5GB/IE
Introduction
Intended Use ............................................................Page 6
Description of parts..................................................Page 7
Technical Data .........................................................Page 7
Includes.....................................................................Page 8
Safety
General Safety Information.....................................Page 8
Battery Safety Instructions........................................Page 10
Before Initial Use
Inserting the Batteries (Figure C).............................Page 11
Attaching the repair device .....................................Page 12
Mounting the magnifying glass...............................Page 12
Use
Using the Precision Engineer’s LED
Magnifying Glass ....................................................Page 12
Changing the Batteries ............................................Page 13
Troubleshooting .............................................Page 13
Cleaning and Maintenance...................Page 14
Disposal.................................................................Page 15
Table of Contents
66454_pow_Feinmechaniker_LED_Lupe_content_LB3.indd 5 25.05.11 17:34
6 GB/IE
Introduction
Precision LED Magnifying Glass
Introduction
The instructions for use are to be considered as part
of the product. They contain important information
concerning safety, use and disposal. Before using
the product, please familiarise yourself with all of the safety
information and instructions for use. The product must only be
used as described and for the stated fields of application. If
you pass the product on to third parties, please give them all
of the documentation as well.
Intended Use
The product is intended for the optical magnification of objects
and is equipped with LED lamps. In addition, the product has
2 fixing clamps and a soldering iron holder. Other uses or
changes to the product are considered to be contrary to the
intended use and may harbour risks of injury and damage.
The manufacturer does not accept any liability for injury or
damage resulting from use of this product contrary to its
intended use. The product is not intended to be used for com-
mercial purposes.
66454_pow_Feinmechaniker_LED_Lupe_content_LB3.indd 6 25.05.11 17:34
7GB/IE
Introduction
Description of parts
1Precision engineer’s LED magnifying glass
2Lens (magnification 2.5/5 times)
3Battery compartment cover
4Battery compartment
5Ball joint
6Retaining screw (lens ball joint)
7Magnifying glass fixing clamp
8Retaining screw (magnifying glass height adjustment)
9On/off switch
10 Supporting rod (height adjustment)
11 Fixing clamp (repair device)
12 Retaining screw (repair device height adjustment)
13 Soldering iron holder
14 Base
15 Repair device
16 Retaining screw (repair device ball joint)
17 Retaining screw (repair device)
18 Alligator clips
19 Retaining screws (alligator clips)
20 LED lamps (Fig. B)
21 Batteries (Fig. C)
Technical Data
Operating voltage: 4.5 volts
Batteries: 3 x 1.5V , AAA type
Max. power rating: 2x 0.06W
66454_pow_Feinmechaniker_LED_Lupe_content_LB3.indd 7 25.05.11 17:35
8 GB/IE
Introduction/Safety
Bulbs: 2x LED (not replaceable)
Magnification/
magnifying glass: 2.5/5 times
Dimensions:
Includes
Immediately after unpacking please check the package con-
tents for completeness and if all parts and the product are in
good condition. Do not under any circumstances use the
product if the delivery is incomplete.
1 Precision engineer’s LED magnifying glass
3 Batteries, 1.5V , AAA
1 Operating Instructions
Safety
General Safety Information
KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN
A SAFE PLACE FOR FUTURE REFERENCE!
DANGER OF DEATH
AND ACCIDENTS FOR TODDLERS AND
CHILDREN! Never leave children unsupervised
with the packaging material. The packaging material
66454_pow_Feinmechaniker_LED_Lupe_content_LB3.indd 8 25.05.11 17:35
9GB/IE
Safety
represents a danger of suffocation. Children frequently
underestimate the dangers. Always keep children away
from the packaging material. This is not a toy.
Children or other individuals who do not know or have
no experience of handling this device, or whose physical,
sensory or mental abilities are restricted, must not use the
device without supervision or instruction by an individual
responsible for their safety. Children must be supervised
in order to ensure that they do not play with the device.
CAUTION! RISK OF INJURY! Please do not use this
device if you find that it is damaged in any way.
Check whether all of the parts are correctly fitted. If the
device is not correctly assembled there is a danger of
injury.
Keep the product away from humidity.
CAUTION! RISK OF EYE INJURIES! Never look
through the precision engineer’s LED magnifying glass
into the sun or other sources of light. Severe eye injuries
may be the result.
CAUTION! DANGER OF FIRE! Never
expose the precision engineer’s LED magnify-
ing glass to direct sunlight or other sources of
light. Never leave the product unattended. Otherwise
there is a danger of fire resulting from concentrated rays
of light and concentrated heat.
The product must be stored in a dark environment.
Do not subject the device to any extreme temperatures or
severe mechanical stress. Otherwise this may result in
deformation of the product.
66454_pow_Feinmechaniker_LED_Lupe_content_LB3.indd 9 25.05.11 17:35
10 GB/IE
Safety
Make sure that the lens 2does not come into contact
with sharp or pointed objects. Otherwise this may result
in damage to the product.
Do not leave the soldering iron unattended if the device is
switched on. The soldering iron holder 13 is only suitable
for holding the soldering iron for a limited time.
Battery Safety Instructions
DANGER TO LIFE! Keep batteries out
of the reach of children. Do not leave batteries lying
around. There is a risk of children or animals swallowing
them. Consult a doctor immediately if a battery is swal-
lowed.
EXPLOSION HAZARD! Never recharge
nonrechargeable batteries, short-circuit
and/or open batteries. This can cause them
to overheat, burn or burst. Never throw batteries into fire
or water. The batteries may explode.
Remove spent batteries from the product immediately.
Otherwise there is an increased risk of leakage.
Always replace the three batteries at the same time and
only use batteries of the same type.
Do not use different types of batteries or mix used and
new batteries together.
Check regularly that the batteries are not leaking.
66454_pow_Feinmechaniker_LED_Lupe_content_LB3.indd 10 25.05.11 17:35
