USER MANUAL
MK FIVE
April 2020
Tabel of contents
Introduction ...................................................................................................................... 4
Product description .................................................................................................... 4
How to get started ...................................................................................................... 5
Display – LCD Mini Display w/buttons ........................................................ 6
Display .................................................................................................................................. 6
Turn display on and o ............................................................................................. 6
Light ....................................................................................................................................... 7
Battery indicator ............................................................................................................ 7
Assist functions .............................................................................................................. 8
Trip counter/Odometer ........................................................................................... 9
Troubleshooting ............................................................................................................ 10
Battery - mounting/dismounting .................................................................... 11
Charger/Charging ....................................................................................................... 12
Canopy/Mounting canopy .................................................................................... 13
Storage ................................................................................................................................. 18
Capacity and use .......................................................................................................... 18
Warning ............................................................................................................................... 18
Disposal of battery ...................................................................................................... 19
Battery registration ..................................................................................................... 19
Maintenance .................................................................................................................... 20
Transportation of electric bike ........................................................................... 20
Road trac law ............................................................................................................... 21
Insurance ............................................................................................................................ 21
Frame No. ........................................................................................................................... 21
Technical data ................................................................................................................. 22
Battery specications ................................................................................................ 23
4
Introduction
Congratulations with your new 3-wheeler Ridgeback MK FIVE e-bike.
The new generation of e-bikes are designed and developed based on many
years of experience in the e-bike area.
Before you start using the e-bike, please read this manual, as it contains some
important information concerning the use and maintenance of an e-bike.
Ridgeback MK FIVE e-bike is manufactured according to the most advanced
production technology. Through tests and test driving a high quality standard is
ensured.
Ridgeback MK FIVE has a strong frame and great performance and is adapted to
the Nordic weather conditions.
You will achieve an easier and more fun way to transport yourself.
Product description
Your bike is produced according to the guidelines in European standard:
Machinery directive 2006/42/EC and the electric components according to
EN 15194:2017 EPAC Bicycles.
Ridgeback MK FIVE is the perfect choice if you want an electric bike that can be
used for transportation of children, dogs or luggage. The bike is equipped with to
seats and four seatbelts. It is possible to cover the cargobox with the canopy.
The frame is produced in aluminum, which provides a sti and robust construction
and its low weight is maintained. The motor is integrated in the rear wheel and the
battery is integrated under the carrier.
In that way the weight distribution is optimal. The electrical bicycle can also function
as a regular bike.
5
How to get started
When the battery is installed, the system can be powered on by using the on/o
button on the display. When using the pedals, the engine will start to assist you,
depending on the chosen assist level. The engine operates as follows:
Electronic controller applies the assist when the sensor detects a movement on
the pedals.
The assist power can be controlled by pre xed assist levels and can be used to
adjust to current needs.
Driving uphill gives you the full ability to use the assist function and can be turned
o when driving downhill.
The controls automatically disonnects the engine, when there isn't any movement
on the pedals or when the speed exceeds 25km/h.
For further details see the "Functions" on the next page.
To ride the bike it is necessary to be aware of how the weight is distributed. Make
sure of the control of the bike when you make turns.
Info
* Place the weight in the box as close to the handlebare as possible to increase the
stability of the bike.
* The bike does not turn like a normal bike.
* Gear down when driving in hilly terrain.
* The battery must be fully charged before each drive.
* Avoid maneuvering at high speed.
* The tires must be suciently pumped.
6
Display - LCD Mini Display with buttons
Display
Turn display on and o
The display is turned on and o by pressing the on/o button for 2 seconds.
The display is mounted on the handlebar and function both as battery indicator and
assist level function. Use the 3 buttons on left side to navigate.
Battery indicator
Level down
On/O
Level up
Speed
Trip counter
Assist level
On/O
7
Battery indicator
The battery indicator is shown on the left side of the display and allows you
to see the approximate battery level using 4 segments.
When reaching the lowest level, it will start ashing.
Please note that the battery level may vary depending on whether you
drive uphill or downhill.
Battery indicator
Light
Turn on/o the light by pressing the "level up" button for 1-2 seconds.
Level up
8
Trip counter / Odometer
This display can change between trip counter and odometer (total distance):
Change between trip counter and odometer by pressing the "power button"
shortly. The odometer cannot be reset.
Resetting the trip counter:
Keep "On/O" and "Level down" pressed simultaneously for 2-3 seconds.
Level down
On/O
Trip counter
9
Assist functions
The display has 2 dierent assist functions:
* Assist levels (1-4) - selectable by using the "level up" and "level down" buttons.
Level 4: Highest level
Level 1: Lowest level
Level 0: Assist function disabled
* Walk assist:
If the bike support this, it is activated by holding down the "level down" button.
Using the walk assist function allows you to drive the bike up to 6 km/h
without the use of the pedals and regardless of the assist level setting.
This function is useful when pushing the bike uphill.
Level down/
walk assist
Level up
Assist level
10
Error codes Description Possible solution
E02Indicates errors in power consumption Contact your dealer
E03Indicates errors in the controller Contact your dealer
E04Indicates errors in the display Contact your dealer
E05Indicates errors in the brake sensor Contact your dealer
E07Indicates error in the wheel speed sensor Contact your dealer
E08Low battery voltage Charge the battery
E09Overvoltage Contact your dealer
The error indicator has the following error codes
Troubleshooting
An error code appears on the display in case of any system errors.
The error is indicated by a number, which will be displayed.
Error codes from E02to E09 indicate the type of error. The nal diagnosis
of errors requires professionals. Contact your dealer for assistance.
Error code
