SpectraLink 8000 SVP Server

Overview

The SVP Server is an Ethernet LAN device that works with APs to

provide QoS on the wireless LAN. Voice packets to and from the

SpectraLink 8000 Wireless Telephones are intercepted by the SVP

Server and encapsulated for prioritization as they are routed to and

from the SpectraLink 8000 Telephony Gateway.

One or more SVP Servers are required in systems with five or more

SpectraLink 8000 Telephony Gateways. In systems with four or fewer

SpectraLink 8000 Telephony Gateways, the SVP Server is not required

because SVP is handled within the SpectraLink 8000 Telephony

Gateway(s).

SpectraLink Voice Priority (SVP) and

Quality of Service

SpectraLink Voice Priority (SVP) is the SpectraLink quality of service

(QoS) mechanism that is implemented in the wireless telephone and

AP to enhance voice quality over the wireless network. SVP gives

preference to voice packets over data packets on the wireless medium,

increasing the probability that all voice packets are transmitted

efficiently and with minimum delay. SVP is fully compatible with the

IEEE 802.11b standard.

SpectraLink 8000 Wireless Telephones support basic WMM (Wi-Fi

Multimedia) if also supported by the AP as part of the 802.11e

protocol. If the AP supports WMM, the wireless telephone

automatically discovers and uses it. WMM does not replace the SVP

Server.

SpectraLink 8000 SVP Server: Administration Guide for SRP

PN: 1725-36032-001_G.doc

Multiple SVP Servers

Multiple SVP Server environments are those which have more than

one SVP Server. Up to 16 SVP Servers may be installed in any one

subnet.

The Timing Function

In the SpectraLink Gateway environment, SVP Servers provide the

"timing" function for active calls. In multiple SVP Server

environments, the active calls are distributed across the SVP Servers.

The number of active SVP Servers is determined dynamically.

Whenever SVP Servers are added to or removed from the system, the

distribution of the "timing" function for active calls is affected.

The addition of an SVP Server is detected as soon as the new SVP

Server is up and running. The new SVP Server will immediately start

providing the “timing” function for the appropriate wireless

telephones. The user should not detect any change. The removal of an

SVP Server is detected within one minute. During this time, any

wireless telephone that was using the SVP Server that was removed

will be affected. If the wireless telephone was not in a call, it may lose

contact with its Gateway, resulting in a check-out/check-in sequence.

If the wireless telephone was in a call, the audio will be lost and the

call will be dropped.

SpectraLink 8000 SVP Server Overview

PN: 1725-36032-001_G.doc 9

SpectraLink 8000 SVP Server Capacity

The table below shows the capacity of SpectraLink 8000 Telephony

Gateways in a multiple SVP Server environment. The table shows the

total possible calls at 100% active calls. However, since it is unlikely

that all handsets will be in use at the same time, the table then

analyzes the number of handsets that could be installed in any given

system where 15%, 25% or 50% of the handsets are in active calls at

any one time. The calculations are not linear due to the Erlang1

calculation for telephony traffic. The possible installed handsets

figures are approximate and meant as a guideline and not as an

absolute recommendation for any facility.

Possible installed handsets

Number

SVP

Servers

Number of

calls

possible

per Server

Total

possible

installed

handsets

@ 100% in

active calls

Number of

SpectraLink

8000

Telephony

Gateways

required

Erlang @ 15% in

active

calls

@ 25% in

active

calls

@ 50% in

active

calls

1 120 120 15 103 240 240 206

2 120 240 30 111 480 480 438

3 120 3202 40 160 640 640 640

1An Erlang is a unit of telecommunications traffic measurement. Strictly speaking, an Erlang represents the

continuous use of one voice path. In practice, it is used to describe the total traffic volume of one hour.

Erlang traffic measurements are made in order to help telecommunications network designers understand traffic

patterns within their voice networks. This is essential if they are to successfully design their network topology and

establish the necessary trunk group sizes.

Erlang traffic measurements or estimates can be used to work out how many lines are required between a telephone

system and a central office (PSTN exchange lines), or between multiple network locations.

Please visit www.erlang.com for additional information.

2Limited by the eight simultaneous calls supported by each SpectraLink 8000 Telephony Gateway.

SpectraLink 8000 SVP Server: Administration Guide for SRP

PN: 1725-36032-001_G.doc

Notes on System Configuration

Wireless telephones cannot roam with uninterrupted service

between subnets unless specific LAN components are present.

Certain AP/Ethernet switch combinations establish a layer-2 tunnel

across subnets that enables the handsets to roam. Without this

capability, any call in progress will be dropped when the user

moves out of range and the handset must be power cycled in order

to resume functionality in the new subnet area.

Please see Deploying Enterprise-Grade Wi-Fi Telephony for

detailed configuration information when installing multiple SVP

Server models across several different subnets.

Subnets are not recommended in SpectraLink 8000 Telephony

Gateway environments.

IP multicast addresses are used when SpectraLink i640 and 8030

Wireless Telephones are installed. This requires that multicasting

be enabled on the subnet used for the SpectraLink 8000 Wireless

Telephones, SVP Server, and Telephony Gateways.

Routers are typically configured with filters to prevent multicast

traffic from flowing outside of specific domains. The wireless LAN

can be placed on a separate VLAN or subnet to reduce the effects

of broadcast and multicast traffic from devices in other network

segments.

The SVP Server requires a Cat. 5 cable connection between its

network port and the Ethernet switch. The SVP Server auto-

negotiates to the type of port on the Ethernet switch and supports

10Base-T, 100Base-T, full-duplex and half-duplex port types.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Servidor de Polycom

Polycom

Polycom Realpresence collaboration server 1500 Instrucciones de instalación

Polycom

Polycom RealPresence 800s Manual de usuario

Polycom

Polycom RealPresence RMX 4000 Instrucciones de instalación

Polycom

Polycom DOC2557B Instrucciones de instalación

Polycom

Polycom RSS 2000 Manual de usuario

Polycom

Polycom KIRK 300 Manual del operador

Polycom

Polycom PDS 725-78600-002A2 Manual de usuario

Polycom

Polycom 3150-30828-001 Manual de usuario

Polycom

Polycom Realpresence collaboration server 1500 Hoja de datos

Polycom

Polycom KIRK Wireless Server 600v3 KWS600v3 Manual de usuario

Polycom

Polycom RSS 2000 Manual de usuario

Polycom

Polycom RealPresence RMX 1800 Hoja de datos

Polycom

Polycom realpresence 1800 Manual de instrucciones

Polycom

Polycom DOC2232A Manual de usuario

Polycom

Polycom RMX 2000 Hoja de datos

Polycom

Polycom RealPresence Manual de usuario

Polycom

Polycom KIRK Wireless Server 6000 Manual de usuario

Polycom

Polycom Collaboration Server (RMX) 1800 Instrucciones de instalación

Polycom

Polycom RMX 1500 Manual de usuario

Polycom

Polycom Realpresence collaboration server 1500 Manual de servicio

Polycom

Polycom Collaboration Server (RMX) 1800 Instrucciones de instalación

Polycom

Polycom ReadiManagerSE200 Manual de usuario

Polycom

Polycom 3725-18101-001B Manual de servicio

Polycom

Polycom KIRK 14117800 Manual del operador

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
