Pro-Form 831.297390 Manual de usuario

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

Serial Number

Decal

Model No. 831.297390

Serial No.

The serial number is found in the location

shown below. Write the serial number in

the space above for future reference.

USER'S MANUAL

SEARS, ROEBUCK AND CO., HOFFMAN ESTATES, IL 60179

TABLE OF CONTENTS

IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

MAINTENANCE AND TROUBLE-SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

FULL 90 DAY WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

Note: An EXPLODED DRAWING and PART LIST are attached to the center of this manual. Please save them for

future reference.

1. It is the responsibility of the owner to ensure

that all users of this treadmill are adequately

informed of all warnings and precautions.

2. Use the treadmill only as described in this

manual.

3. Place the treadmill on a level surface, with at

least eight feet of clearance behind it. Do not

place the treadmill on any surface that blocks

air openings. To protect the floor or carpet

from damage, place a mat under the treadmill.

4. Keep the treadmill indoors, away from mois-

ture and dust. Do not put the treadmill in a

garage or covered patio, or near water.

5. Do not operate the treadmill where aerosol

products are used or where oxygen is being

administered.

6. Keep children under the age of 12 and pets

away from the treadmill at all times.

7. The treadmill should not be used by persons

weighing more than 250 pounds.

8. Never allow more than one person on the

treadmill at a time.

9. Wear appropriate exercise clothing when

using the treadmill. Do not wear loose cloth-

ing that could become caught in the treadmill.

Athletic support clothes are recommended for

both men and women. Always wear athletic

shoes. Never use the treadmill with bare feet,

wearing only stockings, or in sandals.

10. When connecting the power cord (see page 7),

plug the power cord into a surge suppressor

(not included) and plug the surge suppressor

into a grounded circuit capable of carrying 15

or more amps. No other appliance should be

on the same circuit. Do not use an extension

cord.

11. Use only a single-outlet surge suppressor

that is UL 1449 listed as a transient voltage

surge suppressor (TVSS). The surge suppres-

sor must have a UL suppressed voltage rating

of 400 volts or less and a minimum surge dis-

sipation of 450 joules. The surge suppressor

must be electrically rated for 120 volts AC and

15 amps.

12. Keep the power cord and the surge protector

away from heated surfaces.

WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the

following important precautions and information before operating the treadmill.

IMPORTANT PRECAUTIONS

13. Never move the walking belt while the power

is turned off. Do not operate the treadmill if

the power cord or plug is damaged, or if the

treadmill is not working properly. (See

BEFORE YOU BEGIN on page 4 if the tread-

mill is not working properly.)

14. Never start the treadmill while you are stand-

ing on the walking belt. Always hold the

handrails while using the treadmill.

15. The treadmill is capable of high speeds.

Adjust the speed in small increments to avoid

sudden jumps in speed.

16. To reduce the possibility of the treadmill over-

heating, do not operate the treadmill continu-

ously for longer than 1 hour.

17. Never leave the treadmill unattended while it

is running. Always remove the key when the

treadmill is not in use.

18. Do not attempt to raise, lower, or move the

treadmill until it is properly assembled. (See

ASSEMBLY on page 5, and HOW TO MOVE

THE TREADMILL on page 10.) You must be

able to safely lift 45 pounds (20 kg) in order to

raise, lower, or move the treadmill.

19. When folding or moving the treadmill, make

sure that the storage latch is fully closed.

20. Inspect and tighten all parts of the treadmill

regularly.

21. Never insert any object into any opening.

22. Always unplug the power cord before per-

forming the maintenance and adjustment pro-

cedures described in this manual. Never re-

move the motor hood unless instructed to do

so by an authorized service representative.

Servicing other than the procedures in this

manual should be performed by an authorized

service representative only.

23. This treadmill is intended for in-home use

only. Do not use this treadmill in any commer-

cial, rental, or institutional setting.

WARNING: Before beginning this or any exercise program, consult your physician. This

is especially important for persons over the age of 35 or persons with pre-existing health problems.

Read all instructions before using. SEARS assumes no responsibility for personal injury or property

damage sustained by or through the use of this product.

