Pts Diagnostics Pts connect Series Manual de usuario

Designed exclusively for use with CardioChek® Plus analyzers,

CardioChek PA analyzers (versions 2.55 and greater), and

PTS Connect Blu-Dock™ devices.

User Guide

Important Safety Instructions

Warning

1. Only use the AC adapter provided with this printer, or an AC adapter that has been

approved for use with this printer. Use of an incorrect AC adapter may cause risk of

overheating or fire.

2. Do not bend or place a heavy object on the power cord as it could damage the cord

and result in risk of electric shock or fire. Do not use the power cord if damaged or

frayed.

3. The thermal print head may become quite hot after printing. Be careful when

changing labels and cleaning the thermal head.

Caution

1. Never insert objects of any kind into this printer as they may touch dangerous

voltage points or short out parts, and may result in a risk of fire or electric shock.

Never spill liquid of any kind on the printer.

2. This printer contains no user-serviceable parts. Do not attempt to service the

printer yourself as this can expose you to dangerous voltage points or other risks.

Repair service should be performed by a trained technician.

3. Do not use this printer near water or in extreme humidity.

4. Be sure to hold only the connector end of the power cord or interface cable when

disconnecting. Repeated pulling on the cable could damage the cable.

5. If any of the following conditions occur, turn off the printer and unplug the power

cord from the power outlet:

- The power cord is damaged or frayed.

- Liquid has been spilled into the printer or the printer has been exposed to rain

or water.

- The printer does not recover from an error or the printer does not operate

normally when the operating instructions are followed.

- The printer exhibits a distinct change in performance, such as emitting a strange

noise, odor, or smoke.

6. Before using your printer, please remove the clear protective tape covering on the

engine cover and roll cover.

4 5

7. When the printer is unused for a period of time without a label, the platen

rubber may become stuck. This condition may cause a fatal error in the printer

mechanism. To avoid this, please keep a label loaded in the printer — even when

not in use.

8. Do not use the printer without closing the print engine cover.

Contents

Materials Provided

REF 2750 PTS Connect® Printer (1)

(PTS Connect Printer user guide included)

REF 2759 PTS Connect Printer Power Supply

(version included in box may very by territory)

REF 2151 PTS Connect Printer Label Roll

REF 2757 PTS Connect Printer USB Cable

(for use with CardioChek Plus analyzers only)

REF 2758 PTS Connect Printer Serial Cable

(for use with CardioChek PA and CardioChek Plus analyzers only)

Materials Needed but Not Provided

CardioChek PA or CardioChek Plus analyzers

Installation

For best performance, we recommend that you install your PTS Connect printer

on a at surface in a location that satises the following environmental conditions:

• Not subject to vibration

• Not exposed to direct sunlight

• Dust-free

• Condensation-free

• Temperatures: 59 to 95°F (15 to 35°C)

• Humidity: 30% RH to 80% RH (non-condensing)

Caring for Your Printer

Your printer is a high-precision device that’s designed for trouble-free operation.

Just follow these few precautions:

Note: The printer is designed for use with PTS Connect printer labels only.

Use of improper labels may damage the printer and void your warranty.

• Do not operate the printer in a dusty environment.

• Keep the printer out of direct sunlight.

• Turn the printer o when not in use.

• Pull the power plug out when the printer is not in use for a long time.

A Word About Labels

For best results, we recommend the use of PTS Connect printer labels. Other brands may

not be engineered to provide optimum, trouble-free results with your printer; therefore,

they may not work with your printer or they may damage it and void your warranty.

The printer labels have a sensor mark on

the backing of each label for top-of-label

alignment. Check to be sure the labels have

this mark before loading them into the printer.

Caring for Labels

The labels are sensitive to heat, moisture,

and light.With this in mind:

• Store labels in a cool, dry place.

• Do not scratch or rub labels with a hard

object.

• Do not expose labels to high heat or direct light for an extended period of time.

• Keep organic solvents away from labels.

Sensor Mark

6 7

CardioChek Plus Analyzer 1.05 and Higher

1. If the analyzer is off, press either button to turn on the analyzer.

Wait for the display to read INSTALL MEMO CHIP or INSERT STRIP.

Note: If RUN TEST is displayed, go to Step 3.

2. Ensure both power supply and communication cables are connected.

3. Press Next. The display will read RUN TEST.

4. Press Next until SETTINGS is displayed.

5. Press Enter, then Next until PRINT is displayed.

6. Press Enter. PRINT COPIES is displayed.

7. Press Enter. Press Enter to select the highlighted icon or press Next to highlight

one, two, or three copies.

