Pro user IBT1 Manual de usuario

www.pro-user.com

DIGITAL BATTERY TESTER WITH BLUETOOTH®

6V•12V•24V DIGITAL BATTERY TESTER FOR WIRELESS MONITORING YOUR BATTERY

(UP TO 20 BATTERIES AT THE SAME TIME)

DIGITALER BATTERIE-TESTER MIT BLUETOOTH®

6V•12V•24V DIGITALER BATTERIETESTER ZUR DRAHTLOSEN ÜBERWACHUNG IHRER BATTERIE

(BIS ZU 20 BATTERIEN GLEICHZEITIG)

DIGITALE ACCUTESTER MET BLUETOOTH®

6V•12V•24V DIGITALE ACCUTESTER VOOR HET DRAADLOOS MONITOREN VAN UW ACCU

(TOT 20 TEGELIJKERTIJD)

TESTEUR DE BATTERIE DIGITAL AVEC BLUETOOTH®

6V•12V•24V TESTEUR DE BATTERIE BLUETOOTH® POUR SUVEILLER VOTRE BATTERIE SANS FIL

(JUSQU’À20 BATTERIES SIMULTANE!MENT)

IBT1

INTELLIGENT BATTERY TESTER

OPERATING MANUAL

p.03

BEDIENUNGSANLEITUNG

p.12

GEBRUIKSAANWIJZING

p.21

MODE D'EMPLOI

p.30

The IBT1 Intelligent Battery Tester with Bluetooth® is an advanced battery tester manufactured for

Pro-User Europe GmbH that will help you to monitor your battery’s performance data. The IBT1

Intelligent Battery Tester with Bluetooth® functionality and the free app “Check & Charge” additionally

enables you to check your battery with your connected Bluetooth®-enabled device. (iOS 8.0 or later, or

Android 4.4 or later and a mobile device with Bluetooth® BLE Ver. 4.3 or later is needed to connect to

the charger).

We have taken numerous measures in quality control to ensure that your product arrives in top condition,

and will perform to your satisfaction.

Please carefully read and follow the safety and operating instructions. Not following these instructions

may result in a serious accident, including damaged property, serious or even fatal injuries. If the device

is passed on to another person, this manual must also be handed over with it.

CAUTION: Please read this instruction manual carefully before installing and starting up

the device. Do not operate the device unless you have fully read and understood all the

provided information. If you are not confident working with 6V/12V/24V DC voltages or

are unsure of what you are doing, consider to seek for professional help e.g. a car garage

or your vehicle´s manufacturer. Failure to observe these instructions may cause an

electrical shock, fatal or serious injury, material damage or impair the function of the

device.

Read your vehicle's owner's manual!

Some vehicle manufacturers may have special requirements before doing any changes to the vehicle´s

battery. (e.g. fuses that have to be removed or certain security demands).

Pro-User accepts no liability for direct or indirect damage caused by faulty connections, a usage of

damaged or altered products, a usage for purposes other than described and especially caused by failure

to follow these instructions.

For indoor use only: Do not use the unit close to open fire. Do not operate the unit in

explosive atmospheres, such as in the presence of flammable liquids, gases or dust.

Please stop using the device, if the unit is getting very hot, is smoking or is showing any

abnormal behaviour.

Pro-User Europe GmbH is not liable for any direct or indirect damages or injuries caused by the use of

the device, especially caused by failure to follow these instructions.

Type of Batteries

This device is intended to be used only on 6V & 12V & 24V batteries, e.g. Lithium, WET, Gel-, AGM-,

Calcium-, VRLA-Batteries. Follow the recommendations of your battery´s manufacturer.

Storage

When not in use, store the battery tester in a dry environment. Store the battery tester in a safe place

out of the reach of children.

Maintenance

The unit is maintenance-free. If necessary, clean the unit with care using a dry cloth. Don’t try to open

the body casing. There are no user-serviceable parts inside. Damage due to improper use, modifications

or attempted repairs lead to the exclusion of liability and the loss of warranty. Do not lengthen or shorten

the cables. The cables of this device cannot be replaced. If they are damaged, the appliance must be

discarded.