SAVE THESE INSTRUCTIONS

The decal shown below has been placed on your treadmill. If the decal is missing, or if it is not legible,

please call our toll-free HELPLINE to order a free replacement decal (see the back cover of this manual).

Apply the decal in the location shown.

Congratulations for purchasing the new PROFORM®

CROSSWALK GT treadmill. The CROSSWALK GT

treadmill combines advanced technology with innova-

tive design to let you enjoy an excellent form of cardio-

vascular exercise in the convenience and privacy of

your home. And when you’re not exercising, the unique

CROSSWALK GT can be folded up, requiring less than

half the floor space of other treadmills.

For your benefit, read this manual carefully before

using the treadmill. If you have additional questions,

please call our toll-free HELPLINE at 1-800-736-6879,

Monday through Saturday, 7 a.m. until 7 p.m. Central

Time (excluding holidays). To help us assist you,

please note the product model number and serial num-

ber before calling. The model number of the treadmill

is 831.297390. The serial number can be found on a

decal attached to the treadmill (see the front cover of

this manual for the location).

Before reading further, please review the drawing

below and familiarize yourself with the parts that are

labeled.

BEFORE YOU BEGIN

Handrail

Upper Body Arm

Console

Storage Latch Key/Clip

Circuit

Breaker

Incline

Leg

Walking Belt

Hood

Cushioned Walking

Platform

Front Wheel

Foot Rails

Power Cord

Rear Roller

Adjustment Bolts

Water Bottle

Holder (Bottle

not included)

Towel Rack

Accessory Tray

Upper Body Arm

RIGHT SIDELEFT SIDE

1. With the help of a second person, carefully lay the

treadmill on its right side as shown (refer to the drawing

on page 4 to identify the right side).

Insert the Extension Legs (41) into the treadmill. Make

sure that the Extension Legs are turned so the Base Pads

(36) are on the indicated side. Attach each Extension Leg

with an Extension Leg Screw (34).

With the help of a second person, carefully raise the

treadmill to the upright position so the Extension Legs

(41) are resting flat on the floor.

Refer to the inset drawing. Remove the nut, bolt, and

shipping bracket from the left Upright (14).

2. Refer to HOW TO LOWER THE TREADMILL FOR USE

on page 11. Follow the instructions in step 2 to lower the

treadmill.

Position the Left Handrail (2) on the left Upright (14) as

shown. Thread a Handrail Bolt (15) with a Handrail

Washer (16) into the left Upright and the Left Handrail. Do

not tighten the Handrail Bolt yet.

Attach the lower end of the Left Handrail (2) to the

Extension Leg (41) with a 3 1/2” Handrail Bolt (89), a 3/8”

Washer (99), and a Flange Nut (57). Do not tighten the

Handrail Bolt yet.

89 99

Handrail Washer (16)–2 Extension Leg Screw (34)–2

3 1/2" Handrail Bolt (89)–2

3/8" Washer (99)–2

Flange Nut (57)–2

1/2" Screw (13)–6

Handrail Bolt (15)–2

Bolt

Nut

Shipping

Bracket

ASSEMBLY

Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not

dispose of the packing materials until assembly is completed. Refer to the drawings below to identify the small

parts used in assembly. Assembly requires the included allen wrench and your own phillips screw-

driver , adjustable wrench , open end wrench and scissors .

3. With the help of a second person, hold the Console Base

(6) and the Right Handrail (32) near the right Upright (14).

Feed all excess Wire Harness (26) down into the right

Upright; if necessary, bend the Wire Harness as shown.

Route the Wire Harness (26) through the bracket on the

Right Handrail (32) as shown. Insert the bracket into the

right Upright (14).

Refer to the inset drawing. Push the Strain Relief Clip (88)

onto the Wire Harness (26). Insert a 1/2” Screw (13) into

the Strain Relief Clip and into the indicated hole in the

Right Handrail (32). Make sure that there is no slack Wire

Harness between the Strain Relief Clip and the Console

Base (6). Tighten the Screw into the Console Base.

IMPORTANT: The Strain Relief Clip (88) must be

attached as instructed.

