PSI Displays L101IP Manual de usuario

www.psidisplays.co.uk

TFT LCD MONITOR

USER MANUAL

HDVS IP Series (8 Channel versions)

Model No’s. L101IP, L121IP, L152IP,

L156IP, L172IP, L192IP, L215IP,

L240IP, L270IP, L320IP, L420IP,

L460IP.

TFT LCD Monitor with IP Input.

•1. Warning.........................................................................................................3

•2. Safety Precautions........................................................................................4

•3. LCD Monitor Mounting guide........................................................................6

•4. Monitor Controls .....................................................................................8

•5. Connections.................................................................................................10

•6. LCD OSD Function......................................................................................12

•7. PC Timing....................................................................................................13

•8. Features.......................................................................................................13

•9. Specification................................................................................................14

•10. Appendixes ... Troubleshooting for Display problem…………….…..….20

•11. IP Camera Device Side Setting …………………………………………….21

•12. HDVS IP Host Side Operation..................................................................22

•13. HDVS IP Display Setting ……..................................................................24

•14. HDVS IP Network Setting .........................................................................24

•15. NTP Setting .............................................................................................25

•16. Connect With IP Camera ……………………………….….…….………….25

•17. Drag to Change Channel Sequence …………………..….…….………….27

•18. Digital Zooming ………………………………….……………..…………….27

•19. System Device Setting ............................................................................28

•20. Channel Information …………………….…………………….….………….29

•21. Recording ……….....................................................................................30

•22. System HDD/e_SATA Setting ………………………….……..……………32

•23. Troubleshooting for IP Camera Problem …..……………..…………….33

1. WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT

TO RAIN OR MOISTURE.

DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.

CAUTION:

Explanation of Graphical Symbols

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended

to alert the user to the presence of uninsulated “dangerous voltage” within the product=s

enclosure that may be of sufficient magnitude to constitute a risk of electric

shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in the

literature accompanying the product.

Precautions

Safety--------------------------------------- Installation---------------------------------------

Should any liquid or solid object fall into the

cabinet, unplug the unit and have it checked

by the qualified personnel before operating it

any further.

Unplug the unit from the wall outlet if it is not

going to be used for several days or more.

To disconnect the cord, pull it out by the plug.

Never pull the cord itself.

Allow adequate air circulation to prevent

internal heat built-up. Do not place the unit on

surfaces (rugs, blankets, etc.) or near materials

(curtains, draperies) that may block the

ventilation holes.

Do not install the unit in an extremely hot or

humid place or in a place subject to excessive

dust or mechanical vibration.

The unit is not designed to be waterproof.

Exposure to rain or water may damage the unit.

Cleaning------------------------------------

Clean the unit with a slightly damp soft cloth.

Use a mild household detergent. Never use strong

solvents such as thinner or benzene as they might

damage the finish of the unit.

Retain the original carton and packing materials

for safe transport of this unit in the future.

2.Safety Precautions

Federal Communications Commission (FCC) Statement

This Equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

●You are cautioned that changes or modifications not expressly approved

by that party responsible for compliance could void your authority to

operate the equipment.

This device complies with Part 15 FCC Rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received including interference

that may cause undesired

About this user manual

This manual aims at assisting the user on how to operate the monitors described in this

manual.

This manual is subject to rigid quality control. However, no guarantee can be given that

mistakes are not present. We reserve the right to make changes to the manual without prior

notice.

Before operating the appliance, please read this manual carefully and retain it for further

reference. Verify that all appliance items are included in the delivery. Should items be

missing, do not operate the appliance and contact your local dealer.

Never attempt to repair the appliance yourself. This should only be done by qualified service

personnel.

Improper handling of the appliance will invalidate the warranty.

Package List

A. LCD IP input Monitor x 1

B. Power Cord x 1

C. User Manual x 1

D. 12V Power Adapter x 1 [Except for the 32”/42”/46”]

E. USB Mouse x 1

Revision History

Version

Date

Page

Description

V 1.0

2015/03/31

Initial (F/W: V4.0[20150124])

V1.1

2015/04/01

Change IP Monitor cover picture

Modify Stream type

V1.2

2016/01/21

Initial (F/W: V4.0[20150827])

Change IP Monitor cover picture

14,15,16

Modify Stream type

18, 25

Modify IP Channel Setting

V1.3

2016/04/13

14,15,16

18, 19,21

23,25

Modify Stream type

3.LCD Monitor Mounting Guide

A. Desktop

Adjust the viewing angle of LCD to fit most comfortable monitoring status.

B. Wall mount

Free your space with wall mount design.

Please follow the fix-hole size in back panel to install the LCD to the wall.

12.1”/15”/15.6”/17”

19”/21.5”/23.8”/27”

C. VESA Bracket 12.1”/15”/15.6”/17”/19”/21.5”/23.8”/27”

VESA Bracket: 32”

VESA Bracket: 42”/46”

4.Monitor Controls

12.1”/15”15.6”/17”/19”/21.5”/23.8”/27”10.1”

32”/42”/46”

Key Board

1. Power

Push to turn on and turn off the unit.

LED Green light: Power on

LED Red light: Standby mode.

2. / 3. Adjust UP /DOWN

UP: Used as UP function. Or Increase value on the OSD Menu.

And as a hot key for colour adjust function.

DOWN: Used as DOWN function. Or Decrease value on the OSD Menu.

And as a hot key for auto adjust function.

4. Item:

Hot key for OSD adjustments of Volume, Contrast, Brightness,

and Red, Green, Blue.

5. Menu

Push to call out OSD menu. Or Used

Confirm function in OSD Menu.

6. Source

Select input signal from D-SUB, HD, DVI, and IP.

KEY Lock Function:

Push “Menu” and “Item”, OSD of screen will show “Key Lock on”, Into key lock mode.

And push again, OSD of screen will show “Key Lock off “, into key unlock mode.

5.Connections: HDVS IP Series

12.1”/15”/15.6”/17”/19”/21.5”/23.8”/27”

2 3 4 5 6 7 8 9

1: e-SATA

2: RJ-45 (Ethernet Interface)

3: USB IN *2 (USB Mouse/Record Backup Connector)

4: DC 12V IN

5: DVI IN

6: Full HD IN

7: VGA IN

8: AUDIO R/L IN

9: Earphone OUT

10.1”

32”/42”/46”

23 4 5 6 7 8 9

1: e-SATA

2: RJ-45 (Ethernet Interface)

3: USB IN *2 (USB Mouse/Record Backup Connector)

4: DC 12V OUT

5: DVI IN

6: Full HD IN

7: VGA IN

8: AUDIO R/L IN

9: Earphone OUT
