PURE Oasis Flow Manual de usuario
Quickstart Guide
Kurzanleitung
Mise en service rapide
Guida rapida
Guía de inicio rápido
Kvikstart
Oasis_Flow_ML_QSb.indb 1 22/06/2010 14:23:06
2
Getting started 3
Using the controls 4
About the icon bar 5
Listening to digital radio 6
Listening to FM radio 7
Connecting to the internet 8
Listening to internet radio 9
Listening to other internet content 10
The Lounge 11
FlowSongs 12
Using FlowSongs 13
Streaming music from your computer 14
Connecting an iPod or auxiliary device 16
Options 17
Safety instructions 19
Contents
This Quickstart will familiarize
you with the basic controls and
functions of your Oasis Flow.
For in-depth functions, please
refer to the Owner’s Manual at
support.pure.com.
Oasis_Flow_ML_QSb.indb 2 22/06/2010 14:23:06
3
Screw the aerial into the socket on the top panel of your Oasis Flow.
Insert the connector of the supplied mains adapter into the 12V DC
input on the side of the radio. Plug the adapter into the mains supply
and switch on. Oasis Flow is displayed briefly.
Choose your on-screen language (English, French, or German) by
turning the Select dial to scroll to and highlight the language you want.
Push the Select dial in to confirm your choice. Repeat this process to
select the time zone and region closest to you.
The audio source screen is displayed, showing the following options:
Digital radio See page 6
The Lounge (internet content) See pages 8-11
Media player See pages 14-15
FM radio See page 7
Auxiliary input See page 16
Getting started
Digital radio
The Lounge
Media player
FM radio
Auxiliary input
To keep
Oasis Flow
weatherproof,
push connectors
in firmly and
ensure that the
rubber covers on
unused sockets
are closed.
The audio source screen
Oasis_Flow_ML_QSb.indb 3 22/06/2010 14:23:11
4
1. Volume dial
Turn to adjust volume. Push to
mute and un-mute.
2. Select dial
Turn to browse/highlight
stations or options, push to
select. Push to pause a media
track or podcast.
3. Back
Tap to go back one screen.
Repeat to return to the audio
source screen.
4. Standby button
Press to switch the radio on or
into standby (off if not attached
to mains power supply).
Using the controls
5. Touch area
Oasis Flow has a touch
sensitive area at the bottom
of the display. Tap the word or
icon that corresponds to the
function you want to use. For
example:
12
3
4
5
Meet Me In The Sky
BTNH
The World’s Enemy
Track 03
Options
Oasis_Flow_ML_QSb.indb 4 22/06/2010 14:23:12
5
FM
Signal strength
(Digital/FM/Wi-Fi)
Stereo signal (Digital/FM)
ChargePAK battery level*
Clock
Alarm/timer set indicators
Volume level
About the icon bar
Buzz FM
OKPresets Options
Live from The Hive! The Lounge (internet content)
FM radio
Media player
MP
Auxiliary input
AUX
Source Icons
Source Icons
DR
Digital radio
*Oasis Flow has a built-in ChargePAK rechargeable battery. When
plugged into a mains supply the battery icon will be animated to show
that ChargePAK is charging.
Mute
Oasis_Flow_ML_QSb.indb 5 22/06/2010 14:23:14
6
Listening to digital radio
Extend the aerial for optimum reception and select Digital radio from
the audio source screen. The first time you select Digital radio, Oasis
Flow will perform an autotune to find all available stations and will
tune into one when finished. To change station, turn the Select dial to
browse the list of stations and push to tune in to the highlighted station.
To store a digital station as a preset
Tune to the station you want to store as a preset and tap Presets. Turn
the Select dial to highlight a preset number between 1 and 30. Tap
Store to store the preset. (You can replace existing presets.)
BBC Radio 6Music
Now playing: Juicy Fruit
by Mtume
Presets Options
DR
BBC Radio 6Music
OK
Store
Empty 1
Empty 2
Empty 4
Empty 5
Oasis_Flow_ML_QSb.indb 6 22/06/2010 14:23:15
7
Listening to FM radio
Extend the aerial for optimum FM reception and Select FM radio from
the audio source screen. Turn the Select dial to seek to the next or
previous FM station. You can also store up to ten presets in the same
way as digital radio presets (see page 6).
103.30
Seek tune
OKPresets Options
Oasis_Flow_ML_QSb.indb 7 22/06/2010 14:23:15
8
Select The Lounge from the audio source screen.
Your Oasis Flow will scan for wireless networks and show them in a
list. Select your network. Enter your network key or password by using
the Select dial to highlight and select characters. Select sp to insert a
space. Tap More... for lower-case and tap Delete to remove the last
character. Tap Save to finish, your Oasis Flow will connect.
Connecting to the internet
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
sp0123456789
Enter key or password
Delete Save More...
6578616D706C At this point, you can register and connect your radio with the Lounge. (See
the full Owner’s Manual at support.pure.com.)
(3)BT Home Hub A102
(9)SmithFamily
Select wireless network
- No network selected -
Manual
Oasis_Flow_ML_QSb.indb 8 22/06/2010 14:23:15
9
Thousands of radio stations around the world also broadcast online.
To listen, select The Lounge (internet content) from the audio source
screen. Your Oasis Flow will tune to an available station. Turn the Select
dial to enter the Lounge home screen. Select Stations to see a list of
currently available internet stations. Use the Select dial to browse the
list and push to tune in. You can add a station to your favourites by
tapping Add ♥.
Search for a station
Tap Search when browsing the station list to search for stations by
Name, Genre, Country, Language, Quality (reliability/bit rate), or any
combination of these. Use the Select dial to set your options and tap
Go to see the list of results.
My favourites♥
Stations
Listen again
Podcasts
PURE sounds
Listening to internet radio
Clear all Clear
Go Lounge
Name [All]
Genre [Classical]
Country [Netherlands]
Language [Dutch]
Quality [All]
The Lounge home screen
Station search screen
Oasis_Flow_ML_QSb.indb 9 22/06/2010 14:23:15
10
Select The Lounge from the audio source screen, then one of the
following content types:
Listen again
Some stations offer a ‘listen again’ facility, letting you catch up with
anything you might have missed. These archived radio programmes are
available to listen to for a set period of time after the live broadcast.
Podcasts
Podcasts are pre-recorded audio shows on a wide variety of subjects
such as comedy, arts, business, and culture, for you to enjoy anytime.
PURE Sounds
Our library of sounds, from birdsong to cityscapes, rolling thunder to
sports cars.
Listening to other internet content
Oasis_Flow_ML_QSb.indb 10 22/06/2010 14:23:16
