Features
•Image Sensor
oPanasonic 1/2.7” HD CMOS sensor
oFull HD 1920x1080p resolution up to 60 frames per second (3G-SDI)
o2D & 3D noise reduction with our latest “low noise CMOS sensor”
o0.05 Lux @ F1.8 AGC ON
o60.7° Field of View
oDynamic Range Control (DRC) for higher image quality and detail across simultaneously well lit and
shadowed scenes
•Video Outputs
oSimultaneous IP network streaming and 3G-SDI output capabilities
oIP network streaming video output up to 30 frames per second
o3G-SDI High Definition video output up to 60 frames per second
oRTSP, RTMP, & RTMPS streaming using H.264, H.265, & MJPEG
oSupport for line level microphone encoding over IP network stream. Uses AAC audio encoding for better
sound quality and lower bandwidth usage.
•Control and Settings
oPTZOptics VISCA over IP
oRS485 remote camera control interface
oWeb-based IP remote control interface
oButton controls on back of camera
▪Press in the Menu Navigation button to open the On Screen Display (OSD) menu.
▪Press in the Menu Navigation button to select an option within the OSD menu.
▪Press up/down/left/right on the Menu Navigation to traverse the OSD menu.
▪Hold left on Menu Navigation button for 5+ to toggle between Dynamic and Static IP addressing.
•Installation
oStandard 1/4-20 female thread for camera mounting
oPower over Ethernet – Supports PoE 802.3af*
o12VDC 1A Power Supply provided for non-PoE infrastructure
•Warranty
o5-year warranty
*Note: For a high quality and reliable SDI signal we recommend utilizing the included PoE Splitter when powering via PoE