INTRODUCTION

IMPORTANT SAFETY INSTRUCTIONS

General

• Electrical devices are not toys. Keep the product away from children.

• Only use the product as intended and for purposes described in the manual.

• After opening the package, examine all parts for visible damage. If you have found any damage,

please contact the company you purchased this unit from.

• Power-off and stop using the device immediately, if the unit is smoking or is showing any abnormal

behaviour.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory

or mental capabilities, or lack of experience and knowledge, unless they are supervised or have been

instructed on how to use the appliance by a person responsible for their safety. Children should be

supervised to ensure that they do not play with the appliance.

• Installing the device, maintenance and repair work may only be carried out by qualified personnel

who are familiar with the risks involved, the relevant regulations and with the guidelines and safety

precautions to be applied.

• Do not disassemble the device - the internal circuitry may contain hazardous voltages. Attempting to

service the unit yourself may result in electric shock or fire and will void the unit warranty.

• Always keep metal objects or other materials that can short circuit the terminals of the battery or the

device securely away. A resulting spark or short-circuit may not only damage the device, but also

cause an explosion and potentially produce a current high enough to weld a ring or the like to metal.

Remove personal metal items such as rings, bracelets, necklaces, and watches when working on the

device or the battery.

• Operate the device only, if all cables and the housing are undamaged and all connections are tight

and clean. Loose or dirty connections could result in overheating, electrical sparks and fire.

• Ensure the device is standing firmly. The device must be set up and fastened in such a way that it

cannot tip over or fall down.

Environment

• Only use the product in environments from -20°C ~ 65°C (20%-85% Relative Humidity).

• Do not operate the product in damp, wet or dusty environments: Never expose the device to rain or

snow. Doing so may result in damage to the device or other equipment installed in the system or

result in electric shock or fire. Do not operate the unit in explosive atmospheres, such as in the

presence of flammable liquids, gases or dust.

• To avoid heat accumulation, do not cover the device. To prevent overheating , ensure that air inlets

and ventilation is not obstructed. Do not expose the device to a heat source (such as direct sunlight

or heating). Avoid additional heating of the device in this way.

Electrical Cables

• If cables have to be fed through metal holes or other walls with sharp edges, use ducts or cable

bushings to prevent damage.

• Do not lay cables which are loose or bent next to electrically conductive material (metal).

• Do not pull on the cables.

• Avoid to lay 230 V mains cable and 6V/12/24V DC cables in the same duct.

• Prevent all cables from being stepped on, tripped over, or being damaged by e.g. sharp edges or hot

surfaces.

Precautions When Dealing with Batteries

• Batteries can store large amounts of energy and improper handling can be dangerous. NEVER

CONNECT to a battery with an unsuited voltage or other unsuitable or damaged batteries

• Keep children away from batteries and acid.

• Never smoke or allow a spark or flame in vicinity of battery or engine.

• Never use the device when it has received a hard blow, been dropped, or otherwise been damaged.

Also check all cables prior to use. Take it to a qualified professional for inspection and repair.

• To avoid heat accumulation, do not cover the device.

• Avoid getting electrolyte on your skin or clothes. It is acidic and can cause burns. If battery acid

contacts skin or clothing, wash immediately with water. Baking soda neutralizes lead acid battery

electrolyte. If electrolyte gets into your eyes, immediately flood your eyes with running cold water

for at least 20 minutes and get medical attention immediately. Gloves and eye protection is therefore

highly recommended.

• Always keep metal objects or other materials that can short circuit battery terminals securely away

from the batteries. The resulting spark or short-circuit may cause an explosion and can produce a

current high enough to weld a ring or the like to metal. Remove personal metal items such as rings,

bracelets, necklaces, and watches when working with starter batteries.

• Observe technical instructions of the seller or the manufacturer of your battery

• Read your car´s owner's manual. Some vehicle manufacturers may have special requirements before

dealing with the vehicle´s battery (e.g. fuses that have to be removed or certain security demands).