4. Attach the Console Base (6) to the Left and Right

Handrails (2, 32) with three 1/2” Screws (13).

5. Thread a Handrail Bolt (15) with a Handrail Washer (16)

into the right Upright (14) and the Right Handrail (32). Do

not tighten the Handrail Bolt yet.

Attach the lower end of the Right Handrail (32) to the

Extension Leg (41) with a 3 1/2” Handrail Bolt (89), a 3/8”

Washer (99), and a Flange Nut (57).

Tighten all parts used in this step and in step 2.

6. Attach the Storage Latch (12) to the left Upright (14) with

two 1/2” Screws (13). Be careful not to overtighten the

Screws.

Refer to the inset drawing. Remove the backing from the

Adhesive Clip (74). Press the Adhesive Clip onto the

base of the Uprights (14) in the indicated location. Press

the Allen Wrench (73) into the Adhesive Clip.

7. Make sure that all parts are tightened before you use the treadmill. To protect the floor or carpet, place

a mat under the treadmill.

Bracket

57 41

OPERATION AND ADJUSTMENT

THE PERFORMANT LUBETM WALKING BELT

Your treadmill features a walking belt coated with

PERFORMANT LUBETM, a high-performance lubricant.

IMPORTANT: Never apply silicone spray or other

substances to the walking belt or the walking plat-

form. Such substances will deteriorate the walking

belt and cause excessive wear.

HOW TO PLUG IN THE POWER CORD

Your treadmill, like any other type of sophisticated

electronic equipment, can be seriously damaged by

sudden voltage changes in your home’s power.

Voltage surges, spikes, and noise interference can

result from weather conditions or from other appliances

being turned on or off. To decrease the possibility of

your treadmill being damaged, always use a surge

suppressor with your treadmill (see drawing 1 at

the right).

Surge suppressors are sold at most hardware stores

and department stores. Use only a single-outlet surge

suppressor that is UL 1449 listed as a transient voltage

surge suppressor (TVSS). The surge suppressor must

have a UL suppressed voltage rating of 400 volts or

less and a minimum surge dissipation of 450 joules.

The surge suppressor must be electrically rated for

120 volts AC and 15 amps.

This product must be grounded. If it should malfunc-

tion or break down, grounding provides a path of least

resistance for electric current to reduce the risk of elec-

tric shock. This product is equipped with a cord having

an equipment-grounding conductor and a grounding

plug. Plug the power cord into a surge suppressor,

and plug the surge suppressor into an appropriate

outlet that is properly installed and grounded in

accordance with all local codes and ordinances.

This product is for use on a nominal 120-volt circuit,

and has a grounding plug that looks like the plug illus-

trated in drawing 1 below. A temporary adapter that

looks like the adapter illustrated in drawing 2 may be

used to connect the surge suppressor to a 2-pole

receptacle as shown in drawing 2 if a properly

grounded outlet is not available.

The temporary adapter should be used only until a

properly grounded outlet (drawing 1) can be installed

by a qualified electrician.

The green-colored rigid ear, lug, or the like extending

from the adapter must be connected to a permanent

ground such as a properly grounded outlet box cover.

Whenever the adapter is used it must be held in place

by a metal screw. Some 2-pole receptacle outlet box

covers are not grounded. Contact a qualified elec-

trician to determine if the outlet box cover is

grounded before using an adapter.

DANGER: Improper connection

of the equipment-grounding conductor can

result in an increased risk of electric shock.

Check with a qualified electrician or service-

man if you are in doubt as to whether the

product is properly grounded. Do not modify

the plug provided with the product—if it will

not fit the outlet, have a proper outlet

installed by a qualified electrician.

Grounded Outlet Box

Grounding Plug

Surge Suppressor

Grounding Pin

Adapter

Lug

Metal Screw

Grounded Outlet

Grounding Pin

DIAGRAM OF THE CONSOLE

Clip Key

Speed Control

Monitor Displays

CAUTION: Before operating the con-

sole, read the following precautions.

• Do not stand on the walking belt when turning

on the power.

