Precision Power PH.10 Manual de usuario

2012 PHANTOM

SUBWOOFERS

PH.10 PH.12 PH.15

Thank you for choosing PrecisionPower woofers. Designed and engi-

neered in the USA, this product combines innovative technology with

the finest materials to consistently deliver Absolutely State of the Art

performance, sound quality, reliability, and value. This PrecisionPower

product reflects our commitment to offer you unparalleled perfor-

mance and quality for years of dependable service and listening en-

joyment.

Non Pressed Paper Pulp Cone

High Roll Foam Surround

2.0” 4-layer VC on Aluminum Former

Nickel Plated 8ga. Compression Terminals

Poly-Cotton Suspension Spiders

Stamped Steal Frame

Vented T-Yoke Back-plate

Woven Fiber dust cap

Features, Parameters, & Dimensions

Impedance dual 2ohm dual 2ohm dual 2ohm

Re2.2009 2.2655 2.2110

Fs(hz) 39.12 33.17 25.17

Qes 1.3808 1.5087 1.2924

Qms 6.7067 7.0376 3.7318

Qts 1.1451 1.2424 0.9559

le(mh) 0.9689 0.9656 1.0144

dIameteR 10Inch 12Inch 12Inch

sd78.5398 In^2 113.0973 In^2 176.7146 In^2

Vas (l) 30.4636 64.8921 163.3262

Bl8.8105 9.1637 11.0581

sen 82.9 83.7 84.7

Rms/max 720/1800 850/2000 1000/2200

cutout dIam 9.6Inch 11.6Inch 14.5Inch

mountIng depth 5 5/8 Inch 6 Inch 6 7/8 Inch

ph.10 ph.12 ph.15

Enclosure Construction

Enclosure Dimensions

Enclosure Recommendations

Included in this manual are a number of different enclosure sugges-

tions. These are by no means the only enclosures to use, but they

provide a starting point to determine the correct enclosure for your

needs many factors must be addressed (amount of power, vehicle,

placement, crossovers, etc) Therefore, as always, PrecisionPower

recommends that your subwoofer be installed by an authorized Pre-

cisionPower dealer.

All enclosures should be made of .75” (3/4”) material only. When pos-

sible, make the baffle 1.5” (1 ½) thick and add .75” (3/4”) to the depth

of the enclosure to compensate. All volumes INCLUDE vent/port and

subwoofer displacements. DO NOT change the volume unless you

plan on adding a substantial amount of bracing. For added per-

formance, applying a coat of fiberglass resin to the interior walls will

greatly improve sealing the enclosure. Adding a thin layer of poly-fill

will improve response by smoothing out reflections within the enclo-

sure.

sealed ph.10 ph.12 ph.15

mIn .75cu Ft. 1.0cu Ft. 1.5cu Ft.

optImum 1.0cu Ft. 1.5cu Ft. 2.5cu Ft.

poRted

mIn 1.0cu Ft. 1.5cu Ft. 2.5cu Ft.

poRt Wxl 3Inch x5.5Inch 4Inch x5Inch 5Inch x7.8Inch

F3 (hz) 34 38 30

optImum 1.5cu Ft. 2.25cu Ft. 2.75cu Ft.

poRt Wxl 4Inch x6Inch 6Inch x7Inch 6Inch x7Inch

F3 (hz) 32 34 28
