Progress PVS1550 Manual de usuario
PVS1550
User Manual
Notice d'utilisation
Benutzerinformation
Dishwasher
Lave-vaisselle
Geschirrspüler
CONTENTS
Safety information 2
Safety instructions 3
Product description 5
Control panel 5
Programmes 6
Settings 7
Options 9
Before first use 9
Daily use 10
Hints and tips 12
Care and cleaning 13
Troubleshooting 15
Technical information 18
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damages that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Do not let children play with the appliance.
•Keep detergents away from children.
•Keep children and pets away from the appliance door when
it is open.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
General Safety
•This appliance is intended to be used in household and
similar applications such as:
–farm houses; staff kitchen areas in shops, offices and
other working environments;
2 Progress
–by clients in hotels, motels, bed & breakfast and other
residential type environments.
•Do not change the specification of this appliance.
•The operating water pressure (minimum and maximum)
must be between 0.5 (0.05) / 8 (0.8) bar (MPa)
•Obey the maximum number of 9 place settings.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
•Put the cutlery in the cutlery basket with the sharp ends
pointing down or put them in the cutlery drawer in a
horizontal position with the sharp edges down.
•Do not leave the appliance with the open door unattended
to avoid stepping accidentally onto it.
•Before any maintenance operation, deactivate the appliance
and disconnect the mains plug from the socket.
•Do not use high pressure water sprays and/or steam to
clean the appliance.
•If the appliance has ventilation openings in the base, they
must not be covered e.g. by a carpet.
•The appliance is to be connected to the water mains using
the new supplied hose-sets. Old hose sets must not be
reused.
SAFETY INSTRUCTIONS
Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance where
the temperature is less than 0 °C.
• Follow the installation instruction
supplied with the appliance.
• Make sure that the appliance is installed
below and adjacent to safe structures.
Electrical connection
WARNING! Risk of fire and
electrical shock.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by our
Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the installation.
Progress 3
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance complies with the E.E.C.
Directives.
• Only for UK and Ireland. The appliance
has a 13 amp mains plug. If it is
necessary to change the fuse in the
mains plug, use fuse: 13 amp ASTA (BS
1362).
Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let the
water flow until it is clean and clear.
• Ensure that there are no visible water
leaks during and after the first use of the
appliance.
• The water inlet hose has a safety valve
and a sheath with an inner mains cable.
WARNING! Dangerous
voltage.
• If the water inlet hose is damaged,
immediately close the water tap and
disconnect the mains plug from the
mains socket. Contact the Authorised
Service Centre to replace the water inlet
hose.
Use
• Do not sit or stand on the open door.
• Dishwasher detergents are dangerous.
Obey the safety instructions on the
detergent packaging.
• Do not drink and play with the water in
the appliance.
• Do not remove the dishes from the
appliance until the programme is
complete. Some detergent may remain
on the dishes.
• The appliance can release hot steam if
you open the door while a programme
operates.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
Service
• Contact the Authorised Service Centre
to repair the appliance. We recommend
only the use of original spare parts.
• When you contact the Authorised
Service Centre, ensure that you have the
following information that is available on
the rating plate.
Model :
PNC :
Serial Number :
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
4 Progress
PRODUCT DESCRIPTION
43
7
9 8
10 56
11
12
1Upper spray arm
2Lower spray arm
3Filters
4Rating plate
5Salt container
6Air vent
7Rinse aid dispenser
8Detergent dispenser
9Cutlery basket
10 Lower basket
11 Upper basket
CONTROL PANEL
1234
1On/off button
2Programme buttons
3Delay button
4Indicators
Progress 5
Indicators
Indicator Description
End indicator.
XtraDry indicator.
Salt indicator. It is always off while the programme operates.
PROGRAMMES
Programme Degree of soil
Type of load
Programme phases Options
1) • Normal soil
• Crockery and
cutlery
• Prewash
• Wash 50 °C
• Rinses
• Dry
• XtraDry
2) • Heavy soil
• Crockery, cutlery,
pots and pans
• Prewash
• Wash 70 °C
• Rinses
• Dry
• XtraDry
• Normal soil
• Crockery and
cutlery
• Prewash
• Wash 65 °C
• Rinses
• Dry
• XtraDry
3) • Fresh soil
• Crockery and
cutlery
• Wash 60 °C or 65
°C
• Rinses
• XtraDry
4) • All • Prewash
1) With this programme you have the most efficient use of water and energy consumption for crockery and cutlery
with normal soil. (This is the standard programme for test institutes).
