Pylontech US2000 PLUS Manual de usuario

1 2 4

1 External

Power Cable - 2 External

Power Cable + 4 External

Communication Cable

3 Fan

Power Cable -/+

In the battery modules’ cable kit

Power Link Port 0

Link Port 1

US2000 Plus Lithium Battery + +

- -

Cables connection of lower layer 3 batteries

Power Link Port 0

Link Port 1

US2000 Plus Lithium Battery + +

- -

Power Link Port 0

Link Port 1

US2000 Plus Lithium Battery + +

- -

Pylontech Out-door Cabinet Cable Connection

B C

Power Link Port 0

Link Port 1

US2000 Plus Lithium Battery

+ +

- -

Cables connection of upper layer 3 batteries

Power Link Port 0

Link Port 1

US2000 Plus Lithium Battery

+ +

- -

Power Link Port 0

Link Port 1

US2000 Plus Lithium Battery

+ +

- -

Master Battery

B C

Move the cabinet to the basement.

Please use the attached 2 wide nylon belts to handling cabinet.

Unpack the corrugated box.

And lift the cabinet from the box.

Fix with the hangers (recommend)

Move the 2 hangers from inside to outside.

M12

foundation

bolt

Or fix the cabinet with the cabinet feet.

M12

foundation

bolt

Connect the grounding cable from basement.

Grounding

Point

Wall

•Connect the cables of lower layer 3 batteries. Please see < Cabinet OD Cable Connection >.

Put the separate board on the 4 stop blocks. Install 3 batteries on the upper layer just like under layer.

And lock the blade bolt.

•Connect the cables of lower layer 3 batteries. Please see < Cabinet OD Cable Connection >.

•Connect the cable terminals to the inverter.

1 2 43

•Turn on each battery’s power switch.

•Press Master Battery’s soft start button. Please see the product menu (capital 4.2 B).

Lock the 6 dowels for these 3 batteries.

Take away the 4 shield sleeves on the rails. Put 3

batteries on the under layer. And lock the blade bolt.

Align the calibration and the battery’s hole.

Master Battery

Pylon Technologies Co., Ltd.

No. 73, Lane 887, ZuChongzhi Road, Zhangjiang Hi-Tech Park

Pudong, Shanghai 201203, China

T +86-21-51317697 | F+86-21-51317698

E [email protected]

W www.pylontech.com.cn
