Pulsar PSC12015 Manual de usuario

PSC12015

PSC 12V/1,5A/66MM power supply

v.2.0

Edition: 10 from 11.09.2023

Supersedes edition: 9 from 26.03.2020

Features of the power supply:

power output 1,5 A/12 V DC *

universal supply voltage range ~100-240 V

high efficiency 87%

standby power <0,1 W

efficiency level: VI

IP67 case

protections:

SCP short-circuit protection

overvoltage protection (AC input)

overload (OLP)

warranty –2 year from the production date

1. Technical description.

1.1.General description.

Stabilized DC power supply is intended for supply CCTV cameras that require stabilised voltage of 12 V DC.

The unit is protected against short-circuit and overload.

1.2.Technical parameters.

Supply voltage

~100-240 V; 50/60 Hz

Current consumption

0,4 A

Supply power

18 W max.

Efficiency (average)

87%

Efficiency (10% load)

82%

Output voltage

12 V DC

Output current tAMB<30°C

1,5 A instantaneous current - refer to graph 1.

Output current tAMB=40°C

1 A - refer to graph 1.

Ripple voltage

100 mV p-p max.

Short-circuit protection SCP

electronic, automatic recovery

Overload protection OLP

105-150% of power supply, automatic recovery

IP protection class

IP67

Operation conditions

temperature 0oC ÷40oC

relative humidity 20%...90%

Dimensions (LxWxH)

58 x 58 x 28 [mm]

Net/gross weight

0,16 / 0,19 [kg]

Protection class EN 62368-1

II (second)

Lenght of DC cable

0,5 m + plug DC5,5/2,1 female

Lenght of AC cable

0,3 m

Storage temperature

-20ºC...+60ºC

* In order to extend the life of the power supply, the load current of 1 A is recommended.

Graph 1.

Relation between output current and ambient

temperature (instantaneous load).

Fig.1. Dimensions of power supply.

*Refer to graph 1

1.3. Accessories.

For the power supplies are available accessories - fuse blocks and cable adapter. For details –visit www.pulsar.pl.

2. Installation.

2.1. Requirements.

The power supply shall be mounted by a qualified installer, holding relevant permits and licenses (applicable and

required for a given country) with ~230 V mains supply. Unit should be mounted in confined spaces with normal relative

humidity (RH=90% maximum, without condensing) and temperature from 0°C to +40°C.

In order to fulfill LVD and EMC requirements the rules for power supplies, encasing and shielding shall be observed

according to application.

2.2. Installation procedure.

1. Fit the power supply inside the box or other device.

2. Connect the DC output to the load or to the terminal block.

3. Connect the power supply to the AC line.

4. After tests and operation control are performed, close installation box, case etc. and switch on the power.

3. Maintenance.

Any and all maintenance operations may be performed following the disconnection of the power supply from the power

network. The power supply does not require any specific maintenance procedures, however, in the case of significant level of

dust, it should be cleaned with the compressed air.

WEEE LABEL

Waste electrical and electronic equipment must not be disposed of with normal household waste.

According to European Union WEEE Directive, waste electrical and electronic equipment should

be disposed of separately from normal household waste.

Pulsar sp. j.

Siedlec 150,

32-744 Łapczyca, Poland

Tel. (+48) 14-610-19-45

e-mail: [email protected]

http:// www.pulsar.pl
