USER MANUAL FOR

Contents

About Crystal/Nectar RO 2

Table of Chemical Constituent 3

Principle of Osmosis and Reverse Osmosis 4

Salient Features 5

How does Crystal/Nectar RO works 6

Installation and Usage 7

Problems, Check Points and Solutions 8

System Warranty 9

Technical Speciﬁcations 10

Warranty Card 11-12

Innovations

for happiness

The Table below gives an insight on how chemical impurities can impact your health

Total Hardness asCaCO3 200 Encrustation in water supplying

mg/L, max structure and adverse effects on

domestic use

Total dissolved solids 500 Beyond this palatability decreases

and may cause gastro intestinal

irritation

Iron (Fe) mg/L, max 0.3 Beyond this limit taste,

appearance are affected, has

adverse effect on domestic uses

and water supplying structures.

It also promotes iron bacteria

Chlorides (Cl) mg/L, max 250 Beyond this limit taste corrosion

and palatability are affected

Nitrate (NO3), mg/L, max 45 Beyond this methaemoglobinemia

takes place

Fluoride (F) mg/L, max 1 Fluoride should be kept as low as

possible. High luoride may cause

uorosis

Mercury (Hg) mg/L, max 0.001 Beyond this limit the water

becomes toxic

Arsenic (As) mg/L, max 0.01 Beyond this limit the water

becomes toxic

Lead (Pb) mg/L, max 0.01 Beyond this limit the water

becomes toxic

Chemical

Constituent

Requirement (Acceptable

limit)1510500-2012 Drinking

water speciﬁcation

Undesirable effect outside

the desirable limit

Table of Chemical Constituent

Congratulations and a warm welcome to the World of Propello Water

Puriﬁcation Systems.

The Crystal/Nectar RO is a result of our constant endeavor to provide

100% Pure and Healthy drinking water.

The Crystal/Nectar RO water puriﬁer uses Reverse Osmosis Technology

to remove all kinds of impurities, Chemicals and Micro-organisms. This

technology also removes the hardness of water. The Crystal Alkaline RO

helps to improve PH level.

The Crystal Alkaline puriﬁer uses Alkaline Cartridge to maintain the

necessary amount of minerals in the water .With the use of RO Technology

and other ﬁltration stages the Crystal Alkaline RO water puriﬁer ensures

that you get the purest drinking water.

On the other hand Nectar RO has Copper Cartridge which ensures the

goodness of copper, calcium and magnesium in water.

Here's wishing you and your family a happier and healthier life.

With Warm Regards,

Propello Family

• Suitable for mounting or counter-top installation.

• Puriﬁcation by RO and UV Technology.

• 10 litre storage tank capacity.

• External SMPS Adaptor for water protection

• RO membrane fused inside membrane housing to prevent tampering.

• Push-ﬁt components for leak-proof & maintenance free performance.

• Fully automatic operation with auto-on and auto-off.

• ABS construction for corrosion-free lifespan.

• Equally suitable for water from all sources

• Crystal/Nectar Reverse Osmosis System provides close to 100% removal of

almost all unwanted and harmful substances

• LPS prevents the pump from dry running in case the overhead tank is empty

• Automatic Water Level Sensor controls the water level automatically and shuts off

the pump when the storage tank is full

RO Technology

Unique RO Technology membrane removes excess TDS, blocks dissolved impurities and

chemical contaminants, while retaining essential minerals in the drinking water.

Alkaline Cartridge/Copper Cartridge:

• Make the water nutrient, by providing essential minerals.

• It provides healing effects and improves health immunity

• Enhance the taste of water.

• It balances the pH level of your drinking water.

• Helps to maintain Calcium & magnesium in the water besides enchancing copper ions.

• It helps in protecting the storage tank water from external bacterial contamination. .

Total Protection:

Eliminates tough new age contaminants like lead, pesticides and heavy metals from water.

It also ensures that water is free from disease-causing bacteria, virus and protozoa.

Large Storage Capacity:

It comes with a 10-litre in-built storage tank. Thereby ensuring puriﬁed water on tap, all the

time.

Salient Features

What is Osmosis?

In living cells movement of liquids takes place through

a semi-permeable membrane separating solutions of

different concentrations. Passage of water from weak

solution to through a semi permeable membrane is

called osmosis. Osmosis is a vital mechanism in the

transport of ﬂuids in living organisms, for example,

uptake of water from the earth and also transport of

water between cells in case of plants.

Principle of Osmosis and Reverse Osmosis

What is Reverse Osmosis?

Reverse Osmosis (RO) is when osmosis is reversed by

applying external pressure to the more concentrated

(polluted side). The water is forced through a synthetic

semi permeable membrane that allows only water

(H20) molecules. When pressure is applied to the

concentrated solution, the water passes through the

membrane and the rest is left behind, to be drained

out. In the Reverse Osmosis System, water is pushed

under high pressure through a very ﬁne membrane of

pore size 0.0001 micron. So the water that comes

through the membrane ﬁlter is free from total dissolved

solids, hardness, micro-organisms, chemicals, other

metal contaminants, particles and VOC.

