ProMinent® DULCO®flex

DF2a

Assembly and operating instructions

A1666

Original Operating Instructions (2006/42/EC)Part number 984881 BA DX 024 12/16 EN

Please carefully read these operating instructions before use. · Do not discard.

The operator shall be liable for any damage caused by installation or operating errors.

The latest version of the operating instructions are available on our homepage.

General non-discriminatory approach In order to make it easier to read, this

document uses the male form in

grammatical structures but with an

implied neutral sense. It is aimed

equally at both men and women. We

kindly ask female readers for their

understanding in this simplification of

the text.

Supplementary information

Please read the supplementary information in its entirety.

Information

This provides important information relating to the correct operation of the

unit or is intended to make your work easier.

Warning information

Warning information includes detailed descriptions of the hazardous situation,

see

Ä Chapter 2.1 „Labelling of Warning Information“ on page 8

The following symbols are used to highlight instructions, links, lists, results and

other elements in this document:

More symbols

Symbol Description

Action, step by step.

⇨Outcome of an action.

Links to elements or sections of these instructions or other

applicable documents.

nList without set order.

Supplemental directives

Symbol Description

[Button]

Display element (e.g. indicators).

Operating element (e.g. button, switch).

„Display /

GUI“

Screen elements (e.g. buttons, assignment of function keys).

CODE Presentation of software elements and/or texts.

Supplemental directives

Table of contents

1 About This Pump....................................................................................... 5

2 Safety and Responsibility.......................................................................... 8

2.1 Labelling of Warning Information....................................................... 8

2.2 Safety notes....................................................................................... 9

2.3 Intended use.................................................................................... 11

2.4 Users' qualifications......................................................................... 12

3 Storage and Transport............................................................................. 14

4 Overview of equipment / Functional description...................................... 15

5 Assembly and Installation........................................................................ 16

5.1 Assembling the peristaltic pump...................................................... 16

5.2 Installing hose lines......................................................................... 18

5.3 Electrical installation of the peristaltic pump.................................... 19

6 Start up.................................................................................................... 22

7 Maintenance, repair and faults ............................................................... 23

7.1 Maintenance.................................................................................... 23

7.2 Repair.............................................................................................. 24

7.3 Troubleshooting............................................................................... 25

8 Decommissioning and Disposal............................................................... 26

8.1 Disposal of Used Parts.................................................................... 27

9 Technical data......................................................................................... 28

9.1 Accessories and spare parts........................................................... 32

9.2 Dimension sheet.............................................................................. 33

10 EU Declaration of Conformity for Machinery........................................... 34

11 Index........................................................................................................ 35

Table of contents

1 About This Pump

The ProMinent® DULCO®flex peri‐

staltic pump is designed for use in

swimming pools, hot tubs, and spas

and wellness zones.

About This Pump

Identity Code

DULCO®flex, Version DF2a

Pump type:

1.5 bar; 0.4 litres/h, 5 1/min

1.5 bar; 0.8 litres/h, 10 1/min

1.5 bar; 1.6 litres/h, 20 1/min

1.5 bar; 2.4 litres/h, 30 1/min

Hose material:

PPharMed®, 4,8 x 8 mm

VViton®, 4,8 x 8,1 mm , for fragrances (custom design)

Design:

0With ProMinent® logo

1Without ProMinent® logo

P Pool design

Hydraulic connector:

0 Standard, 6 x 4, suction and discharge side

9 Special connector, 10 x 4, discharge side

Electrical connection:

A 230 V, 50/60 Hz

Cable and plug:

0 without cable

1 with cable, 2.0 m, open end

About This Pump

DULCO®flex, Version DF2a

4 with cable, 0.8 m, open end

A with cable, 2.0 m, European plug (EN

50075)

Control:

0 Mains power supply ON/OFF

Mounting type:

W Wall-mounting

Accessories:

0 without accessories

1 with foot valve 1/4", lipped

injection valve, 2 m suction

line, 5 m discharge line

About This Pump

2 Safety and Responsibility

2.1 Labelling of Warning Infor‐

mation

Introduction

These operating instructions provide

information on the technical data and

functions of the product. These oper‐

ating instructions provide detailed

warning information and are provided

as clear step-by-step instructions.

The warning information and notes

are categorised according to the fol‐

lowing scheme. A number of different

symbols are used to denote different

situations. The symbols shown here

serve only as examples.

DANGER!

Nature and source of the

danger

Consequence: Fatal or very

serious injuries.

Measure to be taken to avoid

this danger.

Description of hazard

– Denotes an immediate

threatening danger. If the

situation is disregarded, it

will result in fatal or very

serious injuries.

WARNING!

Nature and source of the

danger

Possible consequence: Fatal or

very serious injuries.

Measure to be taken to avoid

this danger.

– Denotes a possibly haz‐

ardous situation. If the sit‐

uation is disregarded, it

could result in fatal or very

serious injuries.

CAUTION!

Nature and source of the

danger

Possible consequence: Slight

or minor injuries. Material

damage.

Measure to be taken to avoid

this danger.

– Denotes a possibly haz‐

ardous situation. If the sit‐

uation is disregarded, it

could result in slight or

minor injuries. May also be

used as a warning about

material damage.

Safety and Responsibility

NOTICE!

Nature and source of the

danger

Damage to the product or its

surroundings.

Measure to be taken to avoid

this danger.

– Denotes a possibly dam‐

aging situation. If the situa‐

tion is disregarded, the

product or an object in its

vicinity could be damaged.

Type of information

Hints on use and additional

information.

Source of the information. Addi‐

tional measures.

–

Denotes hints on use and

other useful information. It

does not indicate a haz‐

ardous or damaging situa‐

tion.

2.2 Safety notes

WARNING!

Danger from hazardous sub‐

stances!

Possible consequence: Fatal or

very serious injuries.

Please ensure when handling

hazardous substances that you

have read the latest safety data

sheets provided by the manu‐

facture of the hazardous sub‐

stance. The actions required

are described in the safety data

sheet. Check the safety data

sheet regularly and replace, if

necessary, as the hazard

potential of a substance can be

re-evaluated at any time based

on new findings.

The system operator is respon‐

sible for ensuring that these

safety data sheets are available

and that they are kept up to

date, as well as for producing

an associated hazard assess‐

ment for the workstations

affected.

Safety and Responsibility

WARNING!

Danger of electric shock

Mains voltage may be present

inside the pump housing.

Immediately disconnect the

pump from the mains power

supply if the pump housing has

been damaged. Only return the

pump to service after an

authorised repair.

CAUTION!

Warning of feed chemical

spraying around

The metering pump can gen‐

erate a multiple of its rated

pressure. Hydraulic parts may

burst if a discharge line is

blocked. -

Correctly install a relief valve in

the discharge line downstream

of the metering pump.

CAUTION!

Warning of backflow

Metering pumps are not abso‐

lutely leak-tight shut-off

devices.

Use a shut-off valve, a solenoid

valve or a vacuum breaker for

this purpose.

CAUTION!

Personnel injury and material

damage

The pump can start to pump,

as soon as it is connected to

mains voltage.

Install an emergency cut-off

switch in the pump power

supply line or integrate the

pump in the emergency cut-off

management of the system.

CAUTION!

Device starts immediately

The unit does not have an

On/Of switch and begins to

work as soon as it is connected

to the mains voltage.

Only connect the device to the

mains voltage when all installa‐

tion work has been completed

and the pumped chemicals can

no longer escape in an uncon‐

trolled manner.

CAUTION!

Contact with chemicals

De-pressurise, drain and rinse

the hydraulic part of the unit

before working on it.

Safety and Responsibility
