Polar Electro CD610 Manual de usuario

Model • Modèle • Modell • Modello • Modelo • Malli:

CD610/CD611/CD612/CD613/CD614/CD615/CD080/CD081/CD082/

CD083/CD084/CD085/GL185

Refrigerators/

Freezers

Instruction manual

EN Fefrigerators/Freezers

Handleiding

2DE Kühlschrank/Gefrierschrank

Bedienungsanleitung

NL Koelkast/Vrieskast

Handleiding

10 IT Frigorifero/Congelatore

Manuale di istruzioni

Armoire positive/négative

Mode d'emploi

18 ES Frigorífico/Congelador

Manual de instrucciones

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 1CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 1 2022/9/30 15:362022/9/30 15:36

Safety Instructions

• Position on a flat, stable surface.

• A service agent/qualified technician should carry out

installation and any repairs if required. Do not remove any

components or service panels on this product.

• Consult Local and National Standards to comply with the

following:

- Health and Safety at Work Legislation

- BS EN Codes of Practice

- Fire Precautions

- IEE Wiring Regulations

- Building Regulations

• DO NOT use jet/pressure washers to clean the appliance.

• DO NOT use the appliance outside.

• DO NOT use this appliance to store medical supplies.

• DO NOT allow oil or fat to come into contact with the plastic

components or door seal. Clean immediately if contact occurs.

• DO NOT store products on top of the appliance.

• Bottles that contain a high percentage of alcohol must be

sealed and placed vertically in the refrigerator.

• Always carry, store and handle the appliance in a vertical

position and move by holding the base of the appliance.

• Always switch off and disconnect the power supply to the unit

before cleaning.

•Keep all packaging away from children. Dispose of the packaging

in accordance with the regulations of local authorities.

• If the power cord is damaged, it must be replaced by a POLAR

agent or a recommended qualified technician in order to avoid

a hazard.

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 2CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 2 2022/9/30 15:362022/9/30 15:36

• Children should be supervised to ensure that they do not play

with the appliance.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience or knowledge, unless they have been

given supervision or instruction concerning the use of the

appliance by a person responsible for their safety.

• POLAR recommend that this appliance should be periodically

tested (at least annually) by a Competent Person. Testing

should include, but not be limited to: Visual Inspection,

Polarity Test, Earth Continuity, Insulation Continuity and

Functional Testing.

• POLAR recommend that this product is connected to a circuit

protected by an appropriate RCD (Residual Current Device).

Caution: Risk of Fire

• Do not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

Warning: Keep all ventilation openings clear of

obstruction. Unit should not be boxed in without

adequate ventilation.

• Warning: Do not use mechanical devices or other means

to accelerate the defrosting process, other than those

recommended by the manufacturer.

• Warning: Do not damage the refrigerant circuit.

• Warning: Do not use electrical appliances inside the food

storage compartments of the appliance.

Introduction

Please take a few moments to carefully read through this manual. Correct maintenance and operation of

this machine will provide the best possible performance from your POLAR product.

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 3CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 3 2022/9/30 15:362022/9/30 15:36

Pack Contents

The following is included:

• POLAR Refrigerator / Freezer

• Shelves - Refrigerator only

CD610/CD080 x 3

CD612/CD082 x 4

CD614/CD084 x 4

• Tray Guides - Bakery refrigerator only

GL185 x 12

• Keys x 2

• Spacers x 2

• Instruction Manual

POLAR prides itself on quality and service, ensuring that at the time of unpacking the contents are

supplied fully functional and free of damage.

Should you find any damage as a result of transit, please contact your POLAR dealer immediately.

Installation

Note: A bracket is used to support the door during transportation. On receipt please remove the bracket.

Note: Not for use in vans or trailers, food trucks or similar vehicles.

If the unit has not been stored or moved in an upright position, let it stand upright for

approximately 12 hours before operation. If in doubt allow to stand.

1. Remove the appliance from the packaging. Make sure that all protective plastic film and coatings are

thoroughly removed from all surfaces.

2. To optimize performance and longevity, ensure a minimum clearance of 2.5cm is maintained between

the unit and walls and other objects, with a minimum 20cm clearance on the top. NEVER LOCATE

NEXT TO A HEAT SOURCE.

Note: Before using the appliance for the first time, clean the shelves and interior with soapy

water then dry well.

The appliance is supplied with feet by default. However, castors can be supplied as an

option from serial number range: 8124199-UK / 8128873-EU onwards.

Reversing the door

Depending on the location of the appliance, it may be necessary to change the direction the door opens

by changing the side of the door handle. (Tip: Images in this section are for illustration only and may

slightly differ from the actual appliance appearances.)

To reverse the door handle:

1. The door handle is on the left side. Disassemble the right lower hinge.

Door handle

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 4CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 4 2022/9/30 15:362022/9/30 15:36

2. Remove the door from the right upper hinge.

Then remove the hinge sleeve from the door

top.

3. Remove the right upper hinge and install it

on the left side. Afterwards, install the hinge

sleeve onto the hinge.

4. Reverse the door and hang it onto the left

upper hinge.

Door handle

5. Remove the pre-mounted screws on the left

lower side.

6. Install the previously removed right lower

hinge on the left side.

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 5CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 5 2022/9/30 15:362022/9/30 15:36

7. Secure the hinge in place using the previously

removed screws.

8. Now the door handle is installed on the right

side.

Operation

Control Panel

The control panel is located on the front of the

appliance.

Turn On

1. Close the door of the appliance.

2. Connect the appliance to a mains power

supply.

Set the Operating Temperature

1. Press the SET button for 3 seconds. The

display will flash.

2. Press the or buttons to display the

required temperature.

3. Press the SET button to store the temperature.

Manual Defrost

Press and hold the defrost button “aux” for 2

seconds to begin a manual defrost. The defrost

light illuminates.

Storing Food

To get the best results from your POLAR appliance,

follow these instructions:

• Only store foodstuffs in the appliance when it

has reached the correct operating temperature.

• Do not place uncovered items as below inside

the appliance, as this can lead to a damaged

and leaking evaporator, and thus void your

warranty: hot food, hot liquids, acidic fluids,

acidic products.

• Wrap or cover food where possible.

• Do not obstruct the fans inside the appliance.

• Avoid opening the doors for prolonged periods

of time.

Lock/Unlock the Doors

• A lock is fitted to the doors to ensure foodstuffs

are kept secure within your POLAR appliance.

• Use the keys provided to lock/unlock the door.

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 6CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 6 2022/9/30 15:362022/9/30 15:36

Cleaning, Care & Maintenance

• Switch off and disconnect from the power supply before cleaning.

• Clean the interior of the appliance as often as possible.

• Do not use abrasive cleaning agents. These can leave harmful residues.

• Clean the door seal with warm soapy water.

• Always wipe dry after cleaning.

• Do not allow water used in cleaning to run through the drain hole into the evaporation pan.

• Take care when cleaning the rear of the appliance. Sharp edges can cut.

Condensation will form in refrigeration with frequent opening of the doors and on hot humid

days, please ensure condensation is allowed to drain properly or is wiped dry.

Cleaning the Condenser

Periodically cleaning the condenser can extend the life of the appliance.

POLAR recommend that a POLAR agent or qualified technician should clean the condenser.

Troubleshooting

A qualified technician must carry out repairs if required.

Fault Probable Cause Solution

The appliance is not

working The unit is not switched on Check the unit is plugged in correctly and

switched on

Plug or lead is damaged Replace Plug or lead

Fuse in the plug has blown Replace the fuse

Mains power supply fault Check mains power supply

The appliance turns on,

but the temperature is

too high/low

Too much ice on the evaporator Defrost the appliance

Condenser blocked with dust Clean the condenser

Doors are not shut properly Check doors are shut and seals are not

damaged

Appliance is located near a

heat source or air flow to the

condenser is being interrupted

Move the refrigerator to a more suitable

location

Ambient temperature is too high Increase ventilation or move appliance to a

cooler position

Unsuitable foodstuffs are being

stored in the appliance Remove any excessive hot foodstuffs or

blockages to the fan

Appliance is overloaded Reduce the amount of food stored in the

appliance

The appliance is

leaking water The appliance is not properly

levelled Adjust the screw feet to level the appliance

(if applicable)

The discharge outlet is blocked Clear the discharge outlet

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 7CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 7 2022/9/30 15:362022/9/30 15:36

Fault Probable Cause Solution

The appliance is

leaking water Movement of water to the drain is

obstructed Clear the floor of the appliance (if

applicable)

The water container is damaged Call POLAR agent or qualified Technician

The drip tray is overflowing Empty the drip tray (if applicable)

The appliance is

unusually loud Loose nut/screw Check and tighten all nuts and screws

The appliance has not been

installed in a level or stable

position

Check installation position and change if

necessary

The display lamp does

not light Lamp needing replacing Call POLAR agent or qualified Technician

Technical Specifications

Note: Due to our continuing program of research and development, the specifications herein may subject

to change without notice.

Model Voltage Power Current Temperature

Range

Gross

Capacity

(L)

Net usable

capacity

(L) Refrigerant Dimensions

H x W x D mm

Weight

(kg)

CD610

CD080 230V

50Hz 120W 1A 2°C ~ 8°C 150 64 R600a 855 x 600 x

595 44

CD611

CD081 230V

50Hz 150W 1A -10°C ~ -25°C 140 78 R600a 855 x 600 x

595 44

CD612

CD082 230V

50Hz 185W 1.5A 2°C ~ 8°C 400 238 R600a 1850 x 600 x

600 69

CD613

CD083 230V

50Hz 210W 2A -10°C ~ -25°C 365 258 R600a 1850 x 600 x

600 73

CD614

CD084 230V

50Hz 200W 1.5A 2°C ~ 8°C 600 419 R600a 1900 x 780 x

695 90

CD615

CD085 230V

50Hz 350W 3.5A -10°C ~ -25°C 600 469 R600a 1890 x 780 x

695 95

GL185 230V

50Hz 185W 1.5A 0°C ~ 8°C 522 410 R600a 1720 x 777 x

715 90

Note: For optimal product performance and efficiency, please ensure to mind the net usable capacity (load

limit) when filling.