• Always wear the clip (see the drawing above)

while operating the treadmill. When the key is

removed from the console, the walking belt will

stop.

• Adjust the speed in small increments.

• The training zones marked beside the speed

control are general guidelines only. See pages

14 and 15 for more information.

• To reduce the possibility of electric shock,

keep the console dry. Avoid spilling liquids on

the console. Use only a sealable water bottle.

BATTERY INSTALLATION

The console

requires two or

three "AA" bat-

teries (not in-

cluded). Alkaline

batteries are rec-

ommended. To

install batteries,

open the battery

cover as shown.

Press the batter-

ies into the battery

compartment, with the negative ends of the batteries

(marked “–”) touching the springs. Close the battery

cover.

STEP BY STEP CONSOLE OPERATION

Step onto the foot rails of the treadmill. Find the clip

attached to the key (see the drawing above), and slide

the clip onto the waistband of your clothing. Follow the

steps below and on page 9 to operate the console.

Insert the key fully into the power switch.

The four displays will

not turn on until the

ON/RESET button is

pressed or the walk-

ing belt is started.

Note: If you just in-

stalled batteries, the

displays will already be on.

Batteries

Battery Cover

Incline Control

Note: If there is a thin sheet of clear

plastic on the console, remove it.

Reset the speed control.

Slide the speed control

down to the RESET

position. Note: Each

time the walking belt is

stopped, the speed

control must be moved

to the RESET position

before the walking belt

can be restarted.

Start the walking belt.

After you have moved the speed control to the

RESET position, slide it slowly upward until the

walking belt begins to move at slow speed.

Carefully step onto the walking belt and begin ex-

ercising. Change the speed of the walking belt as

desired by sliding the speed control.

To stop the walking belt, step onto the foot rails

and slide the speed control to the RESET position.

Change the incline of the treadmill, if desired.

To change the incline

of the treadmill, hold

down the top or bottom

of the incline control.

Important: Change

the incline of the

treadmill only with

the incline control.

Do not place objects

under the treadmill to change the incline.

Follow your progress with the four monitor

displays.

The TIME display—

This display shows the

total time that you have

walked or run on the

treadmill.

The DISTANCE

display—This display

shows the total distance

that you have walked or

run, in miles.

The SPEED display—

This display shows the

speed of the walking belt,

in miles per hour.

The CALORIES/

FAT CALORIES

display—This display

shows the approximate

numbers of calories

and fat calories you

have burned. (See FAT

BURNING on page 14.) Every seven seconds, the

display will change from one number to the other.

Arrows in the display will indicate which number is

currently shown.

Note: The displays can be reset by pressing the

ON/RESET button.

When you are finished exercising, stop the

walking belt and remove the key.

Step onto the foot

rails, stop the walking

belt, and remove the

key from the console.

Store the key in a se-

cure place. After the

key is removed, the

displays will remain on for about five minutes.

Note: Any time that the walking belt is stopped

and no console buttons are pressed for five

minutes, the displays will automatically turn off.

HOW TO USE THE UPPER BODY ARMS

As you exercise on

the treadmill, you

can hold either the

handrails or the

upper body arms.

The upper body

arms are designed

to exercise your

arms, shoulders,

and back for a total

body workout. Hold

one upper body

arm with each

hand, and move

them forward and

back as you walk

on the treadmill.

To vary the intensity of your upper body exercise, the

resistance of the upper body arms can be adjusted. To

increase the resistance, turn the resistance knobs clock-

wise; to decrease the resistance, turn the knobs coun-

terclockwise.

2Arrow

Upper Body

Arms

Resistance

Knobs

HOW TO FOLD AND MOVE THE TREADMILL

HOW TO FOLD THE TREADMILL FOR STORAGE

Unplug the power cord. Caution: You must be able to

safely lift 45 pounds (20 kg) in order to raise, lower, or

move the treadmill.

1. Hold the treadmill with your hands in the locations shown

at the right. Caution: To decrease the possibility of in-

jury, bend your legs and keep your back straight. As

you raise the treadmill, make sure to lift with your legs

rather than your back. Raise the treadmill about halfway

to the vertical position.