8. Press Enter to accept and return to PRINT COPIES.

9. Press Next. TEST PRINTER is displayed. Press Enter for a sample printout.

Note: For CardioChek Plus analyzers 1.04 or older, please contact

PTS Diagnostics Customer Service.

How to Print Results from Memory

(CardioChek PA & CardioChek Plus analyzers)

1. If the analyzer is off, press either button to turn on the analyzer.

Wait for the display to read INSTALL MEMO CHIP or INSERT STRIP.

Note: If RUN TEST is displayed, go to Step 3.

2. Ensure both power supply and communication cables are connected.

3. Press Next. The display will read RUN TEST.

4. Press Next until MEMORY is displayed, then press Enter.

5. Press Enter to select CHEM or press Next, then Enter to select CONTROL.

6. Press Next to highlight the test name, then press Enter to select.

(LIPIDS for example)

7. Press Next to highlight the date/time of the test result you want to print.

8. Press Enter to print the selected results.

How to Set Up the CardioChek Analyzers for Printing

CardioChek PA Analyzer

1. If the analyzer is o, press either button to turn on the analyzer. Wait for the

display to read INSTALL MEMO CHIP or INSERT STRIP.

Note: If RUN TEST is displayed, go to Step 3.

2. Ensure both power supply and communication cables are connected.

3. Press Next. The display will read RUN TEST.

4. Press Next until SETTINGS is displayed.

5. Press Enter. PRINT is displayed.

6. Press Enter. PRINT MEDIA is displayed.

7. Press Enter to select LABEL, or Next then Enter to select PAPER and return to

PRINT MEDIA.

8. Press Next, then press Enter to display PRINT COPIES.

9. Press Next to display 01, 02, or 03 copies.

10. Press Enter to accept the desired number of copies and return to PRINT COPIES.

11. Press Next, then press Enter to display OUTPUT SELECT.

12. Press Next until PRINTER A is displayed.

13. Press Enter to select and return to OUTPUT SELECT.

14. Press Next. TEST PRINTER is displayed.

15. Press Enter for a sample printout.

Note: For CardioChek PA analyzers 2.56 or older, please contact

PTS Diagnostics Customer Service.

8 9

Changing a Label Roll

Warning: Do NOT throw spindle away when changing label rolls.

This procedure describes how to remove and replace label rolls.

• When you run out of labels, the green status light on the front of the printer ashes.

Removing the Old Roll

Caution: Do NOT pull on the labels to remove them from the printer.

This may cause labels to get stuck inside the printer.

1. Tear off any printed labels. If labels aren’t torn off, they may get jammed

when you perform step 2.

2. Press and hold the form feed button. The labels will reverse out of the printer.

If this does not work, see “Adjusting the Position of Labels” to release the platen to

remove the labels.

Adjusting the Position of Labels

If you nd the labels are advancing at an angle, follow these steps to realign them:

1. Swivel the label cover open and remove the print engine cover by pulling forward

on the edges at the top of the cover.

2. Release the pressure on the label stock

by moving the platen release lever

forward. When you let go of the platen

release lever, it goes back to the original

position. Hold the platen release lever

until the adjustment of the label position

completes.

3. Realign the label stock so it is straight.

4. Return the platen release lever.

5. Make sure the labels feed through the

paper inlet slot.

6. Replace the print engine cover, starting

at the bottom, and push the top edge

forward until the cover

snaps into place.

Platen lever

Loading a Roll of Labels

Prepare the roll of labels

1. Remove the sticker from the

beginning of the roll of labels.

Note: Make sure there is a black

sensor mark on the label backing.

2. If needed, cut between the labels

to create a “leader.”

3. If the end of the roll is not prepared as shown above,

cut between the labels leaving as much backing as possible.

Load the roll of labels

Warning: Do NOT throw spindle away when changing label rolls.

1. Make sure the power cord is connected

and the printer is turned on. The green

status light should be flashing.

2. Press the left and right side of the

label cover and lift up the edge of the

label cover to open.

3. Remove the spindle from the printer

and insert the label roll on the spindle.

4. Insert the labels and spindle into the printer.

If necessary, adjust the guides

to fit the labels as shown below.

5. Insert the free end of the label roll, label side

down, into the paper inlet slot. Push the label

stock into the paper inlet slot until you feel a

slight resistance. Continue pushing gently. The

printer automatically feeds the labels through

and aligns the end in the exit slot. If the label

end doesn’t appear through the slot: Press and

release the form feed button

to advance the labels.

6. Close the label cover.

Roll

Prepared End Cut here

Waste Roll

Label Guides

Label

Cover

Spindle

10 11

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on,

the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modications not expressly approved by PTS Diagnostics could void the

user’s authority to operate the equipment.

