ProRunner X1 Manual de usuario
X1 Walk treadmill Operating Instructions
Special tips:
A. Before installation and operation, please read this operation manual carefully.
B. Please save this manual for future reference.
C. Product may vary slightly from the item pictures due to model upgrade.
１
IMPORTANT SAFETY INSTRUCTIONS
Danger–To reduce the risk of electric shock disconnect your treadmill from the electrical
outlet prior to cleaning and/or service work.
DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE
GROUNDED PLUG BY USING IMPORPER ADAPTERS OR IN ANY WAY MODIFY THE
CORD SET.
1) Install the treadmill on a flat level surface with access to correct voltage and
frequency, grounded outlet.
2) Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both
carpet and treadmill may result.
3) Do not block the rear of the treadmill. Provide a minimum of 1 meter clearance
between the rear of the treadmill and any fixed object.
4) Place your unit on a solid, level surface when in use.
5) Never allow children on or near the treadmill.
6) When running, make sure the plastic clip is fastened on your clothing. It is for your
safety, should you fall or move too far back on the treadmill.
7) Keep hands away from all moving parts.
8) Never operate the treadmill if it has a damaged cord or plug.
9) Keep the cord away from heated surfaces.
10) Do not operate where aerosol spray products are being used or where oxygen is
being administered. Sparks from the motor may ignite a highly flammable
environment.
11) Never drop or insert any object into any openings.
12) The treadmill is intended for in-home use only and not suitable for long time
running.
13) To disconnect, turn all controls to the off position, remove the safety key, and then
remove the plug from the outlet.
14) The pulse sensors are not medical devices. Various factors, including the user’s
movement, may affect the accuracy of heart rate readings. The pulse sensors are
intended only as exercise aids in determining heart rate trends in general.
15) Use handrails provided; they are for your safety.
WARNING - Read all instructions before using this treadmill. It is important your
treadmill receives regular maintenance to prolong its useful life. Failing to
regularly maintain your treadmill may void your warranty.
２
16) Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable
for use on your treadmill. Quality athletic shoes are recommended to avoid leg
fatigue.
17) Allowed temperature: 5 to 40 degrees.
Remove the safety key after use to prevent unauthorized treadmill operation.
IMPORTANT ELECTRICAL INFORMATION
WARNING!
1) NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill.
Route the power cord away from any moving part of the treadmill including the
elevation mechanism and transport wheels.
2) NEVER operate treadmill on Generator or UPS power supply.
3) NEVER remove any cover without first disconnecting AC power.
4) NEVER expose this treadmill to rain or moisture. This treadmill is not designed for
use outdoors, near a pool, or in any other high humidity environment.
IMPORTANT OPERATION INSTRUCTIONS
1) Insert the power plug into the socket directly.
2) The constant running time is less than 2 hours. Be sure to read the entire manual
before operating your machine.
3) Understand that changes in speed and incline do not occur immediately. Set your
desired speed on the computer console and release the adjustment key. The
computer will obey the command gradually.
4) Use caution while participating in other activities while walking on your treadmill;
such as watching television, reading, etc. These distractions may cause you to
lose balance or stray from walking in the Centre of the belt; which may result in
serious injury.
5) In order to prevent losing balance and suffering unexpected injury, NEVER mount
or dismount the treadmill while the belt is moving. This unit starts with a very low
speed. Simply standing on the belt during slow acceleration is proper after you
have learned to operate this machine.
6) Always hold on to handrail while making control changes.
３
7) A safety key is provided with this machine. Remove the safety key will stop the
walking belt immediately; the treadmill will shut off automatically. Insert the safety
key will reset the display.
8) Do not use excessive pressure on console control keys. They are precision set to
function properly with little finger pressure.
9) This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety, Children should be
supervised to ensure that they do not play with the appliance.
10) Please consult your doctor at first before running, if you have one of the following
diseases:
a. Cardiopathy, hypertension, sugar diabetes, respiratory disease, smoking,
and other chronic diseases, complication disease.
b. If you are over 35 years old and heavier than common weight.
c.Women in pregnant or in breasting period.
11) Please stop exercising immediately and consult your doctor when you feel giddy,
surfeit, thorax ache or other symptoms.
12) Please drink adequate water after taking exercises on our treadmill for more than
20 minutes.
Warning: Now here we suggest that you should consult with your physician or health
professional before starting your workout, especially for the age up to 35 old or once-health
problem people. We take no responsible for any troubles or hurts if you don’t following our
specification. Treadmill will be carefully assembled and covered the motor shield, then
connect to the power.
