BASIC TROUBLESHOOTING INSTRUCTIONS: JAZZY 614/JAZZY 614HD

WITH DYNAMIC CONTROLLER

Any electromechanical device requires occasional troubleshooting. However, most problems that arise can usu-

ally be solved with a bit of thought and common sense. Many of these problems occur because the batteries are

not fully charged or because the batteries are worn down and can no longer hold a charge. Below are a series of

basic troubleshooting instructions for the Jazzy 614 and Jazzy 614 HD power chairs equipped with Dynamic

controllers. This information is to be used as a supplement to the troubleshooting instructions provided in the

owner’s manual. If you have any questions about this information, contact your authorized Pride Provider.

What if the systems on my Jazzy 614/Jazzy 614HD seem to be “dead” (no lights when the on/off key is pressed)?

Make sure the batteries are installed and wired properly.

Make sure the connections on the battery terminals are tight and secure.

Make sure the battery quick-disconnect harness connections are fully joined.

Make sure the main circuit breaker has not tripped—push in the main circuit breaker reset button.

Make sure the controller is completely connected to the power base.

Why does my Jazzy 614/Jazzy 614HD travel less distance than it used to on a full charge?

Determine if the batteries have ever been replaced. Batteries over a year old might be worn down and less

effective.

Determine how frequently you charge the batteries in comparison to how often you use the power chair.

If you use your power chair on a daily basis, you should charge the batteries overnight for 8-14 hours.

Determine when the batteries were last charged. Even if the power chair has not been in use, the batteries

should be charged at least once a week for 12-14 hours.

Determine how long you let the batteries charge. It takes 8-14 hours to fully charge a depleted set of

batteries; continual undercharging reduces the overall life of the batteries.

Determine if a wall switch controls the electrical outlet used for battery charging. If so, the batteries will

not fully charge if the wall switch is turned off inadvertently.

Is an extension cord being used to connect the battery charger to the electrical outlet? Pride prohibits the

use of an extension cord when charging the batteries. The charger should be plugged directly into a properly

wired standard electrical outlet as the length and condition of an extension cord could have an adverse affect

on the battery charger.

Determine how far you let the battery condition meter LEDs go down before charging the batteries. If

you continually allow the battery condition meter LEDs to fall too low (into the red), the overall life of the

batteries will be reduced.

Determine if the connections on the battery terminals are tight and secure. A loose connection at the

battery terminals can cause a loss of voltage in the system.

Determine if the connections on the circuit breaker are tight and secure. A loose connection at the circuit

breaker can prevent the Jazzy 614/Jazzy 614HD from operating.

Determine if the motor brushes are properly installed and not overly worn (if you have access to the

motor brushes). Missing or worn motor brushes can cause an increased use of voltage while driving.

INFINFB2468/Rev. A/May 2010 www.pridemobility.com 1

2 www.pridemobility.com INFINFB2468/Rev. A/May 2010

What if my Jazzy 614/Jazzy 614HD is operating slower than it has in the past?

Determine the speed at which the chair is set. Check the speed settings.

Determine when the batteries were last charged. When the batteries are low, they supply less power to the

motors; this causes the motors and the wheels to spin at a slower rate.

Determine the temperature of the power chair at the time the problem occurred. What kind of terrain

was the end user driving over? If used outside, how long has it been outside? The Jazzy 614/Jazzy 614HD

electronical system will protect itself from overheating when its internal temperature gets too high by reducing

the amount of power that goes to the motors. When this happens, the Jazzy 614/Jazzy 614HD will gradually

slow down to a stop if the internal temperature is too high. Allow the Jazzy 614/Jazzy 614HD to cool down

and it will resume normal speeds. Try to maintain an even speed and avoid stop-and-go driving, also limit

baggage weight to essential items.

What if my Jazzy 614/Jazzy 614HD begins pulling to one side?

Determine if the joystick is being deflected straight. Even a small amount of deflection right or left will

cause the chair to veer over a long distance.

Determine if the Jazzy 614/Jazzy 614HD has pneumatic tires. If so, are both tires inflated to the proper

pressure? Maintain but do not exceed the psi/bar/kPa air pressure rating indicated on each tire if equipped

with pneumatic tires. If one tire is inflated more than the other, the power chair will pull to the side that is

underinflated.

NOTE: If the tires on your power chair list the psi rating only, use the following conversion formulas to find

the bar or kPa rating: bar = psi x 0.06895; kPa = psi x 6.89476.

Determine if the caster wheels are pivoting freely. If either caster is not pivoting freely, the unit will veer

to the side.

What if my Jazzy 614/614HD makes clicking noises?

Determine if the click happens just one time after the joystick is pressed forward, backward, or side-to-

side. If so, the click is the sound of the brake releasing to allow the motors to turn.

Determine if the click continues while driving the unit. If the unit is new, the customer should continue to

use the unit for a month, then call back if the problem persists.

Determine at what time the noise began. If the unit is new, the customer should continue to use the unit for

a month, then call back if the problem persists.

BASIC TROUBLESHOOTING INSTRUCTIONS: JAZZY 614/JAZZY 614HD

WITH DYNAMIC CONTROLLER

INFINFB2468/Rev. A/May 2010 www.pridemobility.com 3

DYNAMIC CONTROLLER FLASH CODES

Under normal conditions and with the batteries fully charged, the battery LEDs will all be steadily on. Fewer

LEDs imply a reduction to battery charge.

When a fault is detected by the Dynamic controller, the service indicator wrench icon will flash in a numbered

sequence, followed by a 2-second pause. In addition, the battery LEDs will chase from left to right, alternating

with a steady flash.

The Jazzy 614/Jazzy 614HD does not drive and the battery LEDs are chasing from right to left.

The Dynamic controller is in lockout mode. To unlock the controller, press the horn button twice.

The battery LEDs are chasing left to right, alternating with a steady display. When the joystick is moved,

the speed gauge will also flash.

The Dynamic controller is plugged in for charging. The steady display indicates the status of the charge.

Determine if the 4-pin plug is properly plugged into the power module. If not, then the charger inhibit feature

will activate.

The Jazzy 614/Jazzy 614HD does not drive and the battery LEDs are flashing rapidly non-stop.

The Dynamic controller has detected an “Out of Neutral at Power Up” condition. Release the joystick back to

the neutral position.

FLASH CODES CODE # CAUSE POSSIBLE SOLUTION

One, pause, one 1Possible Stall Timeout Turn joystick off, then on.

Two, pause, two 2Battery Fault

Charge batteries, check battery connections and fuses.

Three, pause, three 3Left Motor Fault Make sure the left motor is plugged in.

Four, pause, four 4Right Motor Fault Make sure the right motor is plugged in.

Five, pause, five 5Left Park Brake Fault Make sure the left brake is not in freewheel mode.

Six, pause, six 6Right Park Brake Fault Make sure the right brake is not in freewheel mode.

Seven, pause, seven 7Joystick Fault Check the joystick connection.

Eight, pause, eight 8Power Module Fault Check connections to the power module and batteries.

Nine, pause, nine 9Controller Communi-

cation Fault

Check bus connections from the joystick to the power

module.

Ten, pause, ten 10 Controller Fault Contact Technical Service for assistance.

Eleven, pause, eleven

11 Incompatible Device

Fault Contact Technical Service for assistance.

BASIC TROUBLESHOOTING INSTRUCTIONS: JAZZY 614/JAZZY 614HD

WITH DYNAMIC CONTROLLER