2. Move your right hand to the position shown and hold the

treadmill firmly. Raise the treadmill until the storage latch

closes over the catch. Make sure that the storage latch

is fully engaged over the catch.

To protect the floor or carpet from damage, place a

mat under the treadmill. Keep the treadmill out of

direct sunlight. Do not leave the treadmill in the stor-

age position in temperatures above 85° Fahrenheit.

HOW TO MOVE THE TREADMILL

Before moving the treadmill, convert the treadmill to the stor-

age position as described above. Make sure that the stor-

age latch is closed fully over the catch.

1. Hold the handrails and place one foot on the base as

shown.

2. Tilt the treadmill back until it rolls freely on the front wheels.

Carefully move the treadmill to the desired location. Never

move the treadmill without tipping it back, or the base

pads may come off. To reduce the risk of injury, use

extreme caution while moving the treadmill. Do not at-

tempt to move the treadmill over an uneven surface.

3. Place one foot on the base, and carefully lower the tread-

mill until it is resting in the storage position.

Base

Front Wheels

Catch

Closed

Storage

Latch

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Rueda de andar de Pro-Form

Pro-Form

Pro-Form 5.2 Treadmill Manual de operación y mantenimiento

Pro-Form

Pro-Form 650 V Treadmill Manual de operación y mantenimiento

Pro-Form

Pro-Form heart rate monitor 545S Manual de usuario

Pro-Form

Pro-Form heart rate monitor 545S Manual de usuario

Pro-Form

Pro-Form 3.5 P Guía de inicio rápido

Pro-Form

Pro-Form 500 ZLT PETL59910.0 Manual de usuario

Pro-Form

Pro-Form 730 Zlt Treadmill Guía de configuración

Pro-Form

Pro-Form 590 HR PETL55132 Manual de usuario

Pro-Form

Pro-Form CX 18i PFTL64505.0 Manual de usuario

Pro-Form

Pro-Form Cross Walk CSI Manual de usuario

Pro-Form

Pro-Form PRO 9000 Manual de usuario

Pro-Form

Pro-Form 831.294230 Manual de usuario

Pro-Form

Pro-Form 485 Pi Treadmill Manual de usuario

Pro-Form

Pro-Form 725FP PFTL69100 Manual de usuario

Pro-Form

Pro-Form 6.75q Manual de operación y mantenimiento

Pro-Form

Pro-Form 780 Zlt Treadmill Guía del usuario

Pro-Form

Pro-Form 750CS Manual de usuario

Pro-Form

Pro-Form PERFORMANCE 950 Manual de usuario

Pro-Form

Pro-Form PFEL05900 Manual de usuario

Pro-Form

Pro-Form PERFORMANCE 400 Manual de usuario

Pro-Form

Pro-Form 705 Zlt Treadmill Guía de inicio rápido

Pro-Form

Pro-Form Crosswalk 831297311 Manual de usuario

Pro-Form

Pro-Form 500 Zlt Treadmill Manual de usuario

Pro-Form

Pro-Form XP TRAINER 580 Manual de usuario

Manuales populares de Rueda de andar de otras marcas

Treadly

Treadly TREADLY 2 Manual de usuario

HEALTH ONE

HEALTH ONE Walk Ro Manual de usuario

NordicTrack

NordicTrack NTL12941 Manual de usuario

NordicTrack

NordicTrack T7.5 S Manual de usuario

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manual de usuario

Merax

Merax MS282992 Manual de usuario

FYTTER

FYTTER RU-2SX Manual de usuario

Precor

Precor 903 Manual de usuario

FitLogic

FitLogic freewill d225 Manual de usuario

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manual de usuario

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manual de usuario

Stamia

Stamia InMotion II Manual de usuario

Smooth Fitness

Smooth Fitness EVO 3i Manual de usuario

NordicTrack

NordicTrack NETL81810.0 Manual de usuario

Schwinn

Schwinn 830/Journey 8.0 Manual de usuario

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manual de usuario

Spirit

Spirit XT8 Manual de usuario

NordicTrack

NordicTrack T 14.0 Treadmill Manual de usuario