４
No.
Description
Specification
Qty
A
Walking treadmill
1
B
Remote control
1
C
Power wire
1
D
Safety key
1
E
Wrench
1
F
Lubricant Oil
20ml/bottle
1
G
Manual
1
CARTON CONTENTS:
５
1.WALKING TREADMILL
①.WALKING BELT
②.DISPALY PANEL
③.SAFETY KEY HOLE
④.WHEEL
⑤.OVERLOAD PROTECTOR BUTTON
⑥.SQUARE SWITCH
⑦.POWER SOCKET
⑧.WHEEL
2.LED WINDOW DISPLAY:
Displays time, distance, calories, steps and speed value in turn every 5 seconds.
ROGRAMS
Initial
Default Value
Set Range
Display Range
TIME(MIN:SECOND)
0
-
-
0：00--59：59(MIN)
/1：00－18：00 (HOUR)
SPEED(KM/H)
0.0
0.8
0.8-6.0
0.8-6.0
DISTANCE(KM)
0
-
-
0.0--99.9
STEP
0
-
-
0-99999
CALORIE(KCAL)
0
-
-
0--9999
FUNCTION INSTRUCTIONS
Display time Display speed Display distance Display calories Display steps
６
3.REMOTE CONTROL FUNCTIONS:
Note: If the treadmill does not respond to the remote control, you will need to resync the treadmill
and remote control. To sync the remote control with the treadmill, press witch button to switch off
the treadmill first, then press switch button to switch on the treadmill, meanwhile hold on (Keep
pressing around 5 second ) START/PAUSE button before power on till you hear one "BI" sound from
treadmill that means the remove control was connected to treadmill successfully. then user could
start work out.
1.SPEED + BUTTONS: Press this button to increase the speed.
②.SPEED – BUTTONS: Press this button to decrease the speed.
③.DISPLAY SWITCH BUTTON: When in use,you can press this button to switch
the display between time, distance, calories, steps and speed value.
④.START/PAUSE BUTTON: Press this button to start or pause the machine.
⑤.STOP BUTTON: Press this button to stop the machine.
⑥.BATTERY COVER
NOTE: When attempting to get off of the treadmill but you do not press the Start/Pause
button, the treadmill will stop automatically within 10 seconds. If you want to continue
exercising, restart the treadmill.
LUBRICATION REMINDER
Your treadmill needs lubrication maintenance every 300 KM. The system will
release a beeping sound every 10 seconds and display an “OIL” icon on your
７
display to remind you when it’s time. Please read the LUBRICATING THE
TREADMILL on Page 12 to learn the proper steps to lubricating your machine.
Apply the lubricating oil to the middle of the running deck on both sides. After
application, press and hold the STOP button for 3 seconds to clear the reminder.
POWER SAVE FUNCTION:
When the treadmill has been idle for 10 minutes, it will enter Power Saving Mode.
While the treadmill is in this mode, the window display of the computer will be
turned off. To turn it back on, press any button.
POWER ON:
Flick the power switch to this symbol to turn on the treadmill.
POWER OFF:
Flick the power switch to this symbol to turn the treadmill off at anytime. This
includes during exercise.
８
OPERATING INSTRUCTIONS
９
PROBLEM
POSSIBLE CAUSE
SUGGESTED ACTION
Treadmill will not start
Not plugged in
Plug cord into outlet
Safety Key not inserted
Insert Safety Key
Running belt not
centered
Running belt tension not
correct on the left or right
sides of the running board
Tighten the adjustment bolts on
the left and right side of the rear
roller
Computer not
working
Wires from the computer
Check wire connections
and bottom control board not
properly connected.
from the computer to the control
board.
Transformer is damaged
If the transformer is damaged,
contact customer service.
0001 ERROR:
Message failure
Wires from the computer and
bottom control board not
properly connected.
Check wire connections from the
computer to the control board. If
the wire has been punctured or
damaged, you will need to
replace it. If the problem is not
rectified, you may need to
replace the control board.
0002 ERROR: Burst
clash protection
Incoming voltage is lower
than 50% of the required
voltage.
Check that the incoming power
supply is the correct voltage.
0005 ERROR:
Current overload
protection (Self
Protecting System)
The incoming voltage is too
low or too high. The control
board is damaged.
Restart the treadmill. Check the
incoming voltage to ensure it’s
correct. Check the control board,
replace if damaged.
TROUBLE SHOOTING