The 8 stages Crystal/Nectar RO are as follows:

Stage Component Function

1 Iron ﬁlter Helps in remove dissolved iron from water

2 Pre-ﬁlter yarn removes suspended impurities likr dirt mud,

polypropylene rust, sand etc.

3 Pre-carbon Filter Silver Removes excess chlorine, bad odour, colour,

impregnated Activated bad taste and organic impurities

Carbon

4 Sediment Filter Melt Removes ﬁne particles such asdirt, dust,

blown Yarn mud and sand

polypropylene

5 Reverse Osmosis Membrane Removes TDS, hardness, luoride,

Thin Film Composite (TFC) pesticides, VOC, heavy metals like lead,

0.0001 micron mercury, cadmium & Arsenic etc.

Removes micro-organisms like bacteria,

viruses and protozoan cysts.

6 Alkaline Cartridge/ • Make the water nutrient, by providing

Copper Cartridge essential minerals.

• It provides healing effects and improves

health immunity.

• Enhance the taste of water.

• It balances the pH level and copper ions

of your drinking water.

• It helps in protecting the storage tank

water from external bacterial

contamination.

7 UF Keeps the water sparkling clean

8 TDS Controller Helps to maintain TDS of output water

How does Crystal/Nectar RO works

Can be used for:

Watering plants.

Cannot be used for:

Cleaning utensils, daily household cleaning, washing clothes and drinking

purpose

Check points before calling our Service Department

Before you panic and call our service department, here are some simple

steps to be followed. Most times you’ll ﬁnd that one or a combination of

these will solve the problem/s. When these steps at your end fail then

immediately call our helpline/service department and we will take up your

case on priority.

Thank You.

Installation and Usage

Install it in a dry ventilated place

• Keep it away from direct sunlight or below freezing temperatures.

Connect it only to cold tap water.

• Filters can be damaged if connected to hot tap water.

• Make sure that the tap water pressure is max. 2.0 kg/cm2. If the tap

water pressure you receive is higher than the maximum speciﬁed, the

use of a pressure reducing valve is recommended. The above

accessory is available with our company at an additional cost.

• If not, water might fow back into the puriﬁer.

• Make sure that the puriﬁer is installed within the distance of 1m (max)

from the tap water supply.

• This puriﬁers for 230V only so make sure that you connect to a 230V

power outlet.

• Do not install the puriﬁer in a place where rainwater could leak into it

(Outdoor etc.).

Water is a rapidly depleting source. It is our moral responsibility to

ensure that water is recycled as much as possible.

The water fushed :

Problem Check Points Solutions

Water tastes bad 1. Is the storage tank clean? If not then dispose off the tank water

and clean the tank

2. Have you kept the puriﬁed If yes, then dispose off water

water in the tank too long? and clean the tank.

3. Is it time to change ﬁlters? Call our service department to

change ﬁlters.

Too much or too little water 1. Is the tap water valve closed? Open the tap water valve.

is being puriﬁed 2. Is the tap water temperature too low? If so, the amount of puriﬁed

water will be reduced.

3. Filters may be clogged or damaged. Call our service department and

change ﬁlters.

4. Pump or SV has failed. Call Service department to

rectify/change

Water doesn't come out. 1. Is there water in the tank? Check the storage tank.

If tap water is not supplied,

2. Is tap water supplied? close the tap water valve.

3. Is the tap water valve closed? Open the tap water valve.

4. Not sure what is wrong. Call our service department.

Water is leaking 1. Is water coming out of the After checking the inside of the

top cover or the puriﬁer? product, close the tap water valve,

unplug the power cord and call our

service department.

Problems, Check Points and Solutions

Warranty is the responsibility of the company.

This product is warranted for one year from the date of sale against all defects except

plastic components, rubber and their assembly there of. In the event of any complaint,

please contact your dealer or the nearest company service center.

Toll free number 1800 121 0600

This warranty is valid only when...

• The application has not been opened or tampered with, by any unauthorized person.

• The unit is brought to and taken from the service center at the customer's cost and risk.

• The guarantee card or cash memo duly signed by the authorised dealer are presented

with the complaint.

• The application has been installed, used and maintained in accordance with the

instruction manual

This warranty does not apply for...

• Damage due to chipping peeling, plating, and denting.

• Breakage or damage to components of Bakelite, urea, ABS, SAN and such plastic

material, rubber parts and cord.

• The items that are subject to normal wear and tear due to operations.

• Damage resulting from accidents, mishandling or negligence on part of customer.

