PULSE+ TU-101 Manual de usuario

1



AM / FM Tuner + RDS

Model: TU-101

www.pulse-audio.co.uk

2



Safety Information

The lightning bolt

within a triangle is

intended to alert the

user to the presence

of dangerous voltage

levels within the

product’s enclosure.

This voltage may be of

sufficient magnitude to

constitute an electric

shock risk.

To reduce the risk of

electric shock, do not

remove cover of this

device. There are no user

serviceable parts inside.

Refer servicing only to

qualified service

personnel.

The exclamation point

within a triangle is intended

to alert the user to

important operating and

maintenance (servicing)

instructions in the literature

accompanying the

appliance.

Safety Precautions

Read and retain these instructions.

Follow all instructions and heed warnings.

Do not use this device near water or in high humidity areas.

If the surface becomes dirty, clean only with dry cloth, do not use solvents or

thinners.

Install in accordance with the manufacturer’s instructions.

Do not install near heat sources such as radiators, heat registers, stoves, or other

devices that produce heat.

Do not defeat the safety purpose of the grounded plug. The BS1363A 13A mains

plug has two blades and a third ground prong. The wide blade or third prong is

provided for your safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

Protect the power cord from being stressed at the plugs, main socket outlet, and

where they exit the tuner.

Only use accessories specified by the manufacturer.

Unplug the device during lightning storms or when unused for an extended time.

Refer all servicing to qualified personnel.

This device must not be exposed to water in any way. No object filled with liquids

should be placed on apparatus.

Keep unit away from other tuners & TVs as this may cause undesirable interference

to these devices.

For installation, mount unit securely in a 19” rack, or on a solid flat surface.

3



Pulse 1U 19” AM/FM Tuner with RDS

The PULSE TU-101 is a fully featured, 19” rack mounting professional AM/FM tuner.

Designed to provide high quality, reliable performance for all applications including

schools, community centres, retail shops and industrial installations.

This unit includes a host of features, along with an impressive list of specifications, which

are detailed over the next pages. Please take the time to read this document completely

prior to installation of this product. Should you have questions regarding installation or

operation of this unit, please contact your Pulse Retailer or Pulse Technical Support.

Features

AM & FM Radio Tuner with RDS

Auto/manual tuning

40 Preset memory (10 AM, 30 FM)

LCD screen

Radio station display

Automatic radio controlled time & date

Outputs: 2x Balanced XLR (L+R)

IR remote control (requires 2xAAA batteries)

1U 19” Rack mountable with removable rack ears

Included Accessories

Instruction manual

IR remote control

AM Loop antenna

UK power cable

Rack ears

4



Connections & Controls



4

12

8

1

1415 16

109

13

2

5



1. Power Switch: Power on/off switch for tuner.

2. Memory Presets: Quick access to stored AM/FM radio stations (1-10).

3. Display: 2 Row, 32 character LCD display

4. Remote Sensor: Infrared sensor for remote control.

5. Down / Up: Press to decrease / increase the receiving frequency.

(By increments of:- AM: 0.09KHz - FM: 0.05MHz)

6. Band: Changes tuner between AM and FM modes.

7. Direct: This function allow you to select a specific radio frequency directly.

8. Sleep: This button allows a sleep timer to be set

9. ME-Down/Up: Toggles through the stored radio stations.

10. Memory: Used to manually set a memory pre-set.

11. ASM: Auto Search and Memory function.

12. MO/ST: Press this button to change the tuner between Mono and Stereo modes.

(Stereo mode will only be available if the signal is of sufficient strength)

13. AM Input: Spring terminals for supplied AM loop antenna. (For weak signal areas

it is advised for an external aerial to be connected)

14. FM Input: 75ΩFM coaxial antenna input. (For weak signal areas it is advised for

an external aerial to be connected)

15. XLR Outputs: Balanced audio signal outputs (left and right), for connecting to

mixer or amplifier.

16.Power Input: IEC socket for supplied power lead.

17.IR Remote: Full function IR remote control.

18.Removable Rack Ears: Allows unit to be mounted into a 19” rack or removed

for stacking.

Extra buttons on remote control:

RDS : Change RDS functions : PS – PTY – RT - CT

+10/-- : Used to advance through the memory pre-sets by +10.

Mute : Press to mute the audio output, press again to resume audio.



6



Functions & Settings

Change Between AM & FM Modes:

1. To change receiving mode from AM to FM, simply press the BAND button.

Tuning In AM Mode:

Auto Tune & Storing.

1. To carry out Auto tuning in AM mode press the BAND button so the display

shows the tuner is in AM mode.

2. Press and Hold the ASM button for 2 seconds. The auto-scan function will search

and store all available AM radio stations in the memory presets.

3. Any previously stored AM stations will be replaced when using this mode.

Note: If no stations are stored then the signal is too weak, either reposition the

Loop antenna and try again or use an external antenna.

Manual Tuning.

1. To carry out Manual tuning in AM mode press the BAND button so the display

shows the tuner is in AM mode.

2. Press either the UP or DOWN buttons to change the AM frequency by 9KHz steps

to the desired frequency, or Hold the UP or DOWN buttons for 2 seconds to skip

to the next available radio station.

Direct Tuning.

1. To carry out Direct tuning in AM mode press the BAND button so the display

shows the tuner is in AM mode.

2. Press the DIRECT button (---- will be displayed), use the number keys (1-10/0)

to select the desired frequency then press the DIRECT button again. (Note: If

the frequency selected is outside the tuners range then ERROR will be displayed).

Tuning In FM Mode:

Auto Tune & Storing.

1. To carry out Auto tuning in FM mode press the BAND button so the display

shows the tuner is in FM mode.

