Pro-Lift T-2300A Manual de usuario

Model: T-2300A

WORKING LOAD LIMIT 680 KG

UTILITY/ATV LIFT

OWNER’S MANUAL

WARNING

To avoid crushing and related injuries:

NEVER work on, under or around a load supported only

by a jack. Ensure locking devices are fully engaged.

Imported by

SHINN FU AUSTRALIA PTY. LTD.

15 Viewtech Place, Rowville 3178 VIC Australia

SAVE THESE INSTRUCTIONS

For your safety please read, understand and follow the information contained within before use. The owner and operator

shall have an understanding of this product and safe operating procedures before attempting to use. Instructions and

safety information shall be conveyed in the operators native language before use is authorized. Make certain that

the operator thoroughly understands the inherent dangers associated with the use and misuse of the product. If any

doubt exists as to the safe and proper use of this device as outlined in this factory authorized manual, remove the lift

from service until safe and proper use is clearly understood.

INTENDED USE

This lift is specically designed to lift and support up to rated capacity loads consisting of a single Motorcycle, ATV,

Snowmobile, Water Craft or Riding Lawn Mower whose frames are compatible with the lifting members of the lift.

Incompatibility is evident when the loaded motorcycle, ATV, etc wobbles, feels unstable, and/or does not securely on

the lift’s padded lift arms. Tying down incompatible loads will not make the loads secure and may cause unexpected

loss of load resulting in personal injury and/or property damage. These lifts are NOT suitable for lifting, leveling and/or

positioning cars, trucks, SUV’s or conveyances other than those specically listed and approved above. These lifts

are NOT suitable for lifting, leveling and/or positioning houses, construc-tion trailers and dwellings in general. This

product does not contain independent lifting devices, but is designed to be permanently assembled. Hydraulic unit

is not to be used independently of the motorcycle lift.

WARNING

Study, understand and follow all printed materials provided with and on this device. Do not exceed rated capacity.

Ensure load is compatible with lift’s lifting pad. Center load on lift pads. After lifting load to desired height, ensure

lift arm locking mechanism is engaged. Secure load to lift using apropriate straps. Engage Anti-slide Stops before

working on or around loaded Lift. Move loaded lift only over smooth, level, seam-less surfaces. Before moving, ensure

load has been lowered completely. Use only on hard, level surfaces capable of sustaining rated capacity loads. Lift

only on areas of the load as specied by it’s manufacturer. Do not alter this product in any way. Do not use for any

purpose other than that for which this device is intended. Failure to heed these messages may result in personal

injury and/or property damage.

SPECIFICATIONS:

Rated Capacity: 680 kg

Height Lowered: 118 mm

Height Raised: 368 mm

Net Weight: 26.8 kg

PARTS LIST

ITEM PART NO. DESCRIPTION QTY

1 T-2300A-1 Front Wheel Assy 2

2 T-2300A-2 Rear Wheel Assy 2

3 T-2300A-3 Hydraulic Unit Assy 1

4 T-2300A-4 Height Lock Release 1

5 T-2300A-5 T-handle 1

6 T-2300A-6 Hardware Kit (Not Shown) 1

ASSEMBLY INSTRUCTIONS

1. Install Hydraulic Ram

Attach hydraulic ram to the ram platform with bolts (21) and washers (22) (24).

2. Attach Hydraulic Ram & Lock Bar

A. Remove cotter pin and lock pin (27) from ram. Raise load frame (19) by hand and align the head of the hydraulic

ram with the tab holes in the low center of the load frame. Replace lock pin (27) and secure with safely clasp

(23).

B. To install lock bar, align lock bar (16) into lock pawls (2) on both sides and secure using washers (17) and nuts

(18).

Bolt (21)

Lock washer (22)

Washer (24)

Hydraulic ra

Ram platform

Lock pin (27)

Load frame (19)

Safety clasp (23)

Hydraulic ram

Lock bar (16)

Lock pawl (2)

Lock washer (17)

M8 nut (18)

Lock pawl (2)

ASSEMBLY INSTRUCTIONS

3. Install Pump Pedal.

4. Install Handle.

INSPECT BEFORE EACH USE

Do not use if cracked, broken, bent or otherwise damaged parts are noted or if the lift is suspected to have been

subjected to a shock load. A shock load is caused by rapidly opening and closing the release valve while the lift is

loaded. Such operation may result in a hydraulic overload which may disable the hydraulic unit. Owner and operators

of this device shall be aware that no serviceable or replaceable parts are available for this device other than those

parts listed on page 6. Any lift that appears to be damaged in any way, is worn or operates abnormally shall be

removed from service immediately until such time as repairs can be made. Do not attempt to weld, rivet or otherwise

repair this device. DO NOT modify or alter this device. It is recommended that an annual inspection be done to this

device by qualied persons and that missing or damaged labels, warning safety decals be replaced with ones that

are factory authorized.

