Power Plus Mobility Horizon Manual de usuario

POWER PLUS MOBILITY

1214 Kamato Road, Mississauga, Ontario, L4W 1Y1

Tel: (905) 614 0333 Toll Free (855) 614 0333 Fax: (905) 614 0435

WWW.POWERPLUSMOBILITY.COM

Valued Customer,

Thank you for purchasing a Power Plus Mobility product.

At Power Plus Mobility we manufacture top quality

“Canadian Made” products. Your wheelchair should

provide you with many years of service, but like any piece

of equipment, it will require proper care and service for it

to perform efficiently.

Your satisfaction is necessary and important to us and we

want to guarantee it.

However we suggest you regularly inspect your chair,

checking for loose fasteners, excess play and damage. We

also strongly recommend that regular maintenance be done

by your servicing dealer.

Please complete your “Warranty registration card” and

return it to us at Power Plus Mobility.

Also please read this manual to help you understand the

proper operation, safety and maintenance of your new

chair. If you have any difficulties or require additional

information contact your dealer or our customer service

department at Power Plus Mobility.

LIMITED WARRANTY

Power Plus Mobility guarantees all parts of our wheelchair to be

free of defects in workmanship and materials for a period of two

years from the date of purchase. “Wear” items such as tires,

tubes, armpads and upholsteries are excluded from this warranty.

In addition the frame is guaranteed to be free of defects in

workmanship and material (to the original owner) for a period of

5 years.

This warranty is invalid if the chair has been damaged by

accident, misuse, neglect, improper application, unauthorized

service repair or the addition of non-factory approved

accessories.

Power Plus Mobility will repair or replace defective parts as

required. A return authorization must be obtained and the parts

returned to us freight prepaid, within the warranty period.

Labour and freight charges incurred for replacements or repairs

are not covered.

MAINTENANCE GUIDE

Your wheelchair is designed to give you many years of trouble-free

use with proper care. Some servicing can be done at home, but we

recommend that periodic maintenance be performed at your dealer.

Service frequency depends strongly on the type of use and your

dealer can best advise you on the time interval.

CLEANING

All chrome or powder coated parts can be cleaned with a mild

non-abrasive cleaner such as window cleaner. Stubborn spots or

rust can be removed with automotive chrome cleaner.

The arms and nylon upholstery should be cleaned with a mild soap

and water solution. Both should be rinsed well with clean water to

remove all soap residues. The molded wheels and casters should

also be cleaned with a mild soap and water solution.

LUBRICATION

Your wheelchair has been made with low friction plastic,

chromoly, aluminum and polished chrome to reduce friction and

wear. However a light use of thin lubricant, such as WD40 or

silicone spray will reduce friction and wear, making your chair

easier to use.

SAFETY AND HANDLING

The safe handling of your chair depends on understanding the

purpose and function of your particular wheelchair model.

Recognizing the chairs’ limitations will increase your confidence

level.

LEANING

Leaning should be avoided when possible, as this weight transfer

will reduce your chair’s stability. When leaning forward or

sideways make sure the casters are turned in the direction you are

leaning as this will lengthen the wheel base, increasing stability.

Also make sure the wheel locks are engaged, to prevent your chair

from rolling.

MANOUVERING RAMPS, CURBS, STAIRS

Lean forward in chair, putting weight over front casters when

going up inclines. When going on descending inclines do so slowly

by controlling your speed using the handrims and not the wheel.

To mount a curb use the tipping method, pull the chair backwards

and over the curb. To descend a curb do your tipping and either

pull yourself down backwards or roll yourself forward and down

very slowly.

It is a definite no-no to use your chair on an escalator, find the

nearest elevator instead. Going up or down stairs should be done

with at least two attendants at all times.

TRANSFERRING IN A WHEELCHAIR

Attendant assistance is recommended to stabilize the chair and

help in lifting you, if necessary. Transfers are best accomplished by

following these guidelines:

Use a chair with detachable or flip back arm.

Position your chair as close as possible to the transfer object and

engage your wheel locks to prevent movement.

Try to transfer to objects of the same height or close to.

Maintenance and inspection

If the cleaning and safety notices provided are observed, the product will be

maintenance free.

▸Check product regularly for damage and to ensure that it is securely assembled.

▸In the event of damage and/or likely repairs, contact the dealer immediately.

The product must be checked by an authorized dealer before every re-use or after 24

months at the latest .

Cleaning and disinfection

The product can be cleaned and disinfected using commercially availa- ble agents.

▸Disinfect the product by wiping down all generally accessible surfaces with

disinfectant (after disassembling the product, if possible).

Shower Commode Cleaning in a domestic environment

1. Remove any accessories fitted.

2. Pull the footrests out.

3. Remove the seat cover.

4. Remove any accessories,

5. Reinsert the clips in the seat frame immediately so that they are not misplaced.

6. Wash the individual parts using a cloth or brush and commercially available

cleaning agents and disinfectants.

7. Rinse the parts with warm water.

8. Dry the parts with a cloth.

9. Re-assemble the product,

see Section 4 „Assembly and installation“.

Cleaning in a hospital environment

1. In addition to cleaning as described above, clean the product at regular intervals at

85 °C for 3 minutes in the autoclave.

Cleaning the backrest cover (optional)

Remove the backrest cover.

Wash the cover in a washing machine at max. 60 °C using a mild detergent.

!IMPORTANT Risk of damage

▸Do not disassemble the brackets for the accessories.

!IMPORTANT

In the sensitive area of the bathroom, hygiene is particularly important.

▸Keep the product clean at all times and wash it regularly.

CAUTION Risk of burning your skin

Allow the product to cool after cleaning in the autoclave.

!IMPORTANT

All cleaning agents and disinfectants used must be effective, compatible

with one another and must protect the materials they are used to clean..

▸Clean by hand.

▸Clean without scouring agent.

!IMPORTANT Risk of damage

▸Washing at high temperatures can cause shrinkage. ▸Do not dry

covers in the tumble dryer.

STORAGE

WARNING

Risk of accident due to incorrectly fitted wheels.

The wheels must be replaced by a specialist dealer.

IMPORTANT

Risk of damage

▸Store the product in a dry area at a temperature of between 0 °C and 40 °C,

air pressure of 860 - 1060 hPa and humidity of 30 - 75%.

▸Do not store the product near heat sources.

▸Keep the product out of direct sunlight.

RE-USE

The product is suitable for repeated use. The number of times it can be used

depends on how often and in which way the product is used. Before reuse,

clean and disinfect the product thoroughly and check the safety functions, and

reset if necessary.

DISPOSABLE

The disposal and recycling of used devices and packaging must comply with

the applicable legal regulations.

Please refer to the manufacturer for details of the proper and complete

disposal.

CASTERS

Your casters have two kinds of lock available on it, the

directional lock and the positive lock. You will notice two

levers on each caster corresponding to each of these locks.

FOOTREST'

The'footrest'on'your'chair'is'designed'to'swing'away'and'removes'easily.'To'swing'away,'

remove'feet'from'the'footplate'(1)'and'fold'footplates'up.'Then'push'the'release'handle'(2)'on'

the'footrest'locking'mechanism.'It'will'swing'to'the'side'of'your'chair,'and'could'then'be'

removed'by'lifting'it'straight'up'and'off'the'locating'pins'(3).'To'replace'hold'footrest'at'the'side'

of'your'chair,'locate'onto'mounting'pins,'allowing'it'to'drop'all'the'way'in,'and'then'push'

forward'until'it'locks'into'place.'