2. Press and Hold the ASM button for 2 seconds. The auto-scan function will

search and store all available FM radio stations in the memory presets.

3. Any previously stored FM stations will be replaced when using this mode.

Note: If no stations are stored then the signal is too weak, either reposition the

Loop antenna and try again or use an external antenna.

7



Manual Tuning.

1. To carry out Manual tuning in FM mode press the BAND button so the display

shows the tuner is in FM mode.

2. Press either the UP or DOWN buttons to change the FM frequency by

0.05MHz steps to the desired frequency, or Hold the UP or DOWN buttons for

2 seconds to skip to the next available radio station.

Direct Tuning.

1. To carry out Direct tuning in FM mode press the BAND button so the display

shows the tuner is in FM mode.

2. Press the DIRECT button (---.-- will be displayed), use the number keys (1-10/0)

to select the desired frequency then press the DIRECT button again.

(Note: If the frequency selected is outside the tuners range then ERROR will be

displayed).

Storing A Memory Pre-Set Manually:

1. Tune into desired AM or FM radio station frequency.

2. Press the MEMORY button , a memory preset channel will now be flashing

(CH01) on the LCD screen.

3. Use the UP or DOWN buttons to select the required Pre-Set location, then press

MEMORY button again to finalise the selection.

(Note: If the process is left for 5 seconds without finalising, the station will not be

stored in the memory location and the process will need to be restarted)

Selecting A Memory Pre-Set:

1. For memory pre-sets in locations 1-10 you can use the number keys to go

directly to you stored radio station.

2. Or you can use the ME-UP or ME-DOWN buttons to skip through each memory

location.

3. For FM mode only, you can skip by 10 memory locations by using the +10/--

button on the remote control.

8



Setting a Sleep Timer:

1. Press the SLEEP button, this button allows a sleep timer to be set.

2. Select from one of the pre-set sleep times.

90min, 80min, 70min, 60min, 50min, 40min, 30min, 20min, 10min

3. Once the desired sleep time is selected the display will show how many minutes

are left until the tuner automatically goes into sleep mode.

4. To exit sleep mode press the SLEEP button until no time is displayed.

Extra Remote Control Functions

RDS Modes:

1. The RDS button on the remote allows you to display the following data feeds on

the LCD if available.

2. PS – Programme Service (Station identity name).

PTY – Programme Type (Genre style of programme. News, Drama, Rock, Varied).

RT – Radio Text (Static or scrolling programme text).

CT – Clock Time.

MUTE:

1. The MUTE button can be used to turn off the audio output signal from the tuner

to the connected mixer or amplifier.

2. Press the MUTE button to turn off the audio signal (MUTE will be displayed).

3. Press the MUTE button again to resume the audio signal to the connected mixer

or amplifier.



9



Technical Information

AM Input: Spring terminals for Loop antenna

FM Input: Coaxial for 75 Ohm Unbalanced antenna

Outputs: 2x Balanced XLR (L+R)

Power supply: 230V AC

Power consumption: 50VA

Dimensions (WxHxD): 430x44x185mm (excl. rack ears)

Weight: 2.32kg

AM‐ElectricalPerformance

ParameterValueUnit

AMTuningRange522‐1620KHz

AMStepFreq.9KHz

Sensitivity52uVemf

FM‐ElectricalPerformance

ParameterValueUnit

FMTuningRange87.5‐108MHz

FMStepFreq.0.05MHz

Sensitivity10uVemf

AudioStereoSeparation35dB

AudioOutputVoltage400mVrms

Audio(S+N)/N50dB

AudioTHD0.1%

10



Compliance

When this product reaches the end of its life, do not dispose with household waste. See

www.recycle-more.co.uk for details of how to dispose of PULSE products in an

environmentally sound fashion, or contact PULSE directly via www.pulse-audio.co.uk

Warranty

Pulse products are warranted, by Pulse, against manufacturer defects for a period of one

year from the original date of purchase. This warranty is limited to manufacturer defects,

in either materials or workmanship. PULSE, or any other worldwide divisions of Premier

Farnell PLC, is not responsible for any consequential or inconsequential damage to any

other component, structure or the cost of installation or removal of said items. Defective

items should be returned to the retailer from whom they were originally purchased.

This warranty will not cover damage due to improper use or items damaged by weather.

Batteries are covered by a 90 day warranty from date of purchase.

For questions or specific information regarding warranty replacement or repair, please

contact:

PULSE

www.pulse-audio.co.uk

Tabla de contenidos

Otros manuales de Receptor de coche de PULSE+

PULSE+

PULSE+ TU-100 Instrucciones de instalación

Manuales populares de Receptor de coche de otras marcas

Motorola

Motorola VWA63 Manual de usuario

Nextar

Nextar D3201 Manual de usuario

Alpine

Alpine CDE-163BT Manual de usuario

Pioneer

Pioneer DEH-P645R Manual de usuario

Axxera

Axxera XDMA7600 Instrucciones de funcionamiento

XM OnyX Manual de usuario

Sound Storm

Sound Storm STM93R Manual de usuario

Soundstream

Soundstream VIR-5000 Manual de usuario

Avson

Avson MKT Platform Manual de usuario

Sony

Sony MEX-1HD - Audio Library System Manual de usuario

Pioneer

Pioneer DVH-P500UB Manual de usuario

JVC

JVC KD-AHD69 Manual de usuario

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manual de usuario

Sony

Sony CDX-4160 - Cd Receiver Manual de usuario

XFIRE AUDIO

XFIRE AUDIO BMW42S Manual de usuario

VDO

VDO CD 2253 Manual de usuario

Volvo

Volvo 13 84 580 Manual de usuario

ZENEC

ZENEC ZE-160DVD Manual de usuario
