTENTS

Chapter1

Introduction.....................................................................1

KeyFeatures..................................................................2

Chapter2

InstallationInstructions.........................................................4

ExternalConnectors............................................................5

PS/2Keyboard/MouseConnector...................................5

USB1,USB2,USB3,USB4andLANConnectors...............5

ParallelPort,SerialPortConnectorandSPDIFoutport ......5

Line-injack,Mic-injack,Speaker-outjack.........................6

6-ChannelAudio.............................................................6

IEEE 1394 Port(optional).................................................6

ATX12VPowerSupplyConnectors&PowerSwitch......7

HardDiskLEDConnector(HD_LED)...............................7

ResetSwitch(RESET)..................................................7

PowerLEDConnector(PWR_LED).................................8

FanConnectors(CPU_FAN,CHS_FAN)...........................8

USB5,6;USB7,8..............................................................9

InfraredHeader(IrDA)..................................................9

Wake-UpOnLAN(WOL)(optional)..................................10

IEEE 1394_1Port(optional)..............................................10

AudioConnectors(CD_IN)..............................................11

6CH-BRACKERConnector(optional).....................................11

AudioInterface(F_Audio)................................................12

OnboardSATA................................................................12

UARTCom2(optional).....................................................13

GamePort(optional).......................................................13

JumperSettings..................................................................14

ClearCMOS(JCC)................................................................14

BIOS-ProtectionJumper(JAV)..............................................15

CONTENTS

Chapter3

BIOSDescription................................................................16

AWDFLASH.EXE...............................................................17

AWARD BIOSDescription.................................................18

Appendix

QDIUtilityCD......................................................................20

Using4-/6-ChannelAudio...................................................31

Layout

Caution

Besuretoadd someSiliconeGrease betweentheCPUand the

heatsinktokeepthemfullycontactedtomeettheheatsinkrequire-

ment.

Besuretounplug theAC powersupplybeforeadding or

removing expansion cards,RAMorothersystemperipherals,

otherwise yourmainboardand RAMmightbeseriouslydamaged.

Note:

ThismanualissuitableforK8V800 series ofmainboards.Each

mainboardiscarefullydesignedforthePCuserwho wantsdifferent

features.

-6A:with6channelAudio

-L:withonboardLAN

-F:withIEEE 1394 ports

Chapter1

K8V8001

Chapter1

Introduction

K8V800 seriesofmainboardsutilizeVIAK8T800+VIAVT8237 chipset,

providing afullycompatible,high performanceand cost-effectiveATX

platform.The newintegratedtechnologies,togetherwithAC’97 audio(2/

6-channel),8USB 2.0,2SATA,andATA133/100/66/33,givecustomers

an advanced,multimediasolution atreasonableprice.It provides

HyperTransportTMtechnologytosupportAMDAthlonTM64Socket754pro-

cessorsand the DDR266/333/400 memory.It alsoprovidesadvanced

featuressuchasWakeupbyUSBdevicesand Wake-on-LANfunctions.

SuspendingtoRAM,theoptimalimplementationoftheAdvancedConfigu-

ration and PowerInterfacemakesthe PC’spowerconsumption drop to

the lowestpossibleleveland enablequick wakeup.

Introduction

K8V800

Formfactor

ATXformfactorof305mm x230mm

Microprocessor

SupportsAMDAthlonTM64Socket754CPU

SupportsHyperTransportTMtechnology

Systemmemory

SupportsDDR266/333/400SDRAM

Supports64/128/256/512Mbtechnologyupto2GB

Providestwo184-pinDDRSDRAMinterfaces

OnboardIDE

SupportsIndependenttiming ofup to4drives

SupportsUltraATA33/66/100/133,PIOmode

TwofastIDEinterfacessupportingfourIDEdevicesincludingIDEharddisksandCD

ROMdrives

OnboardLAN(optional)

10/100Mbit/secEthernetsupport

10/100MLANinterfacebuilt-inonboard

USB2.0

USB2.0compliant,operatesat480Mbps,about40XtimesfasterthanUSB1.1which

currentlyworks atasnailspaceofjust12Mbps

Provides8USB 2.0ports

OnboardI/O

Onefloppyportsupportinguptotwo3.5″or5.25″floppydriveswith360K/720K/1.2M/

1.44M/2.88Mformat

Twohigh speed16550 compatibleCOMswith16bytesend/receiveFIFO

OneparallelportsupportsSPP/EPP/ECPmode

SupportsPS/2mouseandPS/2keyboard

Providesone IrDAconnector

AllI/Oportscanbe enabled/disabledinthe BIOSsetup

OnboardAudio

AC’972.3SpecificationCompliant

ProvidesonboardLine-inJack,Microphone-inJack,Speaker-outJackConnector

6-channelOnboardAudio

AC’972.3SpecificationCompliant

ProvidesFrontleft&right,Rearleft&right/Line-inJackandCenter&Woofer/Microphone-

inJack,whichcan be specified bysoftware

AGPInterface

Providesone standardVGAconnectorand integratedAGPunit

AGPconnectorsupportsAGP3.0includingAGP8Xdatatransfers

Chapter1

K8V8003

Advancedfeatures

PCI2.2SpecificationCompliant

ProvidesTrend ChipAwayVirusOnGuard

SupportsWindows98/2000/ME/XPsoft-off

SupportsWake-on-LAN

OnboardSATA

TwoSATAdevicesincludingSATAHDDandCDROM/DVDROMdevices

Supports150Mbpstransferrate.

BIOS

LicensedadvancedAWARD(Phoenix)BIOS,supportsflashROM,plugandplayready

SupportsIDECDROM/SCSI/USBbootup.

IEEE 1394 Ports(Optional)

SupportstwoIEEE1394aports

Greenfunction(optional)

SupportsACPIpowerstatus:S0(full-on),S1(poweron suspend),S3(suspend to

RAM),S4(suspend toDisk,dependson OS)and S5(soft-off)

MainExpansion Slotsand Connectors

Slot/Port(Quantity)Description

PCI(5)PCIslots

IDE(2)IDEports

FLOPPY(1)FloppyDriveport

DDR(2)DIMMsocket

USB(8)USBconnectors

AGP(1)AGPslot

LAN(1)LANconnector

COM(2)COMconnectors

PARALLEL(1)Parallelconnector

IrDA(1)IrDAconnector

InstallationInstructions

K8V800

Chapter2

Installation Instructions

ThissectioncoversExternalConnectorsandJumperSettings.Refer

tothe mainboardlayoutchartforlocationsofall jumpers,external

connectors,slotsand I/Oports.Furthermore,thissection listsall

necessaryconnectorpinassignmentsforyourreference.The par-

ticularstateofthejumpers,connectorsandportsareillustratedinthe

following figures.Beforesetting the jumpersorinserting these

connectors,pleasepayattention tothe direction.
