Pylontech Force-L1 Manual de usuario

Lithium-Ion Phosphate Battery

Force-L1 Product Manual

Information Version: 2.2

This manual introduces Force-L1 from Pylontech. Force-L1 is a 48Vdc Lithium-Ion Phosphate

Battery storage system. Please read this manual before you install the battery and follow the

instruction carefully during the installation process. Any confusion, please contact Pylontech

immediately for advice and clarification.

CONTENT

1. SAFETY PRECAUTIONS .......................................................................................................................1

1.1 Before Connecting...........................................................................................................................1

1.2 In Using.................................................................................................................................................2

2. INTRODUCTION..................................................................................................................................3

2.1 features:...............................................................................................................................................3

2.2 Specifications.....................................................................................................................................4

2.2.1 The parameter of system.............................................................................................................4

2.2.2 Battery Module (FL48074)............................................................................................................6

2.2.3 Control Module FC0048-100 (internal power supply)..........................................................7

Definition of RJ45 Port Pin .................................................................................................................... 11

3. EMERGENCY SITUATIONS................................................................................................................12

19P1FL0801

1/ 12

1. Safety Precautions

Reminding

1) It is very important and necessary to read the user manual carefully (in the accessories)

before installing or using battery. Failure to do so or to follow any of the instructions or

warnings in this document can result in electrical shock, serious injury, or death, or can

damage battery, potentially rendering it inoperable.

2) If the battery is stored for long time, it is required to charge them every six months, and the

SOC should be no less than 90%;

3) Battery needs to be recharged within 12 hours, after fully discharged;

4) Do not expose cable outside;

5) All the battery terminals must be disconnected for maintenance;

6) Please contact the supplier within 24 hours if there is something abnormal.

7) Do not use cleaning solvents to clean battery;

8) Do not expose battery to flammable or harsh chemicals or vapors;

9) Do not paint any part of battery, include any internal or external components;

10) Do not connect battery with PV solar wiring directly;

11) The warranty claims are excluded for direct or indirect damage due to items above.

12) Any foreign object is prohibited to insert into any part of battery.

Warning

1.1 Before Connecting

1) After unpacking, please check product and packing list first, if product is damaged or

lack of parts, please contact with the local retailer;

2) Before installation, be sure to cut off the grid power and make sure the battery is in the

turned-off mode;

3) Wiring must be correct, do not mistake the positive and negative cables, and ensure no

short circuit with the external device;

4) It is prohibited to connect the battery and AC power directly;

5) The embedded BMS in the battery is designed for 48VDC, please DO NOT connect

battery in series;

6) Battery system must be well ground and the resistance must be less than 1Ω;

7) Please ensured the electrical parameters of battery system are compatible to related

equipment;

19P1FL0801

2/ 12

8) Keep the battery away from water and fire.

1.2 In Using

1) If the battery system needs to be moved or repaired, the power must be cut off and the

battery is completely shut down;

2) It is prohibited to connect the battery with different type of battery.

3) It is prohibited to put the batteries working with faulty or incompatible inverter;

4) It is prohibited to disassemble the battery (QC tab removed or damaged);

5) In case of fire, only dry powder fire extinguisher can be used, liquid fire extinguishers are

prohibited;

Please do not open, repair or disassemble the battery except staffs from Pylontech or authorized

by Pylontech. We do not undertake any consequences or related responsibility which because

of violation of safety operation or violating of design, production and equipment safety

standards.

19P1FL0801

3/ 12

2. Introduction

Force-L1 lithium iron phosphate battery is one of new energy storage products developed and

produced by Pylontech, it can be used to support reliable power for various types of equipment

and systems. Force-L1 is especially suitable for application scene of high power, limited

installation space, restricted load-bearing and long cycle life.

Force-L1 has built-in BMS battery management system, which can manage and monitor cells

information including voltage, current and temperature. What’s more, BMS can balance cells

charging and discharging to extend cycle life.

Multiple batteries can connect in parallel to expand capacity and power in parallel for larger

capacity and longer power supporting duration requirements.

