Pyle PP555 Manual de usuario

Mini-Phono Pre-Amplifier

PP555

www.pyleaudio.com

Please read before installing

Installation Manual

The pyle PP555 mini phono preamp was manufactured to enable you to connect

your record players (L) & (R) RCA OUT to the AUX, CD, DVD, Mp3 LINE IN on most

Stereo amplifiers.

This Unit :

•Converts your phono signal to a line level signal

•State-of-the-art phono preamp to accommodate magnetic pickups

•Ultra low-noise audio operational amplifiers offer outstanding sound performance

•Dedicated RCA and 1/4' output connections

•DC 12-Volt adapter included

Installation:

1. You can power your PP555 by installing a 9V battery in the bottom battery

compartment or by plugging the 12-Volt DC Adaptor into the DC jack located

under the grounding post.

Note Please be sure to adjust Power selector switch accordingly depending on

which power source you are using.

2. When connecting your record player to the pre-amp please

be sure to connect the ground cable. Most all record players

have a double RCA (L) & (R) combined with a ground wire.

Failure to connect ground wire properly may result in humming

noise.

3. You can choose to connect your amplifier's LINE IN to either

the (L) & (R) RCA OUTPUT or the 1/4 " Stereo Jack.

We hope you enjoy your Pyle product!

If you have any questions please contact:

support@pyleaudio.com
