PRO35 Image Converter
1
Support systems for use with the PRO35 Image Converter
There are four possible solutions, explained in the following:
1. 15mm light weight support (by default delivered with the PRO35)
– for use with normal (prime) lenses
– for attachment of 15mm light weight accessories
2. 15mm light weigth support (ARRI based)
3. 19mm heavy duty support – Chrosziel based
– for use with heavy lenses (i.e. zoom lenses)
– for attachment of 19mm movie accessories
4. 19mm heavy duty support – ARRI based
– for use with heavy lenses (i. e. zoom lenses)
– for attachment of 19mm accessories
Support bridges to adapt from 19mm ligth weigth support to 15mm heavy duty support are
available as well:
Cables and general accessories
22612 PRO35 power supply cable for “Lens” connector
(Hirose 12-pin/ Fischer 7-pin, angled connector) (with twist protection MK II)
19142 PRO35 power supply cable Anton Bauer 2-pin (with twist protection MKII)
19143 PRO35 power supply cable Digibeta Hirose 4-pin (with twist protection MKII)
19144 PRO35 power supply cable XLR 4-pin (with twist protection MKII)
19187 PRO35 power supply cable XLR 5-pin (with twist protection MKII)
19188 PRO35 power supply cable “open end” (with twist protection MKII)
20449 RS switch ON/OFF (to use with MINI35 and PRO35)
21067 RS switch holder complete (incl. RS switch holder, Cmotion fastener,
RS extension cable 0,8m)
21065 RS extension cable, 0,8m
19710 PRO35 support bridge for 19mm to 15mm rods
19715 PRO35 support bridge for 15mm to 15mm rods
