WARNING: If burner does not light or flame is too low, your may have spider or other insect
blockage in burner, or the flow limiting device has been activated. See "Burner
Assembly/Maintenance" under Proper Care and Maintenance, or "Regulator Resetting
Procedure" under Connecting LP Cylinder and Hose /Regulator to Grill.
MATCH LIGHTING THE MAIN BURNERS
1. Open lid before lighting.
2. Turn the burner control knobs "OFF"
3. Strike the match and place approximately 1/2" (1 to 2 cm) above lighting hole located on
right and left hand side of the grill body.
4. Turn right or left burner control knob to the HIGH position. The burner should light within 5
seconds.
5. If the burner does not light, turn the control knob to "OFF" and wait 5 minutes for gas to
evacuate the grill ,Repeat Steps 1 through 5 until the burner ignites.
6. Once lit, light adjacent burners in sequence by pressing in and rotating the control knob to
the "HIGH" position.
7. If the burner does not light within the first few attempts of match lighting ,there is a
problem with the gas supply ,turn off the gas at the burner and cylinder, DO NOT attempt
to operate the grill until the problem is found and corrected, See"Trouble Shooting"section
of this manual.
LIGHTING THE SIDE BURNER:
1. Open lid before lighting side burner.
2. Make sure control knob is in the "OFF" position.
3. Push and turn side burner control knob to the "HIGH" position.
4.Press and turn th control knob to "HIGH" to light burner.
5. If the burner does NOT occur in 5 seconds, turn control knob to "OFF", wait 5 minutes to allow gas
to dissipate and repeat lighting procedure.
6. To turn off, turn each control knob clockwise until it locks in the "OFF" position.
WARNING: If burner does not light or flame is too low, you may have spider or other insect blockage in
burner, or the flow limiting device has been activated. See "Burner Assembly/Maintenance" under Proper
Care and Maintenance, or "Regulator Resetting Procedure" under Connecting LP Cylinder and
Hose/Regulator to Grill.
MATCH LIGHTING THE SIDE BURNER:
1. Open the lid to the side burner before lighting.
2. Make sure control knob is in the "OFF" position.
3. Strike and carefully place a match approximately 1/2" (1 to 2 cra) from the burner.
4. Turn the side burner control knob to the "HIGH" position. The burner should light immediately.
5. If the burner does not light, turn the control knob to "OFF" and wait 5 minutes for gas to dissipate and
repeat lighting procedure.
6. If the burner does not light within the first few attempts of match lighting, there is a problem with the gas
supply. Turn off the gas at the burner and cylinder. DO NOT attempt to operate the grill until the problem is
found and corrected. See "Trouble Shooting" section of this manual.
LIGHTING THE ROTISSERIE BURNER:
1. Open grill hood before lighting rotisserie burner.
2. Make sure control knob is in the "OFF" position.
3. Push and turn the control knob of that burner to the "HIGH" position. Continue to push in control
knob while pressing electronic igniter for 3-5 seconds.
4. Once burner is lit, continue to push and hold control knob for 30 seconds.
5. If ignition does NOT occur in 5 seconds, turn control knob to '"OFF", wait 5 minutes to allow gas
to dissipate and repeat lighting procedure.
6. To turn off, turn each control knob clockwise until it locks in the "OFF" position.
IMPORTANT: DO NOT use back rotisserie burner when main burners are in use.
NOTE' If burner does not light or flame is too Iow, you may have spider or other insect blockage in
burner, or the flow limiting device has been activated. See "Burner Assembly/Maintenance" under
Proper Care and Maintenance, or "Regulator Resetting Procedure" under Connecting LP Cylinder
and Hose/Regulator to Grill.
TO CHECK FOR LEAKS
Make 2-3 fluid ounces of leak detecting solution by mixing one part washing up liquid with 3 parts
water.
Ensure the control valve is "OFF".
Connect the regulator to the cylinder and ON/OFF valve to the burner, ensure the connections are
secure then turn ON the gas.
Brush the soapy solution onto the hose and all joints. If bubbles appear you have a leak, which must
be rectified before use.
Retest after fixing the fault
Turn OFF the gas at the cylinder after testing.
If leakage is detected and cannot be rectified. Do not attempt to cure leakage but consult your gas
dealer.
LIGHTING THE MAIN BURNERS:
1.Open the hood
2. Open lid before lighting burner.
3. Make sure all control knobs are in the "OFF" position.
4. Select the burner to be lit. Push and turn the control knob of that burner to the "HIGH" position.
5.Press and turn the control knob to "HIGH" to light burner.
6. If the burner does NOT occur in 5 seconds, turn control knob to "OFF", wait 5 minutes to allow gas
to dissipate and repeat lighting procedure.
7. Repeat Steps 3-5 for lighting each burner. Always use the control knob for lighting each burner.
8. To turn off, turn each control knob clockwise until it locks in the "OFF" position. This does not turn
off the gas flow from the cylinder.
Position the cylinder as far away form the appliance on the right hand as possible without
stressing the hose.
This barbecue is designed for use outdoors, away from any flammable materials. It is
important that there are no overhead obstructions and that there is a minimum distance of
1 m from the side or rear of the appliance. It is important that the ventilation openings of the
appliance are not obstructed. The barbecue must be used on a level, stable surface. The
appliance should be protected from direct draughts and shall be positioned or protected
against direct penetration by any trickling water (e.g. rain).
Parts sealed by the manufacturer or his agent must not be altered by the user. No
modifications should be made to any part of this barbecue and repairs and
maintenance should only be carried out by a CORGI registered service engineer.
Connection to Appliance
Before connection, ensure that there is no debris caught in the head of the gas cylinder,
regulator, burner and burner ports. Spiders and insects can nest within and clog the
burner/venturi tube at the orifice. A clogged burner can lead to a fire beneath the appliance.
Clean burner holes with a heavy-duty pipe cleaner.
Fit the hose to the appliance using a spanner to tighten it onto the connection thread. If the
hose is replaced it must be secured to the appliance and regulator connections with hose
clips. Disconnect the regulator from the cylinder (according to the directions supplied with
the regulator) when the barbecue is not in use.
The Barbecue must be used in a well ventilated area. Do not obstruct the flow of combustion
air to the burner when the barbecue is in use. ONLY USE THIS BARBECUE OUTDOORS.
Never check for leaks with a naked flame,
always use a soapy water solution
BEFORE USE CHECK FOR LEAKS
