Promag UHF860 Manual de usuario

UHF860 Reader User Guide

TM970180 - 01

October 11, 2013

UHF860 Reader User Guide

Table of Contents

Safety Certification

Introduction

Part I Installation 6

.......................................................................................................................................... 61 Package Contents

.......................................................................................................................................... 72 Hardware Installation

................................................................................................................................................................................. 7Reader

...................................................................................................................................................................... 9Connecting through USB232B Converter

...................................................................................................................................................................... 15Connecting through Wiegand

................................................................................................................................................................................. 17Antenna

...................................................................................................................................................................... 18Antenna & Accessories

...................................................................................................................................................................... 21Antenna Portal

.......................................................................................................................................... 223 Software Installation

.......................................................................................................................................... 234 Configuration

................................................................................................................................................................................. 25Device Setting

...................................................................................................................................................................... 25Basic

...................................................................................................................................................................... 27Advance

...................................................................................................................................................................... 29Save/Load Settings

................................................................................................................................................................................. 30Environment Tuning

...................................................................................................................................................................... 30Reflect Pow er

................................................................................................................................................................. 30Sw eep

................................................................................................................................................................. 32Scan

...................................................................................................................................................................... 33Pow er/Sensitivity Auto Tune

................................................................................................................................................................................. 35Tagging

...................................................................................................................................................................... 35Read/Write Memory Bank Data

...................................................................................................................................................................... 36Labeling

...................................................................................................................................................................... 39Reading

................................................................................................................................................................................. 41I/O Testing

................................................................................................................................................................................. 42Live Demo Setting

Part II Operation 45

Part III Appendix 47

.......................................................................................................................................... 471 A. Tag Memory Glossary

.......................................................................................................................................... 502 B. Antenna Specifications

.......................................................................................................................................... 513 C. UHF Reader Specifications

.......................................................................................................................................... 524 D. Reader LED statusIndication

Part IV FAQ 54

Introduction to UHF860 Reader

A 4-port Ultra High Frequency RFID Reader

UHF860 Reader is a compact RFID reader with ports to connect

four antennas and has a reading range of 5 mtrs.

The reader is ideal for inventory control, cargo tracking, warehouse

management, shop floor management, class management and

other applications.

A utility software is supplied with the reader for configuration and

demo operations.

This guide is for easy installation, configuration and demo

operation of the UHF860 Reader.

UHF860 Reader User Guide 2

Introduction

mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written

permission of the publisher.

Products that are referred to in this document may be either trademarks and/or registered trademarks of the respective

owners. The publisher and the author make no claim to these trademarks.

While every precaution has been taken in the preparation of this document, the publisher and the author assume no

responsibilityfor errors or omissions, or for damages resulting from the use of information contained in this document or

from the use of programs and source code that may accompany it. In no event shall the publisher and the author be liable

for any loss of profit or any other commercial damage caused or alleged to have been caused directly or indirectly by this

document.

Published: October 2013 in Taiwan

UHF860 Reader User Guide 3

UHF860 Reader User Guide 4

Safety Certifications

Has been tested in accordance to essential protection requirements of the R&TTE Directive 1999/5/EC on the

approximation of the laws of the Member States relating to Radio Spectrum Matters and found the test results

indeed meet the limitation of the relevant test standard(s) listed below:

EMC

EN 301 489 - 1: V1.8.1 (2008)

EN 301 489 - 3: V1.4.1 (2002)

Radio Spectrum

EN 302 208 - 2: V1.3.1 : 2010

EN 302 208 - 1: V1.3.1 : 2010

Safety

EN 60950 - 1: 2006+A11 : 2009+A1 : 2010

Test standard: FCC rules Part 15 subpart C 15.247 (2011 - 10)

Test Result: No deviations from the technical specification(s) were ascertained in the course of the tests performed.

Test standard: FCC rules Part 15 subpart B

Test Result: Radiated Emission. FCC Part 15. 109 Class B. Test passed.

Part I

UHF860 Reader User Guide 6

Installation

1Installation

This part of the user guide contains description of

- package contents

- hardware installation

- software installation and

- configuration

1.1 Package Contents

UHF860 Reader standard package:

NO.

ITEM

QUANTITY

UHF860 Reader

Pack of fasteners

1 set

CD Disk No. 5460 containing

software and user guide

Optional items:

ITEM

PART NUMBER

UHF Antenna European Standard

ANT800-EU

UHF Antenna American Standard

ANT800-US

Antenna Cable for ANT800 - EU

WAS-T0681-R

Antenna Cable for ANT800 - US

WAS-T0691-R

Antenna Bracket

Please contact sales for further

information

UHF Tag/Card

Please contact sales for further

information

RS232 to USB Converter

USB232B

RS485 to USB Converter

USB485A

Configure Kit

MF700KIT

9V DC 1.7 A 100~240 AC power

adapter

APR-T0022

UHF860 Reader User Guide 7

Installation

1.2 Hardware Installation

1.2.1 Reader

1. The reader has 4 coaxial connectors (with red safety caps) for 4 antennas. Please refer the diagram

below for channel numbers of the ports.

UHF860 Reader User Guide 8

Installation

Antenna channel port indication

14 pin terminal 3.5mm - SMA type connectors

2. The rear side of the reader has a green terminal board with 14 data input/output terminals of 3.5mm

size.

I/O Connection to PC

UHF860 Reader User Guide 9

Installation

1.2.1.1 Connecting through USB232B Converter

Wiring diagram for connecting the reader to computer through USB232B converter

1. If your computer has an RS232 comport use an RS232 cable to connect to the computer. If not use a

USB232B converter. GIGA-TMS provides MF700KIT as an optional item to conveniently connect the

reader to the converter. The picture below illustrates how the kit connects the reader to the converter.

The steps for the connections are given below.

2. Connect TX and RXterminals of the reader to TX and Rx terminals of MF700KIT.
