Potter Amseco EBP-401 Guía de inicio rápido

SPK

CHIME SEL.

OUTPUT

OU TPU T

INPUT

12V AC

GND +12V

EBP-401

LONG RANGE DOOR

ANNUNCIATOR SYSTEM

Potter Electric Signal Company • 2081 Craig Road, St. Louis, MO, 63146-4161 • Phone: 800-325-3936/Canada 888-882-1833 • www.amseco-kai.com

MKT. #8850053 - REVA

5/06 PAGE 1 OF 2

PRINTED IN USA

A Brand

• Intelligent microprocessor driven system

• 40 ft. detection range across doorway

• Four user selectable chime sounds

• Advanced circuit integrated with active-infrared

beam technology

• High/low volume control

• Expandable using additional chimes (CM-5)

Stock Number - 4130030

The EBP-401 is a surface mount, 40 ft., long range annunciator system using active infrared technology. This invisible single infrared

beam triggers a pleasant chime sound when the infrared beam is interrupted. The system can be installed anywhere inside the buildings

where trafﬁc surveillance is required.

Complete Kit Includes:

1 Electronic chime

1 Infrared sensor

1 Reﬂector

1 Power transformer (12VAV 20VA)

1 Long plastic bracket

1 Metal short bracket

1 Short plastic bracket

1 6 ft. power cord with in-line switch

1 26 ft. 2-conductor wires

6 3/4” sheet metal screws

1 3/8” bolt w/locking washer

2 5/8” machine screws w/washers and nuts

1 Manual

2~3

Feet

Min.

Power ON/OFF

Switch

Electronic

Chime Infrared

Sensor 26 ft Wires Power

Transformer

(12VAC 20VA)

Reﬂector Long Plastic

and Short

Metal

Mounting

Bracket

Short

Mounting

Bracket

6 ft Power Cords

With In-line ON/

OFF Switch

Hardware

Wiring Diagram

EBPT-401

Transformer

Power

Switch

CM-5

GND: White/Black

+12V :White

MKT. #8850053 - REVA

5/06 PAGE 2 OF 2

PRINTED IN USA

A Brand

Speciﬁcations

EBP-401

LONG RANGE DOOR

ANNUNCIATOR SYSTEM

Part Information EBP-401

Description Long Range Wired Annunciator System

Detection method Active infrared

Detection range 40 ft.

Maximum transmission range 1000 ft. AWG#22 2P wire

Power source Sensor: 12VAC/DC, 20VA

Chime: 12V DC, 10VA

Power consumption: Standby Sensor: 50mA

Chime: 100mA

Power consumption: In alarm Sensor: -

Chime: 500mA

Volume level 80dB (low) - 95dB (high)

Chime sounds selection Selectable among 4 sounds by a dip SW

Chime sounds level selection JP1 (Jumper SHORT LOW

Jumper OPEN HIGH)

Response time 4m sec.

Light source Infrared pulse beam 950mm

Installation location Indoor

Infrared beam interception warning Sensor: JP1 selectable

OFF/10 sec/60 secretary

Install setting Transformer Power ON - Red Alignment LED ON - Transformer

Power OFF - Transformer Power ON - Setting

Power switch Yes

Temperature 14°F - 122°F (-10°C - 50°C)

Weight

Dimension: (W x H x D)

Sensor: 125g

Chime: 164.4g

Sensor: 2 1/2” x 1 7/8” x 3 7/16”

Chime: 4 7/8” x 3 1/2” x 1 3/8”

Installation

Reflector

ALIGNMENT LED LIGHTS UP

WHEN THE REFLECT OR

ALIGNMENT IS SUCCESSFUL.

3/8" Bolt

5/8" Screw

Metal Short Bracke

NutNut

Short Plastic Bracket

Locking

Washer

Rear Mount Side Mount

Lock Washer

Screw

Lock Washer

Screw

If necessary, use cable

ties to keep wires safely

out of the way to avoid

tripping.
