Prestigio MultiPhone PAP5044 DUO Manual de usuario

PAP5044 DUO EN - 1

Quick Start Guide

Prestigio MultiPhone

PAP5044 DUO

1. Packing List

1. Prestigio MultiPhone

2. AC Adapter

3. Earphone

4. USB Cable

5. Quick Start Guide

6. Warranty Card

7. Legal and Safety Notices

8. Battery

2. Device Overview

3. Uninstalling the back cover and battery

Uninstalling the back cover: hold the side of device tightly with one hand and lift up the back cover at its buckle

with the other hand.

Vol +\ Vol - Button

Adjust the volume level

Earphone Jack

Earphones connection.

USB port

Micro USB cable connection.

Display menu options.

Back

Back to the previous page.

Home

Back to the Home screen.

Power

Turn on/off the device;

Suspend/Activate the device.

Camera

Take photos.

Speaker

Listen to phone calls or music.

EN - 2 PAP5044 DUO

Quick Start Guide

Prestigio MultiPhone

PAP5044 DUO

Taking out the battery: hold the side of device tightly with one hand and pull up the battery handle with the other

hand.

4. Installing the SIM cards and Micro SD card

a. Insert SIM cards

The slot on the right is card 2 slot for GSM card, the left is card 1 slot for 3G WCDMA card (compatible with 2G

card).

PAP5044 DUO EN - 3

Quick Start Guide

Prestigio MultiPhone

PAP5044 DUO

Please make sure the gold contact area on the SIM is facing downwards.

b. Insert Micro SD card

To insert a Micro SD card, place the card connector towards the front side of the device and

the printing side of the card towards the rear side of the device.

To remove the micro SD card, pull the card out of the slot.

5. Charging

Insert one end of USB cable into the USB port on the

device and plug the power adapter to the electrical socket.

Normally it takes approximately 3.5 hours to fully charge the device. Operating the device

while charging with the AC adapter may extend the charging time.

Notice: If you don’t use your phone for a long time, it will gradually discharge. Please charge it first before your

next use or charge the phone every 3 months even you don’t use it.

6. Power on/Sleep Mode/Power off

Press and hold the Power Button for a few seconds. It will automatically enter the Home screen after start-up

screen.

Press the Power Button once to enter sleep mode and press it again to awake the device.

Press and hold the Power Button, and then tap on Power off to power off the device or to enter sleep mode.

EN - 4 PAP5044 DUO

Quick Start Guide

Prestigio MultiPhone

PAP5044 DUO

Technical Specifications

Processor

5.0"HD Quad Core 1.2GHz

Memory

eMMC 4GB＋DDR2 1GB, Micro SD slot supports up to 32GB

Android 4.2 (Jelly Bean)

Display

5" HD720p, Capacitive multi-touch

Resolution

1280*720

Band

WCDMA + GSM (UMTS:900/2100MHz; GSM:850/900/1800/1900MHz)

Interfaces

Communications

Battery

USB 2.0, Micro SD (micro SDHC compatible)

WiFi (802.11 b/g/n), 3G

2000 mAh Li-Poly battery

Dimensions

142.9*72.9*8.4 mm (L x W x H)

Weight

100g(without battery)

PAP5044 DUO EN - 5

Quick Start Guide

Prestigio MultiPhone

PAP5044 DUO

As the Prestigio products are constantly updated and improved, your device’s software and hardware may have a

slightly different appearance or modified functionality than presented in this Quick Start Guide.

Prestigio hereby states that this Smartphone complies to basic requirements and another relevant regulations given

by the EU directive1999/5/ES. Full version of the declaration of conformity is available on

http://www.prestigio.com/certificates
