Pyle PLTLD16 Manual de usuario
15.6’’LEDRVDigitalTV
FHD Flat Screen TV with DVD Combo
with DigitalAntenna and 12V/24V CarAdapter
PLTLD16
NTSC, ATSC
www.PyleUSA.com
2
CONTENTS
SAFETY INFORMATION
PRODUCT INTRODUCTION
CONNECTIONS
REMOTE CONTROL
SETUP WIZARD
SELECT INPUT SOURCE
MAIN MENU
PICTURE MENU
SOUND MENU
TIME MENU
SETUP MENU
CLOSE CAPTION
LOCK MENU
CHANNEL MENU
PC MENU
DVD OPERATION
SPECIFICATION
3
5
6
7
8
9
9
10
11
13
14
15
16
18
19
20
24
www.PyleUSA.com
3
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS- READ CAREFULLY BEFORE USE.
Take note of the following safety information which appears on the back of the TV.
KEEP THESE INSTRUCTIONS
• Do not use this TV near water.
• Clean only with a slightly damp cloth.
• Do not block any ventilation openings.
• Install in accordance with the supplied Quick Start Guide and this User Guide.
• Protect the power chord from being walked on or pinched, particularly at plugs,and the point where it
exits from the TV.
• Do not allow the power chord to overhang the edge of a table.
• Unplug this TV during lightening storms or when unused for long periods oftime.
WARNING!
TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS TV TO RAIN OR
MOISTURE. THE TV MUST NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS
FILLED WITH LIQUIDS SHOULD BE PLACED ON THE TV.
NOTE: No naked ames such as candles should be placed on the TV.
CAUTION TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE ANY COVER SCREWS.
NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates that there are important operating maintenance instructions
in the literature accompanying this unit.
This symbol indicates that dangerous voltage constituting a risk of electric shock is
present within this unit.
www.PyleUSA.com
4
SAFETY INFORMATION
This unit has been produced according to aII current safety regulations. The following safety tips
should safeguard users against careless use and the dangers.
• Although this appliance has been carefully manufactured and rigorously checked prior leaving the
factory, as with all electrical appliances it is possible for problems to develop. If you notice smoke, an
excessive build up of heat or any other unexpected phenomena, you should disconnect the plug from
the mains power socket immediately.
• Ensure that the unit is suciently ventilated! Never place next to or underneath curtains!
• The mains plug or appliance coupler is used as the disconnect device, the disconnect device shall
remain readily operable.
• This set should only be connected to a mains power supply which matches that stated on the Iabel on
the rear of theTV- do not attempt to connect it to any other type of supply.
• The socket -outlet must be installed near the equipment and easily accessible.
• To prevent overload, don't share the same mains supply socket with too many other items of equipment.
• Apparatus with Class 1 construction shall be connected to a mains socket outlet with a protective
earthing connection.
• Keep away from rodents. Rodents enjoy biting into electric exes.
• Always hold the plug when pulling out the plug from the mains supply socket.
Do not pull on the ex, the ex can become overloaded and cause short circuit.
• Set up the unit so that no one is able to trip over the ex.
• Do not place heavy items on the ex,which may damage it.
• Take note that the ex cannot be reached and pulled by young children to avoid injury.
• Do not set up the unit near to heat sources.
The casing and the ex could be damaged by the impact of heat.
• The screen is made of plastic and can break if damage is done.
Be careful when collecting sharp edged plastic splinters to avoid injury.
• Avoid placing the unit on any surface that may be subject to vibrations or shocks.
• To protect the unit during a thunderstorm unplug the AC power cable and disconnect the aerial.
Caution: Do not touch the aerial (RF) connector.
• When you leave your home for a long period of time, unplug the AC power cable for safety reasons.
• The unit becomes warm when in operation. Do not place any covers or blankets on the unit in order to
prevent overheating. The ventilation holes are not to be blocked. Do not set up near radiators.
Do not place in direct sunshine. When placing on a shelf leave 5cm (2") free space around the whole unit.