Pump pedal (29)

Hydraulic ram

Bolt M8x12 (32)

T-handle (25)

Load frame (19)

Handle pin (20)

KNOW YOUR LIFT

To Engage Locking Mechanism, press

Height Locking Lever forward against

Lift Frame. To disengage locking

mechanism, pull Lever back against

Hydraulic Unit.

Hydraulic Unit

Handle

Lift Saddle

Height

Locking/Unlocking

Lever

Swivel Casters

Anti-Slide Stops

OPERATING INSTRUCTIONS

1. Position Lift under appropriate lift point, centering load on lift platform.

2. Locate and pump the lift pedal until the lift platform comes into contact with an appropriate lift point.

3. After centering the load, slowly and carefully raise the lift platform by pumping the lift foot pedal.

4. Engage the Anti-Slide Stops by turning the knobs, extending it until the rear casters don’t touch the ground.

5. Continue pumping until the load has reached desired height. Secure the load using appropriate tie down means.

Four tie down loops have been provided on the frame of the Lift. Make sure that the height locking mechanism is

fully engaged before working on or around the loaded Lift.

WARNING: Clear all tools and personnel before lowering load.

6. To lower, disengage height locking lever and depress release pedal. It may be necessary to slightly raise the lift

platform before disengaging the height locking lever.

Front Wheel

Release Pedal

Lift Pedal

Sleeve

Oil Filler

Plug

CARE AND MAINTENANCE

NOTE: When lift is not in use, lifting arm should be stored in the fully retracted position. Keep lift clean and well

lubricated. Apply a couple of drops of light machine to all pivoting joints as needed. Thoroughly wipe up excess oil

to help prevent slipping and falling.

TO CHECK AND ADD HYDRAULIC OIL

1. To check hydraulic oil level, remove unit from lift, stand unit upright on a stable, level surface. Remove oil ller

plug. Oil should be to the level of the oil ller plug hole.

2. If low, add high quality hydraulic jack oil ONLY. Never use ANY other uid. Use of other uid may result in hydraulic

system failure, causing sudden and unexpected loss of load height.

3. Install oil ller plug, install hydraulic unit into receiver of lift. Secure with provided bolt.

NOTE: To get the longest life possible out of your lift, we recommend changing the hydraulic oil after 7 years of use,

sooner if used in a dust and grit lled environment. Do not expose to moisture. Dry lift completely if it gets wet. Check

pump piston and ram of hydraulic unit periodically for signs of rust and corrosion. Clean mildly affected areas with a

clean oily cloth. Never use abrasives on the pump piston and ram surfaces.

TO REPLACE HYDRAULIC OIL

1. Remove hydraulic unit from lift. Stand unit upright on a stable, level surface. Remove oil ller plug and drain old

oil into a suitable container.

2. Fill with high quality hydraulic jack oil.

NOTE: Dispose of used hydraulic oil in accordance with local regulations.

TO PURGE TRAPPED AIR FROM SYSTEM

1. Fully lower the lift arms, leave release valve open.

2. Remove oil ller plug. As you remove the oil ller plug you may hear pressurized air escaping from the reservoir.

This means you have successfully purged trapped air from the system.

3. Install oil ller plug.

TROUBLESHOOTING

Symptom Possible Causes Corrective Action

Hydraulic unit will not lift load • Release valve not tightly closed

• Overload condition

• Ensure release valve tightly closed

• Remedy overload condition

Hydraulic unit bleeds off after lift

• Release valve not tightly closed

• Overload condition

• Hydraulic unit malfunction

• Ensure release valve tightly closed

• Remedy overload condition contact

PRO-LIFT Customer Support

Lift will not lower after unloading • Reservoir overlled

• Linkages binding

• Ensure Load is removed, then

• Drain uid to proper level

• Clean and lubricate moving parts

Poor lift performance • Fluid level low

• Air trapped in system

• Ensure proper uid level

• Follow procedure of to purge trapped

air from system

Will not lift to full extension • Fluid level low • Ensure proper uid level
