歡迎購買寶工GE-631空氣動力引擎車，在石油燃料能源逐漸消耗殆盡之際，替代能源成為重要議題，而
「空氣」就能解決這項難題！空氣一天24小時無所不在，取之不盡，用之不竭，而且最棒的是─免費！ 也
許你會好奇，空氣要如何取代汽油？現在就跟孩子們一起動手做空氣飛車，親身體驗空氣帶來的原動力！
空氣飛車結合了環保意識﹑科學原理﹑和DIY的樂趣，讓孩子們做中學，學中做！這是一部真正引擎結構的
空氣車，組裝簡單，操作也很容易，內建打氣桿，只要將空氣瓶注滿空氣，車子通過空氣加壓可以在35秒
內推進到50公尺! 空氣動力飛車內紅色矽膠管可確保良好的氣密性，同時設計有測量空氣壓縮量的壓力計，
當持續將空氣注入已注滿的空氣瓶時，安全氣閥裝置會自動開啟來排放多餘的空氣，不用擔心氣瓶爆破問題。
空氣動力引擎車不需要電池，不受天氣狀況侷限提供您更多樂趣，對環境安全、無毒、乾淨，提供8歲以上
的孩子一個充滿啟發、有趣及滿足成就感的學習經驗。
自攻螺絲 華司螺絲 圓軸 (短) 圓軸 (長)
120 6 1
P1 P2 P3 P4
斜口鉗 十字起子 鐵鎚 剪刀
麥克筆 尺紙巾
部分零件含有銳利的邊緣及尖角，組裝時請注意
1
數量 數量 數量 數量
產品介紹 Product Introduction
自備工具如下 Tools You May Need
零件清單 Mechanical Parts List
Tapping Screw Tapping Screw Round Shaft(Short) Round Shaft(Long)
QTY QTY QTY QTY
Diagonal Cutter
Product contains functional edges and sharp points.
Permanent Marker Ruler
Scissors
Screwdriver Hammer
Tissue Paper
空氣動力引擎車
Air Engine Car Kit
Thank you for purchasing GE-631 Air Engine Car Kit. Gasoline is becoming difficult to find noways and is
contributing to environmental issues and worldwide problem, Air as fuel...could possibly be another alternative to
petroleum. Air is available 24/7, does not run out and it's free.You may wonder, how it will be possible. Now build the Air
Power Engine Car with your kids and bring the vision to life . This kit designed with the environment in mind, technology,
and also fun to build. Assembly and operation is breeze. A pump-up bar with a pressure meter is built into the car for
easy operation. When the air chamber is full, you can release the compressed air ; the air then expands and drives
the vehicle to 50 meters in 35 seconds. The silicone tube creates an air tight fit. Another safety device implemented into
the kit is a safety valve. if the user keeps pumping while the tank is full, the safety valve will open and bleed the air
automatically. The car is fun thatrequires no batteries or specific weather conditions to limit its usage. The kit is suitable
for child above 8 years old.
警
告
1.本玩具內含小物件，請勿讓三歲以下孩童取得，以免放入口中造成窒息。
2.兒童使用剪切工具時，請家長指導使用方式，並請在家長監督下使用，以免發生意外。
3.為避免嬰兒或兒童產生窒息的危險，請於拆卸後立即將塑膠袋銷毀或遠離嬰兒及兒童。
Choking hazard - Small parts. Not for children under 3 years.
Adult supervision is recommended when children use scissors.
To avoid danger of suffocation, keep the plastic bag away from babies and children.
Warning