• Keep electrical connections clean: Use terminal grease if necessary.

• Never charge a frozen battery. If battery fluid (electrolyte) becomes frozen, bring the battery to a

warm area to allow the battery to thaw before you begin charging.

• Do not place the device directly on top of the battery or vice versa or on a surface constructed from

combustible material.

PACKAGING MATERIALS

To avoid danger of suffocation, do not let children play with foils or other packaging materials. Remove

all protective coverings before putting the device in operation.

•

Pro-User IBT1 with battery ring terminals and Pro-User “Check & Charge”-Interface (compatible with

Pro User IBC Chargers with “Check & Charge”-Interfaces)

•

Operating manual

Item

Description

Intelligent Battery Tester IBT1

Pro-User Check & Charge Interface to easily connect to a compatible Pro-User charger,

e.g. IBC4000, IBC4000B, IBC7500B

Battery connection cables: red (+ positive terminal) and black (- negative terminal) ring

terminals

SCOPE OF DELIVERY

TECHNICAL DESCRIPTION

Please Read Carefully Before Using The Device

This system is intended to be used only with 6V & 12V & 24V DC batteries, e.g. Lithium and Lead-Acid

batteries e.g. Wet, Maintenance-Free-, Gel, Calcium-, (VRLA-)AGM, Deep-Cycle-batteries

Preparing The Battery

Follow your battery manufacturer´s and vehicle´s manufacturer´s precautions and preparatory

measures, if disconnecting the battery from your vehicle´s 6V/12V/24V system is necessary to install

the device.

Connecting The Ring Terminal Cables

Connect the clamps to the battery in the following order:

1. Connect the RED connection cable to

the positive terminal post of the

battery (marked +).

2. Connect the BLACK connection cable

to the negative post of the battery

(marked -).

It is important to ensure that all

connections are making good contact

with their respective terminal posts.

3. You can easily connect a compatible

Pro-User “Check & Charge” IBC charger

to the IBT1 to recharge your battery.

“Check & Charge”-Interface

Use the conveneint Pro-User “Check & Charge”-Interface to easily connect to a compatible Pro-User IBC

batery charger

OPERATION

Ideal in combination

with the following

Pro-User battery chargers:

Connecting your IBT1 Intelligent Battery Tester to your Bluetooth® enabled smartphone

Note:

iOS 8.0 or later, or Android 4.4 or later and a mobile device with Bluetooth® BLE Ver. 4.3 or later is needed

to connect to the charger

1. Download and install the free “Pro-User Check & Charge” App from Apple App Store or Google

Play Store.

2. Make sure Bluetooth® is enabled on your smartphone.

3. Connect the IBT1 to the battery

4. Open “Pro-User Check & Charge” App.

5. Check the App´s “Settings”- and take the desired settings you need (Background Refresh and

Notifications)

6. Select the IBT1 in the device-list you want to connect to. Make sure the section “Tester” is

selected. You may want to connect to more than one tester or a compatible battery charger.

7. Change the settings as required

Congratulations !

Now you can check your battery status in a very convenient way.

The app is easy to use and gives you all the information you need to know about your battery.

Name & Password:

If you have more than one IBT1 tester or a charger, you may want to rename the devices. The password

is automatically stored in the app.

The password of a Pro-User IBT Battery Tester is not changeable. It

consists of the unique product key printed on the device.

Bluetooth® Connection:

If you put your smartphone to sleep or the Bluetooth® connection was interrupted in another way, it is

possibly required to wait for some seconds and to connect to the charger again (Pull to refresh the device

list). Usually no password is required as the password is stored in the app.

BLUETOOTH® CONNECTION

Mobile Application User Interface:

(software version release 01-2017, details may change)

Start-page of “Check & Charge” List of connected testers

Name and Password setting Battery Status Device settings

The coloured bars in the battery icon

indicate the battery status

WARNING! Do not open or disassemble the device. Attempting to service the unit yourself

may cause the risk of electrical shock or fire. Please follow the safety instructions when

working on the device.