2) This programme has a high temperature rinsing phase for better hygiene results. During the rinsing phase, the
temperature stays at 70 °C for at least 10 minutes.
3) With this programme you can wash a load with fresh soil. It gives good washing results in a short time.
4) With this programme you can quickly rinse dishes to prevent remains of food to bond on dishes and odours to
form in the appliance. Do not use detergent with this programme.
Consumption values
Programme 1) Water
(l)
Energy
(kWh)
Duration
(min)
9.5 0.789 225
6 Progress
Programme 1) Water
(l)
Energy
(kWh)
Duration
(min)
12 - 14 1.2 - 1.4 140 - 160
12 - 14 1.0 - 1.2 100 - 120
8 0.9 30
4 0.1 14
1) The pressure and the temperature of the water, the variations of the mains supply, the options and the quantity of
dishes can change the values.
Information for test institutes
For all the necessary information for test
performance, send an email to:
Write down the product number (PNC) that
is on the rating plate.
SETTINGS
Programme selection mode and
user mode
When the appliance is in programme
selection mode it is possible to set a
programme and to enter the user mode.
Settings available in the user mode:
• The level of the water softener according
to the water hardness.
• Activation or deactivation of the acoustic
signal for the end of a programme.
As the appliance stores the saved
settings, there is no need to configure
it before every cycle.
The water softener
The water softener removes minerals from
the water supply, which would have a
detrimental effect on the washing results
and on the appliance.
The higher the content of these minerals,
the harder your water is. Water hardness is
measured in equivalent scales.
The water softener should be adjusted
according to the hardness of the water in
your area. Your local water authority can
advise you on the hardness of the water in
your area. It is important to set the right
level of the water softener to assure good
washing results.
Water hardness
German de-
grees (°dH)
French de-
grees (°fH)
mmol/l Clarke de-
grees
Water softener
level
47 - 50 84 - 90 8.4 - 9.0 58 - 63 10
43 - 46 76 - 83 7.6 - 8.3 53 - 57 9
37 - 42 65 - 75 6.5 - 7.5 46 - 52 8
Progress 7
German de-
grees (°dH)
French de-
grees (°fH)
mmol/l Clarke de-
grees
Water softener
level
29 - 36 51 - 64 5.1 - 6.4 36 - 45 7
23 - 28 40 - 50 4.0 - 5.0 28 - 35 6
19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)
15 - 18 26 - 32 2.6 - 3.2 18 - 22 4
11 - 14 19 - 25 1.9 - 2.5 13 - 17 3
4 - 10 7 - 18 0.7 - 1.8 5 - 12 2
<4 <7 <0.7 < 5 1 2)
1) Factory setting.
2) Do not use salt at this level.
Whether you use a standard detergent
or multi-tabs (with or without salt), set
the proper water hardness level to
keep the salt refill indicator active.
Multi-tabs containing salt are not
effective enough to soften hard
water.
How to set the water softener
level
The appliance must be in programme
selection mode:
1. To enter the user mode, press and hold
simultaneously and until the
indicators , and flash.
2. Press .
• The indicators and are off.
• The indicator still flashes.
• The indicator starts flashing. The
number of flashes indicates the
current setting.
– E.g. 5 flashes + pause + 5
flashes = level 5.
3. Press repeatedly to change the
setting. Each pressing of
increases the level number. After
reaching level 10, the count starts again
from level 1.
4. Press the on/off button to confirm the
setting.
Acoustic signals
Acoustic signals sound when a malfunction
of the appliance occurs. It is not possible to
deactivate these acoustic signals.
There is also an acoustic signal that sounds
when the programme is completed. By
default this acoustic signal is deactivated
but it is possible to activate it.
How to activate the acoustic
signal for the end of programme
The appliance must be in programme
selection mode.
1. To enter the user mode press and hold
simultaneously and until the
indicators , and flash.
2. Press .
• The indicators and are off.
• The indicator still flashes.
• The indicator is off.