Applicable EC Directives and Standards

Directive Title

2014/30/EU EC Electromagnetic Compatibility Directive

2014/35/EU EC LowVoltage Directive

2009/125/EC Directive on Eco-Design of Energy-related Products

2011/65/EU Restriction of the use of certain hazardous substances

(RoHS) Directive

Standards

EMC EN55022 class B

EN61000-3-2, EN61000-3-3

EN55024

LVD EN60950-1

RoHS EN50581

Removing Stuck Labels

Caution: Do NOT touch print engine. It may be hot.

If a label becomes stuck in your printer, remove it as follows:

1. Make sure that the printer is turned off. If the Status Light is on, hold the Power

Button until the printer is turned off.

2. Swivel the Roll Cover open. With a pair of scissors, cut the label stock between the

label roll and the paper inlet slot.

3. Remove the Print Engine Cover by pulling it toward you while pressing the left and

right side of the Print Engine Cover.

4. Release the pressure on the label stock by moving the Platen Release Lever

forward. When you let go of the Platen Release Lever, it goes back to the original

position. Hold the Platen Release Lever until a label is removed.

5. Remove the stuck label.

6. Return the Platen Release Lever to the original position.

7. Replace the Print Engine Cover, starting at the bottom, and push the top edge

forward until the Print Engine Cover snaps into place.

12 13

Status Light Indicators

LED Indicator State

O Power o/Standby

Steady Green On-line

Steady Yellow O-line

Blinking Green 1* Paper out

Blinking Green 3* Cooling down

Blinking Yellow 1* Paper jam

Blinking Yellow 2* Buer overow

Blinking Red 1* Head temperature error

Blinking Red 2* Voltage error

Blinking Red 3* Head error

Blinking Red 5* Hard error

* The number refers to the number of blinks.

Symbols

Consult instructions for use

Caution

Manufacturer

Catalog number

Serial number

Keep dry

Product requires separate

collection for electrical and

electronic equipment per

the WEEE Directive

This product fullls the

requirements of European

Directive stated within this

document.

Specications

The PTS Connect printer is a compact printing device specically designed for label

printing with the CardioChek PA and CardioChek Plus analyzers.

Printer

Technology Direct thermal

Resolution 300 dpi (11.81 dots/mm)

Max. PaperWidth 2.28 in. (57.9 mm)

Max. PrintableWidth 1.92 in. (48.8 mm)

Print Speed 100 mm/sec max

Interface 650 USB

Operating voltage DC 11.4 V to DC 12.6 V

Current Consumption 2.8 A (Normal)

Current Consumption 3.0 A (Maximum)

Dimensions 4.48 in. (W) x 6.77 in. (D) x 5.83 in. (H)

113.8 mm (W) x 172.0 mm (D) x 148.0 mm (H)

Weight Approx. 1.08 lbs. (490 g)

Life Span 15 km

Environment

Temperature Operating: 41°F to 104°F (5°C to 40°C )

Storage: -4°F to 140°F (-20°C to 60°C)

Humidity Operating: 30% RH to 80% RH (non-condensing)

Storage: 30% RH to 90% RH (non-condensing)

14 15

Technical Support and Ordering Labels and Parts

For assistance, please contact PTS Diagnostics Customer Service

(M-F, 6 a.m.- 9 p.m. US EST) or your local authorized CardioChek dealer.

PTS Diagnostics

7736 Zionsville Road, Indianapolis, IN 46268 USA

Direct: +1-317-870-5610 ·Toll-free inside the US: 1-877-870-5610

Fax: +1-317-870-5608

Email: [email protected] ·Website: ptsdiagnostics.com

REF 2750 PTS Connect Printer

REF 2759 PTS Connect Printer Power Supply

(version included in box may very by territory)

REF 2151 PTS Connect Printer Label Roll

REF 2757 PTS Connect Printer USB Cable

(for use with CardioChek Plus analyzers only)

REF 2758 PTS Connect Printer Serial Cable

(for use with CardioChek PA and CardioChek Plus analyzers only)

CardioChek, MEMo Chip, and PTS Connect are trademarks of PolymerTechnology Systems, Inc.

All other trademarks and product names are the property of their respective owners.

PS-004527 EN Rev. 1 02/19

Polymer Technology Systems, Inc.

7736 Zionsville Road, Indianapolis, IN 46268 USA

Direct: +1-317-870-5610 ·Toll-free inside the US: 1-877-870-5610 ·Fax: +1-317-870-5608

Email: [email protected] ·Website: ptsdiagnostics.com

Tabla de contenidos

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario

pts Diagnostics pts connect Series Manual de usuario

Manuales populares de Impresora de otras marcas
