Prestigio RoadRunner 425 Manual de usuario

Car VideoRecorder

RoadRunner 425

About this user manual

This user manual is specially designed to detail the device’s functions and features.

1. Please read this manual before using the device to ensure safe and proper use.

2. Descriptions are based on the device’s default settings.

3. Prestigio continuously strives to improve its products. Due to software upgrading,

some contents in this user manual may be different from your product. Prestigio

reserves the rights to revise this user manual or withdraw it at any time without

prior notice. Please take your product as standard.

Conventions used in this manual

In this user manual, we use the following symbols to indicate useful and important information:

Caution: provides safety precaution and important information.

Note: gives additional information.

Tips: usage tips.

> The order of options or menus you must select to performa step.

Contents

Unboxing .................................................................................. 1

Inside your package...........................................................................................................................1

Device overview ...................................................................................................................................1

Getting started......................................................................... 2

Insert a microSD card ....................................................................................................................... 2

Install the suction mount..................................................................................................................2

Charge the battery ..............................................................................................................................3

Settings..................................................................................... 4

General settings..................................................................................................................................4

Recording ................................................................................. 5

Record a video .................................................................................................................................... 5

Take a picture........................................................................................................................................5

Record a sound.................................................................................................................................... 5

File management ......................................................................6

Browse files............................................................................................................................................ 6

Delete a file.............................................................................................................................................6

Lock and unlock a file......................................................................................................................... 6

Playback..................................................................................... 7

Play video on DVR.................................................................................................................................7

Playback on PC....................................................................................................................................... 7

Specifications .............................................................................8

User Manual RoadRunner 425

Car video recorder Car charger Quick start guide

Suction mount USB cable

Device overview

9 10

1 4 12

5 6 7 8

Lens 7. Down/Photo capture button

Power on/off 8. REC/OK

SD slot 9. Recording LED light (RED)

LCD screen 10. Power supply LED light (BLUE)

Menu/SOS 11. USB slot

Playback/Up/Mic 12. RESET

1.Unboxing

Inside your package

User Manual RoadRunner 425

Insert a microSD card

Before starting video recording, please insert a microSD card (not included) into the slot until it locks

in place.

The device will automatically recognize it as default storage and all the data will be

saved on this card.

Install suction mount

•Follow the arrow pointing direction to insert the suction mount and lock the device

into its holder

•Remove the protection paper from the suction mount, and position the device

on the clean windshield or dashboard.

2. Getting

started

starstarted

User Manual RoadRunner 425

Charge the battery

Before using the device for the first time, please fully charge the Li-ion battery. The battery will

be completely charged in 1-2 hours.

•Using the car charger: charge the device through cigarette lighter. The device will start

charging after the car engine is turned on.

•Using micro USB cable: connect the device to AC 5V adapter or the USB port of a

computer/laptop.

3. Settings

Before recording, you can set up the device according to your

requirements.

- In video/picture preview mode, press [MENU] to enter video/picture settings,

press [OK] to go the general settings, press return button to exit.

- In setting list, use [ ]/ [ ] to navigate the menu, press [OK] to get the

options and confirm the selection, press [MENU] to exit.

General Settings

Resolution: Select the resolution of recorded video: FHD 1080P 30fps / HD720P 30fps

Record cycle: Set the video duration (1, 3, 5 minutes or off) for loop recording. When the micro

SD card is full, the device will delete the oldest unlocked video files automatically.

Motion Detection: Turn on or off motion detection.

Record audio: Turn on or off audio.

Video Stamp: Set Date and time/Brand/Model name/Car plate in video.

Car Plate: Set the car number.

G-Sensor setting: High/ Medium/Low

Select the sensitivity of the G-sensor. The smaller the number is, the higher the sensitivity is. When

reaching the sensitive value (such as collision), the recording file will be automatically protected.

Park mode: Off/On

Parking monitor function is triggered by the G-sensor in the unit. When G-sensor is OFF, the

parking monitor and CPU will not work. When it is ON, unit will be switched to Parking Monitor

Mode after shutting off.

Frequency: 50Hz/60Hz

Exposure: Select from EV -3, -2, -1, 0, 1, 2, 3. Set exposure value to determine how much light the

camera’s sensor receives. For low light situations, use a higher exposure.

Date and Time: Set the current data and time.

Auto Power Off: Off/1min/3min/5min, once setting the time, the device will power off

automatically If there is no operation to the device.

Beep Sound: Turn on and off the button sound.

Volume: Low/Medium/High

Language: choose the multi-languages.

LCD OFF: off/30sec./1min/2min, after setting, the LCD will turn off automatically, press any button

to wake it up.

Power Off Delay: off/10sec./30sec./60sec. After setting, the device will delay the power off to

save more video after packing to avoid any last video broken.

Format: Format the memory card. Formatting will erase all your stored data. Back up your data

before proceeding.

Reset settings: Restore to default settings.

Version info: Display the current system version.

User Manual RoadRunner 425

Record a video

Auto video recording

Connect the device to car charger, when the car engine launches, the device will automatically

turn on and start loop video recording. When shut off the car engine, the device will save the

last file and turn off.

Manual video recording

In recording mode, press [ ]/Stop button to start and stop video recording.

Record the sound

In recording mode, short press [ ]/ to turn on or off the sound.

Speaker sound

In recording mode, long press [ ]/ to turn on or off the speaker.

Emergency video recording

During recording, press [ ] to make urgent recording and lock current loop video.

4. Recording

User Manual RoadRunner 425

In video preview mode, press [ ] /Playback button to enter into playback mode.

Press [OK] to play the videos.

Press [ ]/[ ] to scroll through the files.

Delete a file

In playback mode, press [MENU] to enter the delete file menu. Press [ ] / [ ] to

choose toDelete current file or all files.

Lock and unlock a file

In playback mode, press [MENU] to enter the delete file menu. Press [ ] / [ ] to

choose toLock or unlock current file.

\ 5. File management

Browse files

User Manual RoadRunner 425

- Press [ ]/playback button to enter video playback mode.

- Press [OK] to start/Pause playback.

- Press [Return]/ again to exit playback mode.

Playback on PC

1. Remove memory card from DVR and insert it into computer’s card reader. (DVR’s USB port data

transmission OFF: for charging purpose only)

2. Connect DVR to PC

(DVR’s USB port data transmission ON: for charging and data transmission)

There are two versions for DVR’s port, please choose a method according real function

6. Playback

Play video on DVR