3. Press to change the setting.
• The indicator is on. The acoustic
signal for the end of programme is
activated.
4. Press on/off to confirm the setting.
8 Progress
OPTIONS
Desired options must be
activated every time before you
start a programme.
It is not possible to activate or
deactivate options while a
programme is running.
Not all options are compatible
with each other. If you have
selected non compatible
options, the appliance will
automatically deactivate one or
more of them. Only the
indicators of the options still
active will stay on.
XtraDry
Activate this option when you want to boost
the drying performance. With the use of this
option, the duration of some programmes,
water consumption and the last rinse
temperature can be affected.
The option XtraDry is not a permanent
option and must be selected at every cycle.
How to activate XtraDry
Press and hold simultaneously and
until the indicator comes on.
If the option is not applicable to the
program, the related indicator does not
come on or it flashes quickly for a few
seconds and then goes off.
BEFORE FIRST USE
1. Make sure that the current level of
the water softener agrees with the
hardness of the water supply. If not,
adjust the level of the water
softener.
2. Fill the salt container.
3. Fill the rinse aid dispenser.
4. Open the water tap.
5. Start a programme to remove any
processing residuals that can still be
inside the appliance. Do not use
detergent and do not load the baskets.
After starting a programme, it may take up
to 5 minutes for the appliance to recharge
the resin in the water softener. It seems that
the appliance is not working. The washing
phase starts only after this procedure is
completed. The procedure is repeated
periodically.
The salt container
CAUTION! Only use salt
specifically designed for
dishwashers.
The salt is used to recharge the resin in the
water softener and to assure good washing
results in the daily use.
How to fill the salt container
1. Turn the cap of the salt container
counterclockwise and remove it.
2. Put 1 litre of water in the salt container
(Only for the first time).
3. Fill the salt container with dishwasher
salt.
4. Remove the salt around the opening of
the salt container.
Progress 9
5. Turn the cap of the salt container
clockwise to close the salt container.
CAUTION! Water and salt can
come out of the salt container
when you fill it. After you fill the
salt container, immediately start
a programme to prevent
corrosion.
How to fill the rinse aid
dispenser
AB
D
C
M
A
X
1
2
3
4
+
-
AB
D
C
CAUTION! Only use rinse aid
specifically designed for
dishwashers.
1. Press the release button (D) to open the
lid (C).
2. Pour the rinse aid in the dispenser (A)
until the liquid reaches the fill level
'max'.
3. Remove the spilled rinse aid with an
absorbent cloth to prevent too much
foam.
4. Close the lid. Make sure that the release
button locks into position.
You can turn the selector of the
released quantity (B) between
position 1 (lowest quantity) and
position 4 or 6 (highest quantity).
DAILY USE
1. Open the water tap.
2. Press the on/off button to activate the
appliance.
Make sure that the appliance is in
programme selection mode.
• If the salt indicator is on, fill the salt
container.
3. Load the baskets.
4. Add the detergent.
5. Set and start the correct programme for
the type of load and the degree of soil.
Using the detergent
30
20
A BD
C
10 Progress
Otros manuales para PVS1550
1
Tabla de contenidos
Idiomas:
Otros manuales de Lavavajillas de Progress
Progress
Progress PI1545X Manual de usuario
Progress
Progress PV1548 Manual de usuario
Progress
Progress PI1530 Manual de usuario
Progress
Progress PI1315W Manual de usuario
Progress
Progress PI1315 Manual de usuario
Progress
Progress PVX1557 Manual de usuario
Progress
Progress PV3571 Manual de usuario
Progress
Progress PVX1556 Manual de usuario
Progress
Progress PV3550 Manual de usuario
Progress
Progress PI3550 Manual de usuario
Progress
Progress PV1546 Manual de usuario
Progress
Progress PVX1535 Manual de usuario
Progress
Progress PVX1572 Manual de usuario
Progress
Progress PVX1571 Manual de usuario
Progress
Progress PIX1535X Manual de usuario
Progress
Progress PVS1550 Manual de usuario
Progress
Progress PVS1540 Manual de usuario
Progress
Progress PVX1530 Manual de usuario
Progress
Progress PVX1557 Manual de usuario
Progress
Progress PI 1310 Manual de usuario