System Warranty

MODEL NAME

PURIFYING TECHNOLOGY

APPLICABLE TDS RANGE IN INPUT WATER

INSTALLATION TYPE

PURIFIED WATER FLOW RATE

STORAGE TANK CAPACITY

TDS REDUCTION

% WATER RECOVERY

NET WEIGHT

OPERATING INPUT

RO MEMBRANE

MEMBRANE TYPE

BOOSTER PUMP VOLTAGE

INPUT WATER TEMPERATURE

INPUT WATER CHLORINE

INPUT WATER IRON

INPUT WATER TURBIDITY

CRYSTAL

REVERSE OSMOSIS (RO)

WITH ALKALINE ENRICH

TECHNOLOGY

UPTO 1500 mg/L

TABLE TOP AND

WALL MOUNTING

10 L/hr

10 LITERS (approx)

90% (approx)

27% (approx.)

9 KGS (approx)

VOLTAGE 230V AC/50HZ

75 GPD

THIN FILM COMPOSITE RO

24V DC

5 DEGREE C –45 DEGREE C

0.2 mg/L (max)

0.3 mg/L (max)

15 NTU (max)

NECTAR

REVERSE OSMOSIS (RO)

WITH COPPER ION

TECHNOLOGY

UPTO 1500 mg/L

TABLE TOP AND

WALL MOUNTING

10 L/hr

10 LITERS (approx)

90% (approx)

27% (approx.)

9 KGS (approx)

VOLTAGE 230V AC/50HZ

75 GPD

THIN FILM COMPOSITE RO

24V DC

5 DEGREE C –45 DEGREE C

0.2 mg/L (max)

0.3 mg/L (max)

15 NTU (max)

Note:

* Technical Speciﬁcations are subject to change without prior notice.

* Flow rate and other parameters depend on the input water pressure and condition of the ﬁlters.

Technical Speciﬁcations

WARRANTY CARD

Name of Customer:

Contact No: (R) (M)

Postal Address:

Date of invoice: Date of installation:

Model No: Unit No:

Membrane No: Pump No:

Dealer Stamp & Sign:

Signature of sales person Customer signature

Dear Customer,

Congratulations! You have become a proud owner of Propello Water Puriﬁer, the model mentioned

below is covered under warranty against all manufacturing defects for a period of 12 months from the

date of purchases subject to the conditions mentioned overleaf.

Model:

SI No.:

Bill No.:

Purchasing Dealer's Name with signature & seal:

Warranty Terms & Conditions

The goods are warranted against all manufacturing defects for a period of 12 months from the date of

purchase subject to the following conditions:

A. The warranty does not cover items that are subject to normal wear and tear due to operations.

B. Defective puriﬁer with valid warranty card and original bill to be produced to the authorized service

franchise or service dealer by the customer's own cost during working hours.

C. This warranty does not cover defects as result of accident/ damage due to transit or misuse.

D. This warranty is not applicable if the damage is a result of attractions, unauthorized repairs,

tampering or alteration of any part, unauthorized installation or damages caused as a result of natural

calamity, riots or any unnatural circumstances.

E. Consumable items will not be covered under warranty.

F. This warranty is valid only when it bears the signature and stamp of the authorized dealer.

G. The defective item or component will be replaced / repaired at the sole discretion of Propello

Innovations Pvt. Ltd. And the replaced parts will be the property of Propello Innovations Pvt. Ltd.

H. This product is intended for domestic use and not for commercial use. The puriﬁed water is intended

for drinking purpose only and any other use such as bathing, washing etc. will lead to cancellation of

warranty.

I. All disputes are subject to Kolkata jurisdiction.

J. The machine has a limited purifying capacity designed only for drinking purposes the warranty will not

to be valid puriﬁed water used for other purposes.

Customer's Signature

WARRANTY CARD

Welcome to

Propello family

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Sistema de filtración de agua de otras marcas

Wisy

Wisy LineAir 100 Manual de usuario

Schaffner

Schaffner Ecosine FN3446 Series Manual de funcionamiento

Pentair

Pentair FLECK 4600 SXT Guía del usuario

H2O International

H2O International H20-500 Manual de usuario

Renkforce

Renkforce 2306241 Manual de usuario

Neo-Pure

Neo-Pure TL3-A502 Manual de usuario

FLTR

FLTR OBF Manual de usuario

STA-RITE

STA-RITE VERTICAL GRID DE FILTERS S7D75 Manual de usuario

Applied Membranes

Applied Membranes W-G844EM Manual de usuario

BEGA

BEGA 116 Manual de usuario

WATA

WATA Standard Manual de usuario

Price

Price FFU series Manual

Gaggenau

Gaggenau BRITA INTENZA 467873 Manual de usuario

Brita

Brita SAFF-100 Manual de usuario

HEISSNER

HEISSNER FPU24000-00 Manual de usuario

BGS technic

BGS technic 1518 Manual de usuario

Reverse Osmosis

Reverse Osmosis RF Series Manual de usuario

ubbink

ubbink Filtramax Series Manual de usuario
