Polygroup TG70M3H90C00 Manual de usuario

3. Each tree section is numbered with a tag. Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective

cap before inserting into the assembled stand.Make sure the pole is firmly inserted and secured into

the stand.

5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all

wires are free of branch hinges.

7. (For pre-lit trees only) Connect the light strings as per the color labels indicated in Fig. B and insert

green label plug into the wall outlet.Your entire tree should now be lit.If some bulbs do not light or

flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in

order to maintain the performance and life expectancy of your pre-lit tree.

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from

the pole and fan out one to the right,one to the left and one at the center of the main stem. (See Fig. C)

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform

look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

Congratulations on purchasing your new tree from Polygroup®! Carefully follow the instructions below

on how to quickly and easily set up your new tree.

TREE ASSEMBLY INSTRUCTIONS

Top view Side view

Fig. C

ASSEMBLY INSTRUCTIONS MADE IN CHINA

Section 3

Section 2

Section 1

Insert

Green Label

Plug Into Wall

Outlet

Assemble

Red Labels

Together

Assemble

Yellow Labels

Together

MODEL #:TG70M3H90C00 / TG70M3H90M00

*Electrical Rating For The Tree

(For Indoor Use Only)

1.36A 120V 60Hz

Fig. B - Tree and Light Assembly

Fig. A - Tree Stand Assembly

Unfold the legs and lay the

stand in a flat area.Then slide

the locking disc downward and

snap into place.

1. Remove all ornaments and decorations. For pre-lit trees, first unplug extension cord from the wall

outlet and then disconnect light extension cord between each section of the tree.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to

remove from section below and fold all branches toward the pole.

3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and

rotate the upper pole in both directions. Lift up the upper pole again.

4. Continue by gently lifting straight up each section(s) from the section below and fold all branches

toward the pole until the bottom section is removed from the tree stand.

5. Carefully place all tree sections into shipping box and tape it shut.

6.When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to

excessive heat or humidity may damage your tree.

STORAGE INSTRUCTIONS

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected according to the color labels indicated

in Fig.B and the power cord is plugged into the wall outlet. Refer to assembly guide for instructions. (If

the tree comes with a foot pedal, try stepping on the on/off button).

2. Please check for blown fuses at the light string plugs and power cord plug. Replace as needed.

Note: Please make sure to use appropriate replacement fuses as indicated on the light string plug and

power cord plug.

3. Please check for loose, broken or missing light bulbs and replace as needed.

Loose Hinge Pin

1. Extra hinge pins are included for repairing the hinges.Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure using the retainer washer.(See Fig. D)

TROUBLE SHOOTING TIPS

Each tree includes hinge pins/washers, and for pre-lit

trees spare bulbs and fuses are also included. If extra

parts are needed, please contact our customer service

center.

SPARE PARTS

ASSEMBLY INSTRUCTIONS MADE IN CHINA

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact

us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service

representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:
