POWERVAR

Grounding Technology Solutions

Uninterruptible Power Manager

For use with ABCEG251, ABCEG401, and ABCEG601

2GTS Series Uninterruptible Power Manager

1.0 - Introduction ...................................................................... 5

2.0 - Safety Instructions............................................................ 9

3.0 - Installation........................................................................12

4.0 - Operation ........................................................................16

5.0 - Maintenance ...................................................................24

6.0 - Specications ................................................................. 29

7.0 - Troubleshooting ..............................................................35

8.0 - Warranty ......................................................................... 37

TABLE OF CONTENTS

3GTS Series Uninterruptible Power Manager

IMPORTANT NOTICE ON BATTERY WARRANTY

The warranty policies stated in Sections 1 and 8 are not valid

for applications in which the UPM is regularly and intentionally

disconnected from AC mains power. POWERVAR’s two year battery

warranty applies only to products that are properly installed and

consistently connected to AC mains power, except during utility

outages.

Products regularly and intentionally disconnected from AC

mains power will experience substantially reduced battery life.

Notwithstanding the stated warranty in Sections 1 and 8.

POWERVAR’s standard warranty term does not apply in these cases

and is supplanted by a 90 day warranty from time of shipment from

POWERVAR. The warranty provided by POWERVAR provides for

the replacement of the battery or battery systems in the event that

the batteries do not meet performance specications as determined

by POWERVAR exclusively.

4GTS Series Uninterruptible Power Manager

Danger- The danger symbol is used to indicate

imminently hazardous situations, locations, and

conditions which, if not avoided, WILL result in death,

serious injury, and/or severe property damage.

Attention- The attention warning symbol is used

to indicate situations and conditions that can cause

operator injury and/or equipment damage.

Caution- The caution symbol is used to indicate

potentially hazardous situations and conditions which,

if not avoided, may result in injury. Equipment damage

may also occur.

Warning- The warning symbol is used to indicate

potentially hazardous situations and conditions which,

if not avoided, COULD result in serious injury or death.

Severe property damage COULD also occur.

Other warning symbols may appear along with the

Danger and Caution symbol and are used to specify

special hazards. These warnings describe particular

areas where special care and/or procedures are

required in order to prevent serious injury and possible

death.

Electrical warnings- The electrical warning symbol

is a lightning bolt mark enclosed in a triangle. The

electrical warning symbol is used to indicate high

voltage locations and conditions may cause serious

injury or death.

Explosion warnings- The explosion warning symbol

is an explosion mark enclosed in a triangle. The

explosion warning symbol is used to indicate locations

and conditions where molten, exploding parts may

cause serious injury or death if the proper precautions

are not observed.

DANGER

CAUTION

WARNING

ATTENTION

5GTS Series Uninterruptible Power Manager

1.0 INTRODUCTION

Thank You

Choosing a power quality solution for your sensitive equipment can

be a daunting task. That’s especially true when it comes to selecting a

product that delivers uninterruptible power, since there are so many on

the market from which to choose. Everyone at POWERVAR thanks you

for selecting a POWERVAR power quality solution for your application.

We understand that your decision was a careful one and that your

purchase of a POWERVAR product is an expression of condence in our

company. We promise to always work our hardest to make certain that

your condence in our products and our company is well deserved.

Thank You!

The GTS product you have purchased is the most advanced solution

available today. It does so much more than provide backup power for

your application. In fact, it’s so advanced that it actually serves as a

comprehensive management interface between your computer system

and its supply of electrical power. That’s why we refer to the GTS as an

Uninterruptible Power Manager or UPM.

We’ve prepared this document to help familiarize you with the functions

and controls of the GTS Series UPM family. If, after reviewing this

manual, you have any questions at all, please feel free to contact us by

phone (1-800-369-7179) or email us at servicerma@powervar.com

Registering your UPM Purchase

Please take a few moments to register your product purchase.

Registration is quick and easy via the product registration page found on

our website at www.powervar.com.

6GTS Series Uninterruptible Power Manager

General

The POWERVAR GTS Series UPM systems are the most advanced, line

interactive, true sinewave UPS products available for your application.

Each model is designed to provide total protection for your system from

a complete range of power quality problems. GTS Series UPM systems

will protect your installation from normal mode voltage impulses,

electrical noise, sags and surges, brownouts, and blackouts. Each GTS

Series UPM contains a low impedance isolation transformer, which

completely eliminates common-mode (neutral-to-ground) voltages that

are a constant threat to the reliable operation of microprocessor-based

systems. When AC power is present, GTS Series constantly lters and

conditions the power supply. When AC power fails, the GTS Series

uses its internal, maintenance-free battery to supply reserved power to

your computer system. Regardless of whether or not commercial power

is present, the GTS Series is constantly on the job, ensuring a fully

conditioned, safely managed interface between your computer system

and its electrical power supply. Figure 1 illustrates the basic operation of

the GTS Series UPM.

Figure 1

7GTS Series Uninterruptible Power Manager

Sinewave Output

The output voltage of all GTS Series UPM models is a true, low distortion

sinewave – the kind that the utility company provides to the wall outlet

and the kind that your equipment is designed to work with. This provides

guaranteed compatibility even with the most sensitive electronic loads.

Voltage Manager

The voltage of the AC power source can often uctuate from its nominal

rating. These deviations in line voltage are tolerated quite well by most

switch mode power supplies (the type used in your computer system).

However, some UPS products may misinterpret these transient changes

in line voltage as a power outage and erroneous battery operation may

occur. This type of activity results in unnecessary strain on the battery

and may eventually shorten its life. POWERVAR’s GTS Series UPM

products feature Voltage Manager – a circuit that constantly monitors

the AC power source. If minor changes in AC voltage occur, the Voltage

Manager adjusts the input voltage to the UPM circuitry so that erroneous

inverter operations are avoided. Ensuring that the UPM switches to

its batteries only in the event of a true power outage, results in longer

battery life and a lower cost for both maintenance and ownership.

Start Manager

Start Manager is special circuitry that enables the internal batteries

and allows you to start the GTS Series UPM from either the main AC

supply or from its own internal battery. On occasion, AC power may not

be available – such as when installing a system in a location where the

electrical wiring has not been completed. Start Manager allows you to

start the UPM and its connected system to perform nal tests on both the

UPM and the computer systems it’s powering.

8GTS Series Uninterruptible Power Manager

MopUPS Express

POWERVAR GTS Series smart communications give you several

options for:

• Protecting data on a computer powered by GTS when battery runs low

• Monitoring the GTS to allow analysis of site power history and GTS

health

An RJ11 port provides a standard basic-signal interface that works with

Legacy and open source UPS monitoring software to trigger automated

computer shutdown on low battery conditions.

The smart USB port links your GTS Series directly in to Windows, Linux

or MAC OS as an HID device -- without need for additional USB device

drivers. Use native OS Power Management utilities for automatic safe

shutdown on low battery.

If you want added functionality including; data and event logging, auto-

run command les before shutdown, access to GTS conguration

and integrated network agent for central monitoring via POWERVAR

ManageUPS®CIO Server software, download and use POWERVAR

software MopUPS®Express (Windows only)

(See page 18 for more information)

User Replaceable Battery

Eventually every UPM requires a new battery. POWERVAR expects

the battery in your GTS Series UPM to last a minimum of two years

– perhaps longer if power outages are short and infrequent. The GTS

Series makes battery replacement by the user fast and easy. It is not

necessary to turn off the UPM or the connected system. The GTS Series

allows the battery to be “hot-swapped” while the system is running.

9GTS Series Uninterruptible Power Manager

2.0 SAFETY INSTRUCTIONS

IMPORTANT - SAVE THESE INSTRUCTIONS

THIS MANUAL CONTAINS IMPORTANT SAFETY INSTRUCTIONS.

KEEP THIS MANUAL HANDY FOR REFERENCE.

CAUTION

A battery can present a risk of electrical shock. Short-circuit currents

can be extremely high and can create severe burns as well as the risk of

re or explosion from vented gases. Always observe proper precautions.

When replacing batteries, use the same quantity, rating and type of

batteries used by POWERVAR. The batteries used in this UPM are

sealed lead-acid and are maintenance free. Proper disposal of batteries is

required. Refer to your local codes for disposal of batteries.

CAUTION

• This UPM contains voltages which are potentially hazardous. All

repairs should be performed by qualied service personnel.

• To reduce the risk of re, connect only to a circuit provided with

20 amperes maximum branch circuit over-current protection in

accordance with the National Electric Code, ANSI/NFPA 70.

• The UPM has its own internal energy source (battery). The output

receptacles of the UPM may be live even when the UPM is not

connected to an AC Supply.

Safe and continuous operation of the UPM depends partially on the care

taken by users. Please observe the following precautions. (Not following

these could result in warranty being voided).

10 GTS Series Uninterruptible Power Manager

NOTE:

• Do not disassemble the UPM.

• Do not attempt to power the UPM from any receptacle except a properly

grounded receptacle that matches the input plug provided with the UPM.

• Do not place the UPM near water or in environments of excessive humidity.

• Do not allow liquid or any foreign object to get inside the UPM.

• Do not block air vents on the side of the UPM.

• Do not plug appliances such as hair dryers, fans, heaters, etc. into

the UPM.

• Do not place the UPM under direct sunlight or close to heat emitting

sources (excessively warm temperatures will shorten battery life).

• This UPM is intended for installation in a temperature controlled,

indoor area free of conductive contaminants.

• The AC power supply for the UPM should be conveniently near the

UPM and easily accessible – avoid extension cords or temporary

power strips to power the UPM.

• The total leakage current of the UPM and consumer connected

equipment should not exceed 3.5 mA.

• Not for use in a computer room as dened in the Standard for the

Protection of Electronic Computer/Data Processing Equipment, ANSI/

NFPA 75.

• The socket-outlet shall be installed near the equipment and shall be

easily accessible.

• The battery should be disconnected from the UPM by unplugging at

its quick connectors when maintenance or service work inside the

UPM is necessary.

• Do not dispose of batteries in a re – batteries may explode.

• Do not open or mutilate batteries. Doing so may release electrolyte or

other toxic substances, which may be harmful to the skin, eyes, or the

environment. A battery can present a risk of electric shock and high

short circuit current. The following precautions should be observed

when working with batteries:

• Remove watches, rings, or any other metal jewelry or objects which

may make contact with the battery.

• Use tools with insulated handles.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unión Postal Universal de Powervar

Powervar

Powervar GTS Series Manual de usuario

Powervar

Powervar ACDEF6000-22 Manual de usuario

Powervar

Powervar AMETEK 3300 Series Manual de usuario

Powervar

Powervar Security Plus Manual del operador

Powervar

Powervar ACE Series Manual de usuario

Powervar

Powervar ACDEF700-11 Manual del operador

Powervar

Powervar 3200 Series Manual de usuario

Powervar

Powervar ACE400 Manual de usuario

Powervar

Powervar 600-1000-1500-2000 VA Manual de usuario

Powervar

Powervar Ace Plus Series Manual de usuario

Powervar

Powervar SG3K-2TXI Manual de operación

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario
