Polaroid TLE-04641C Manual de usuario
46” Full High Definition LCD
TLE-04641C
Questions? Need some help?
This manual should help you understand your new product. If you have
questions, call our toll-free number found on the insert with this icon:
Or visit www.polaroid.com.
This TV incorporates High-Definition Multimedia Interface (HDMITM) technology.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
DISPOSAL OF WASTE ELECTRONIC EQUIPMENT BY PRIVATE
HOUSEHOLDS WITHIN THE EUROPEAN UNION
This sign indicates that this product may not be disposed of with your regular
household waste. The recycling and separate collection of such products is
your responsibility. Please drop off the above-mentioned waste at a designated
place for recycling waste electrical and electronic equipment. If you do not know
where to drop off your waste equipment for recycling, please contact your local
city office or household waste collection service.
ENGLISHENGLISH
1
Warnings and Precautions
To reduce the risk of fire or electric shock, do not expose this equipment to rain or moisture.
This symbol is intended to alert the user to avoid the risk of electric shock.
This equipment must not be disassembled by anyone except qualified service personnel.
This symbol is intended to alert the user to the presence of important operating and
maintenance instructions in the literature accompanying the appliance.
▪TO REDUCE THE RISK OF ELECTRIC SHOCK,
▪DO NOT REMOVE COVER (OR BACK).
▪NO USER-SERVICEABLE PARTS INSIDE.
▪REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Use of controls, adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
CAUTION
Important Safety Instructions
To prevent any injuries, the following safety precautions should be observed in the installation, use,
servicing and maintenance of this equipment.
Before operating this equipment, please read this manual completely, and keep it nearby for future
reference.
WARNING
▪Do not place the equipment on any uneven or unstable carts, stands, tables, shelves etc.
The equipment may fall, causing serious injury to children or adults and serious damage to
the equipment itself.
▪Use only a cart or stand recommended by the manufacturer. This equipment and
recommended cart or stand should be handled with care. Quick stops, excessive force, and
uneven surfaces may cause the equipment and cart/stand to overturn.
▪Do not disable the 3-wire grounding type plug. The grounding pin on the 3-prong plug is an
important feature. Removing the grounding pin will increase the risk of damaging the
equipment.
▪If you can not fit the plug into the electrical outlet, contact an electrician to install a grounding
outlet.
▪Always operate this equipment from the type of power source indicated on the rear of the
serial/model information label.
▪Never overload wall outlets and extensions.
This symbol indicates caution points.
This symbol indicates actions that should not be done.
This symbol indicates actions that must be performed.
2
Warnings and Precautions
▪Use and handle the power cord with care. Do not place any heavy objects on the AC
power cord.
▪Do not pull the AC power cord. Do not handle theAC power cord with a wet hand.
▪Do not touch the power cord and antenna cable during lightning.
▪Remove the plug from the wall outlet, if the equipment will not be used for a long period
of time.
▪Do not place, use or handle this equipment near water.
▪Never expose the equipment to liquid, rain, or moisture.
Seek for service if any of the above is spilled into the equipment.
▪Do not expose the equipment to extreme temperature or to direct sunlight, as the
equipment may heat up and suffer damage.
▪Do not install the equipment near any heat sources such as radiators, heat registers,
stoves, or any other apparatus that might produce heat.
▪Do not attempt to service the equipment yourself.
▪Opening and removing the covers may expose you to dangerous voltage or other
hazards and may void your warranty. Refer service to qualified personnel.
▪Do not place or drop any other objects on top.
▪Do not insert anything into the ventilation holes of your equipment.
Inserting any metal or flammable objects may result to fire or electric shock.
▪Do not place the equipment on uneven or unstable carts, stands, tables, shelves etc.
The equipment may fall, causing serious injury to children or adults and serious damage
to the equipment itself. Always place the equipment on the floor or on a surface that is
sturdy, level, stable and strong enough to support the weight of the equipment.
▪Do not block any ventilating openings. Leave an open space around the equipment.
Never place the equipment :
on a bed, sofa, rug, or any other similar surfaces; too close to drapes/curtains/walls, in a
bookcase, built-in cabinet, or any other similar places that may cause poor ventilation.
▪Unplug this apparatus during lightning storms or when unused for long periods of time.
▪Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
▪Always remove the power cord from the outlet before cleaning the equipment.
▪Never use liquid or aerosol cleaners on the equipment.
Clean only with a soft dry cloth.
▪Only use attachments/accessories specified by the manufacturer.
ENGLISHENGLISHENGLISH
3
Warnings and Precautions
Outdoor Antenna Safety Instructions
Antenna lead-in wire
Antenna discharge unit
Grounding conductors
Ground clamps
Power service grounding
Ground clamps
Electric service
equipment
If an outdoor antenna is connected, follow the precautions below:
EXAMPLE OF OUTDOOR ANTENNA GROUNDING
▪An outdoor antenna should not be located in any area where it could come in contact with
overhead power lines, or any other electric light or power circuits.
▪When installing an outdoor antenna system, extreme caution should be taken to prevent
contact with power lines. Direct contact with power lines may be fatal and should be avoided
at all costs.
Use this TV only in temperature within the 0 to 35 C.
Use this TV only in altitude within the 0 to 2000M.
4
CONTENTS
Warnings and Precautions
Important Safety Instructions....................................................................................... 1
Antenna Safety Instructions......................................................................................... 3
Chapter 1 Introducing the LCD TV
Key Features ............................................................................................................... 7
Package Contents ....................................................................................................... 8
Setting Your LCD TV.................................................................................................... 9
Your LCD TV...............................................................................................................11
Your Remote Control................................................................................................. 13
Chapter 2 Installing the LCD TV
Connecting a TV Cable or anAntenna...................................................................... 15
Connecting a VCR..................................................................................................... 20
Connecting a Video Camera or Game Console ........................................................ 21
Connecting a DVD Player.......................................................................................... 22
Connecting a digital TV Cable Box or Digital Satellite Receiver................................ 24
Connecting an AV Equipment with HDMI Connector................................................. 25
Connecting an AV Equipment with DVI Connector.................................................... 26
Connecting an AV Equipment with SCART Connector.............................................. 27
Connecting a PC........................................................................................................ 28
Connecting an Audio Receiver ................................................................................. 29
Chapter 3 USING THE FEATURES
Using Picture-In-Picture...................................................................................28
Wide Screen Viewing......................................................................................30
Using Telextext Functions................................................................................31
Operating the Menu........................................................................................32
Customizing the VIDEO Settings ......................................................................34
Customizing the AUDIO Settings ......................................................................35
Customizing the SETUP Settings......................................................................35
Using the Parantal Settings............................................................................. 38
Customizing the TV Settings............................................................................39
Troubleshooting.................................................................................................... 41
Display Modes........................................................................................................ 42
Specifications........................................................................................................ 43
ENGLISH
5
Chapter 1 Introducing the LCD TV
Various Audio/Video terminals for external equipment connection
▪2 set of composite A/V input terminals
▪2 SCART input terminals
▪1 set of component Video input terminals
▪1 VGA/ Audio input terminal
▪2 HDMI/Audio input terminals
▪1 sets of Audio(L/R) output terminals
▪1 Headphone terminal
High Definition Multimedia Interface (HDMI)
▪High Definition Multimedia Interface (HDMI) is a small, user-friendly interconnect that
can carry up to 5 Gbps of combined video and audio in a single cable. This system
eliminates the cost, complexity and confusion of multiple cables used to connect
current A/V systems.
HDTV Component Video Inputs
▪Offers the best video quality for DVD(480p) and digital set-top-box (HD1080i,
1080p,720p) connections.
3D Digital Noise Reduction
▪This function can digitally reduce image noise to provide better picture quality.
Film-Mode Detection (3:2 Reverse Pull Down)
▪This function can automatically detect content derived from film and adjust the
interlacer’s frame matching to provide a more natural-looking, clearer image of the
moving picture.
PIP Function
▪The PIP/POP feature allows simultaneous viewing of video from two sources (TV,
VCR, DVD etc). Only one source’s audio is played at a time; the user may select which
source’s audio is heard.
Chapter 1
Introducing the LCD TV
Key Features
6
Chapter 1 Introducing the LCD TV
Make sure all of the following contents are included. If you are missing any items,
please return this product to the original place of purchase.
LCD TV
Make sure all of the following contents are included.
Power Cord
(The power cord type may be different
depending on your country’s power type)
These items are all you need to set up and operate the LCD TV in its basic configuration.
Package Contents
VIDEO Cable Remote Control/
AAA Batteries x 2
User Guide
a
Bottom Stand /
Screw Driver and 6 Screws
Component Cable
Quick Guide
AUDIO Cable
Warranty Card
OK
POWER
GUIDE EXIT
INFO
LIST FAV.CH TIMER FREEZE
MENU
S.MODE
SLEEP
SWAP PIPP.MODE
MTS MUTE
CAPTION P.SIZE
123
456
789
JUMP
0
ENT
VOL. CH.
AIR/CABLE
SOURCE
ENGLISH
7
Chapter 1 Introducing the LCD TV
If you prefer to mount your new Polaroid TV on a wall instead of attaching it to the stand,
please reference the instructions included in the wall mounting kit(not included).
Setting Your LCD TV
How to install the TV Stand
Do not remove the packaging material from the TV before the stand is
attached.
Read all instructions before continuing with the stand installation.
a. Lift foam packaging material from the top of the LCD out of the box.
b. Lift LCD out of the box, with the bottom foam packaging material still attached, and place
onto a stable surface.
c. Remove protective bag from LCD unit, but DO NOT remove the bottom foam packaging
material from the TV.
d. Locate the place on the back of the TV to attach the stand. Secure the stand to the LCD
with all six screws.
8
Chapter 1 Introducing the LCD TV
How to setup the TV
Do not use caustic cleaners (porcelain, stainless steel, toilet, or oven cleaner
etc.) on the remote, as it may suffer damage.
Use a supplied antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT. terminal
(refer to page 17).
Connect the AC power cord at the back of the TV and connect the power cord to wall outlet.
Insert the 2 batteries supplied in remote control.
Connect other an external A/V device (refer to page 19-28).
Step1 Slide the back cover up to open the
battery compartment of the remote
control.
Step2 Insert twoAAA size batteries.
Make sure to match the (+) and
( - ) ends of the batteries with
the (+) and ( - ) ends indicated
in the battery compartment.
Slide the cover back into place.
Tabla de contenidos
Otros manuales de Monitor de Polaroid
Polaroid
Polaroid FLM-3701 Manual de usuario
Polaroid
Polaroid TLA-01901C - 19" LCD TV Manual de usuario
Polaroid
Polaroid FLM-3701 Manual de usuario
Polaroid
Polaroid Polaview HR2500 Instrucciones de funcionamiento
Polaroid
Polaroid LCD-1700 Manual de usuario
Polaroid
Polaroid PLA-5040 Manual de usuario
Polaroid
Polaroid PLA-4260MTR Manual de usuario
Polaroid
Polaroid PLA-4205 Manual de usuario
Polaroid
Polaroid PLA-4255BD Manual de usuario
Polaroid
Polaroid PLA 4260 Manual de usuario