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 8CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 8 2022/9/30 15:362022/9/30 15:36

Electrical Wiring

POLAR appliances are supplied with a 3 pin BS1363 plug and lead.

The plug is to be connected to a suitable mains socket.

POLAR appliances are wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.

Disposal

EU regulations require refrigeration product to be disposed of by specialist companies who remove or

recycle all gasses, metal and plastic components.

Consult your local waste collection authority regarding disposal of your appliance. Local authorities are

not obliged to dispose of commercial refrigeration equipment but may be able to offer advice on how to

dispose of the equipment locally.

Alternatively call the POLAR helpline for details of national disposal companies within the EU.

Compliance

The WEEE logo on this product or its documentation indicates that the product must

not be disposed of as household waste. To help prevent possible harm to human

health and/or the environment, the product must be disposed of in an approved and

environmentally safe recycling process. For further information on how to dispose of

this product correctly, contact the product supplier, or the local authority responsible for

waste disposal in your area.

POLAR parts have undergone strict product testing in order to comply with

regulatory standards and specifications set by international, independent,

and federal authorities.

POLAR products have been approved to carry the following symbol:

mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.

Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to

change specifications without notice.

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 9CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 9 2022/9/30 15:362022/9/30 15:36

Veiligheidstips

• Plaatsen op een vlakke en stabiele ondergrond.

• De installatie en eventuele reparaties dienen door een

servicemonteur/vakman uitgevoerd te worden. Verwijder geen

onderdelen of servicepanelen van dit product.

• Raadpleeg en volg de plaatselijke en nationale regelgeving op

m.b.t. tot het volgende:

- Wetgeving inzake gezondheid en veiligheid op het werk

- Nen-praktijkrichtlijnen

- Brandpreventie

- IEE-bedradingsvoorschriften

- Bouwvoorschriften

• Dit product NIET reinigen met spuit-/drukreinigers.

• Dit product NIET gebruiken voor de berging van medische

producten.

• NIET op de kastbasis, lades en deuren staan of als

ondersteuning gebruiken.

• Laat NIET toe dat olie of vet in contact komt met plastic

componenten of deurafdichtingen. Onmiddellijk reinigen indien

dit wel gebeurt.

• GÉÉN producten op de koellast bewaren.

• Uitsluitend geschikt voor gebruik binnenshuis.

• Flessen met een hoog alcoholpercentage moet goed worden

afgesloten en verticaal in de koelkast worden bewaard.

• Dit product altijd in een verticale positie vervoeren, opslaan en

gebruiken. Het product verplaatsen door aan de onderkant op

te tillen.

• Alvorens dit product te reinigen dient men altijd de

stroomvoorziening uit te schakelen.

• Laat verpakkingsmateriaal niet binnen handbereik van

kinderen. Verpakkingsmateriaal in overeenstemming met

de regelgeving van de plaatselijke overheden als afval laten

verwerken.

CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 10CD610-CD615_CD080-CD085_GL185_ML_A5_v21_20220930.indb 10 2022/9/30 15:362022/9/30 15:36

Otros manuales para CD610

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Refrigerador de Polar Electro

Polar Electro

Polar Electro DL893-A Manual de usuario

Polar Electro

Polar Electro GL180-A Manual de usuario

Polar Electro

Polar Electro CD080-A Manual de usuario

Polar Electro

Polar Electro CD239 Manual de usuario

Polar Electro

Polar Electro CN267 Manual de usuario

Polar Electro

Polar Electro Deli CG841-A Manual de usuario

Polar Electro

Polar Electro G596-A Manual de usuario

Polar Electro

Polar Electro GL178-A Manual de usuario

Polar Electro

Polar Electro G604 Manual de usuario

Polar Electro

Polar Electro DY395 Manual de usuario

Polar Electro

Polar Electro GE579 Manual de usuario

Polar Electro

Polar Electro G Series Manual de usuario

Polar Electro

Polar Electro GH218-A Manual de usuario

Polar Electro

Polar Electro GD873-A Manual de usuario

Polar Electro

Polar Electro UA005-A Manual de usuario

Polar Electro

Polar Electro G Series Manual de usuario

Polar Electro

Polar Electro GJ447 Manual de usuario

Polar Electro

Polar Electro UA001-A Manual de usuario

Polar Electro

Polar Electro GC870-A Manual de usuario

Polar Electro

Polar Electro G590/G591/G592/G593/G594/G595/U632/U633/U634/U635/CC663/CD616/GD879/GD880/ Manual de usuario

Polar Electro

Polar Electro DA546 Manual de usuario

Polar Electro

Polar Electro FD169 Manual de usuario

Polar Electro

Polar Electro G Series Manual de usuario

Polar Electro

Polar Electro GH261 Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