2.1 features:

The whole module is non-toxic, non-polluting and environmentally friendly;

Cathode material is made from LiFePO4 with safety performance and long cycle life;

Battery management system (BMS) has protection functions including over-discharge,

over-charge, over-current and high/low temperature;

The system can automatically manage charge and discharge state and balance current

and voltage of each cell;

Flexible configuration, multiple battery modules can be in parallel for expanding capacity

and power

Adopted self-cooling mode rapidly reduced system entire noise;

The module has less self-discharge, up to 6 months without charging it on shelf, no memory

effect, excellent performance of shallow charge and discharge;

Working temperature range is from -10℃to 50℃, (Charging 0~50℃; discharging -10~50℃)

with excellent discharge performance and cycle life;

Small size and light weight, stackable connection comfortable for installation and

maintenance;

19P1FL0801

4/ 12

2.2 Specifications

2.2.1 The parameter of system

19P1FL0801

5/ 12

Product Type

FORCE-L1

(48V518AH)

Cell Technology

Li-ion(LFP)

Battery System Capacity(kWh)

24.86

Battery System Voltage(Vdc)

Battery System Capacity(AH)

518

Battery Controller Name

FC0048-100

Battery Module Name

FL48074

Battery Module Quantity(pcs)

Battery Module Capacity(kWh)

3.55

Battery Module Voltage(Vdc)

Battery Module Capacity(AH)

Battery Module Cell Series Quantity(pcs)

Battery System Charge Upper-Voltage(Vdc)

53.5

Battery System Charge Current(Standard)

100

Battery System Charge Current(Normal)

100

Battery System Charge Current(Max.@15S)

110

Battery System Discharge lower-Voltage(Vdc)

44.5

Battery System Discharge Current(Standard)

100

Battery System Discharge Current(Normal)

100

Battery System Discharge Current(Max.)

110

Efficiency

96%

Depth of Discharge

90%

Dimension(W*D*H,mm)

600*380*1380

Communication

RS485\CAN

Protection Class

IP55

Weight (kg)

265

Operation Life(Years)

15+

Operation Temperature(℃)

0~50℃

Storage Temperature(℃)

-20~60℃

Product Certificate

VDE2510-50, IEC62619 CE

Transfer Certificate

UN38.3

Other:

1）Battery Controller Dimensions(W*D*H)

2）Battery Module Dimensions (W*D*H)

3）Battery bottom base Dimensions(W*D*H)

600×380×150mm

600×380×170mm

600×380×40mm

19P1FL0801

6/ 12

2.2.2 Battery Module (FL48074)

Product Type

FL48074

Cell Technology

Li-ion (LFP)

Battery Module Capacity (kWh)

3.55

Battery Module Voltage (Vdc)

Battery Module Capacity (Ah)

Battery Module Serial Cell Quantity (pcs)

Battery Cell Voltage (Vdc)

3.2

Battery Cell Capacity (AH)

Dimension (W*D*H, mm)

600*380*170

Weight (kg)

Operation Life

15+Years

Operation Cycle Life

5,000

Operation Temperature

0~50℃

Storage Temperature

-20~60℃

Transportation Certificate

UN38.3

19P1FL0801

7/ 12

2.2.3 Control Module FC0048-100 (internal power supply)

Control Module (FC0048-100) Display Panel

LED Button

Short Press

Display the LED panel for 20sec.

Long Press

(more than

5sec)

When status LED fast flash blue ●, loss the button, then it is

chosen 115200 baud rate of RS485.

When status LED fast flash orange ●, loss the button, then it is

chosen 9600 baud rate of RS485.

19P1FL0801

8/ 12

Status

System Status: blue means working normally; Orange means protection or failure.

Blue, slow flashing.

Power Relay CLOSE. Alarm exist but can work continue.

Blue, lighting.

Power Relay CLOSE. Normal.

Orange, slow flashing.

Power Relay OPEN. Normal protection, can recover on

its own (Over Voltage, Under Voltage, etc.).

Orange, lighting.

Power Relay OPEN. Important protection, failure, lost

efficacy etc. Or failed to assign address.

Battery Module Status

Battery Module Status: blue means working normally; Orange means protection or failure

Blue, slow flashing.

Alarm exist but can work continue.

Blue, lighting.

Normal.

Blue, light once.

1~n LED lights on one by one, for address distribution.

Orange, slow flashing.

Module offline.

Orange, lighting.

Module protection, failure, etc.

System Capacity

Indicate the system SOC.

Blue, slow flashing.

Each LED indicate 25%SOC. Idle

Blue, flashing.

Each LED indicate 25%SOC. Discharge

Blue, lighting.

Each LED indicate 25%SOC. Charge

Remark: Slow flashing: 1.5s ON/0.5s OFF. Flashing 0.5s ON/0.5s OFF.

Fast flashing: 0.1s ON/0.1s OFF.