• Do not allow water or moisture to enter the TV. Do NOT use in wet or moist areas such as Bathrooms,
steamy kitchens or near swimming pools.
• Do not use this unit when moisture condensation may occur.
• Any repairs must be carried out by qualied personnel only.
• Do not open this unit. A non- expert attempting to repair the unit could be dangerous and potentially
cause a re hazard.
• Liquids spilt into the unit can cause serious damage. Switch the set OFF and disconnect the mains
power supply, then consult a qualied service person before attempting to use the unit again.
www.PyleUSA.com
5
• Do NOT remove the safety covers. There are no useable or serviceable parts inside. You may invalidate
the warranty. Qualied personnel must only service this apparatus.
• Do NOT tap or shake the screen, you may damage the internal circuits. Take good care of the remote
control, do not drop.
• Never place hot objects or open ame sources on or close to the TV.
• High temperatures can melt plastic and lead to res.
• To clean the TV use a soft dry cloth. Do NOT use solvents or petrol based uids. For stubborn stains, you
may use a damp cloth with dilute detergent.
HEADPHONE WARNING
Loud music can damage your hearing irreversibly, therefore do not set the volume to a high level
when listening through headphones, particularly for lengthy listening periods.
WHERE TO INSTALL
Locate the television away from direct sunlight and strong lights, soft indirect lighting is recommended
for comfortable viewing. Use curtains or blinds to prevent direct sunlight falling on the screen.
Place the TV on a sturdy platform of which the surface should be at and steady.
This will prevent it from falling over. Make sure the television is located in a position where it cannot be
pushed or hit by objects, as pressure will break or damage the screen, and so that small objects cannot be
inserted into the ventilation slots or openings in the cabinet.
Product Introduction
Front View
LED Indicator Remote Control Window (keep clear)
The functions of the TV buttons are
described below.
PLAY/PAUSE:
Play/pause the disc playing.
EJECT: Eject the disc.
SOURCE: Press to select the source.
MENU: Press to display the OSD menu,
Press again to exit the menu.
CH+/CH- :
Press to scan through channels. Use to
move down/up in the OSD menu screen.
VOL+/ VOL- : Press to adjust the volume.
Use to move left/right in the OSD menu
screen VOL+ button can be used to skip
forward to next menu.
POWER: Turn on/o the TV set.
www.PyleUSA.com
6
CONNECTIONS
1/2. Audio output to connect power amplier stereo equipment.
3. Connect a stereo headphone (3.5mm) for private listening.
4. Connect an optional coaxial digital cable through a compatible amp/receiver to enjoy superior
audio sound.
5/6/7. Connect to an AV device that features component video and audio output jacks.
8. Connect it to the HDMI of DVD or other equipment.
9. Connect an optionalVGA cable from your personal computer.
10. Connect an optional 3.5mm audio cable for sound when using VGA.
11. Connect antenna or cable for television reception.
12. For service technician use only.
13. Connect to the mains adaptor or the car adapter (Input for the 12V/24V power supply)
www.PyleUSA.com
7
REMOTE CONTROL
The remote control is using Infra-Red (IR). Point it towards the front of the LED TV.
The remote control may not work correctly if it is operated out of range or out of angle.
www.PyleUSA.com
8
SET UP WIZARD
STEP 1: Choosing your Picture mode
Use the arrow buttons to select Home Mode standard. Press the ENTER button to complete the step.
STEP 2:
Use the arrow buttons to select Menu Language.
Use the arrow buttons to select English-Francais-Espanol.
Use the arrow buttons to select AIr/Cable.
Select Cable, then press the button to select Cable System. Then press the button to select
Auto-STD-IRC-HRC.
www.PyleUSA.com
9
AUTO SCAN
Press ENTER/ button to start auto scan.
SELECT INPUT SOURCE
MAIN MENU
Press MENU to display the main menu or return to the previous menu or close the main menu.
Press to highlight the desired menu icon, and press ENTER to select.
Press SOURCE button to display the input source list;
Press or SOURCE button to select the input source;
Press ENTER button to enter the input source;
Press EXIT button to quit.