If the device doesn’t work at all, an internal fuse might be blown. This happens always for a reason. Do

not try to replace internal fuses yourself. The device has to be checked by the manufacturer or by an

authorized service.

Bluetooth®

If you cannot connect to your smartphone, please make sure your device fits the requirements: iOS 8.0

or later, or Android 4.4 or later and a mobile device with Bluetooth® BLE Ver. 4.3 or later is needed to

connect to the device. Sometimes it´s useful to turn off the Bluetooth®-function of your smartphone

and reactivate it again or to connect manually. Please see the instructions of your smartphone operating

system how to take the according Bluetooth® settings.

It is essential to keep your battery regularly charged throughout the year, especially during the winter

months. Low temperature reduces the effectiveness of your car battery and your motor oil is thicker.

Engines are more difficult to start and the heater, windscreen wipers and lights are all draining power. It

is at this time that batteries have to be at peak power. If your battery is not regularly maintained and

kept fully charged, it can cause problems and a possible breakdown.

Listed are some helpful hints on how to keep your battery healthy in conjunction with your battery

charger:

Detecting faulty cells with a hygrometer (not possible with Lithium, sealed or maintenance-free

batteries)

Starter-batteries are usually made of several cells, with a nominal voltage of 2V per cell. If one of the

cells is defective, the whole battery deteriorates. If, after several hours of charging, your battery is still

flat, you should test the battery cells.

Using a hydrometer, which can be purchased from most motor accessory stores, you can check the

specific gravity of the electrolyte in each cell. Take hydrometer readings from each cell in the battery.

Put the fluid back into the cell after testing, taking care not to spill the fluid. If one reading is lower than

the others, this could indicate a faulty cell. If necessary, get an auto-electrician to check your battery. In

some cases a battery can be revived, but one faulty cell is enough to ruin your battery.

Care

Sometimes the battery may appear flat, but the reason could simply be dirty or loose connections on

your battery terminals. It is important to maintain the leads on a regular basis. Clean all contacts and

grease them using terminal grease. Make sure that all connections are tight.

It is essential to keep the electrolyte level above the plates, note that you should not overfill it, as the

electrolyte is strongly acidic. When topping up, do not use tap water. Always use distilled or de-ionized

water. If necessary have it checked by your garage.

TROUBLESHOOTING

BATTERY MAINTENANCE AND CARE

Tabla de contenidos

Otros manuales de Equipo de prueba de pro user

pro user

pro user BT400 Manual de usuario

Manuales populares de Equipo de prueba de otras marcas

SMART

SMART KANAAD SBT XTREME 3G Series Manual de usuario

Agilent Technologies

Agilent Technologies BERT Serial Manual de usuario

Agilent Technologies

Agilent Technologies N3280A Manual de usuario

Vernier

Vernier Go Direct Voltage Manual de usuario

Lifeloc

Lifeloc R.A.D.A.R. Manual de usuario

Fluke

Fluke T5-600 Instrucciones de funcionamiento e instalación

Mercury

Mercury TSL01 Manual de usuario

MAHA

MAHA MBT Series Manual de usuario

Fuji Electric

Fuji Electric P-61 Manual de usuario

ETC

ETC SealerAtor Manual de usuario

Skyfine

Skyfine ETHYWAY V2 Manual de usuario

Appion

Appion G5 Twin Manual de usuario

PCB Piezotronics

PCB Piezotronics 8159-0112A Manual de usuario

BW Technologies

BW Technologies MicroDock II Manual de usuario

Sun Nuclear

Sun Nuclear 1027 Manual de usuario

Biomark

Biomark HPR LITE READER Manual de usuario

Hioki

Hioki 3169-20 Manual de usuario

Ashcroft

Ashcroft ATE-100 Manual de usuario

pro user IBT1 Manual de usuario

Manuales populares de Equipo de prueba de otras marcas
