point PMO16BL Manual de usuario
PMO16BL&PMO20BL
User Manual
16 & 20 Litre Mini Oven
2
Thank you for purchasing your new POINT Electric Oven. These operating
instructions will help you use it properly and safely. We recommend that
you spend some time reading this instruction manual in order that you fully
understand all the operational features it oers. Read all the safety
instructions carefully before use and keep this instruction manual for future
reference.
GB
Takk for at du kjøpte denne nye POINT-elektriske ovnen. Denne
bruksanvisningen hjelper deg med å bruke den ordentlig og sikkert. Vi
anbefaler at du tar deg tid til å lese gjennom hele bruksanvisningen for å bli
fortrolig med alle funksjonene den har. Les alle sikkerhetsanvisningene nøye
før bruk, og oppbevar bruksanvisningen for fremtidig referanse.
ENNO
Kiitos, kun valitsit uuden POINT-sähköuunin. Nämä käyttöohjeet opastavat
sinua käyttämään laitetta oikein ja turvallisesti. Suosittelemme, että vietät
hetken tämän käyttöoppaan parissa, jotta ymmärtäisit täysin kaikki
laitteen tarjoamat toiminnalliset ominaisuudet.
Lue kaikki turvallisuusohjeet huolellisesti ennen laitteen käyttöä ja säilytä
käyttöopas myöhempää käyttöä varten.
ENFI
Tak for købet af din nye Kedel fra POINT. elektriske ovn. Disse
brugsanvisninger hjælper dig med at bruge den korrekt og sikkert. Vi
anbefaler, at du læser denne brugsanvisning, så du får en fuld forståelse af,
hvordan alle funktionerne virker. Læs alle sikkerhedsinstruktioner nøje før
brug, og behold denne brugsanvisning til senere reference.
EN
DK
Thank you for purchasing your new POINT elektriska ugnen. These
operating instructions will help you use it properly and safely. We
recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it oers. Read
all the safety instructions carefully before use and keep this instruction
manual for future reference.
SE
3
GBNOFIDKSE
Brugervejledning – Dansk .....................
Bruksanvisning - Norsk .........................
Käyttöopas – Suomi .............................
Bruksanvisning – Svenska ..................... sidor
12
21
30
39
side
sivu
side 38
47
29
20
11
-
-
-
-
-
User manual - English .......................... 4page
GBNOFIDKSE
4
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. Close supervision is necessary when any appliance is used by or near
children.
4. To protect against electric shock, do not place any part of the electric
oven in water or other liquids.
5. Do not let the mains power cable hang over the edge of a table or
counter, or touch hot surfaces.
6. Do not operate appliance with damaged the mains power cable or plug or
after the appliance malfunctions, or has been damaged in any manner,
return appliance to the nearest Authorized Service Center for
examination, repairation, or adjustment.
7. The use of accessory attachments not recommended by the appliance
manufacturer may cause hazard or injury.
8. When operating the oven, keep at least four inches of space on all sides
of the oven to allow for adequate air circulation.
9. Unplug from outlet when not in use, or before cleaning. Let it to cool
before putting on or taking o parts, or before cleaning.
10. To disconnect, turn the control to STOP, then unplug the plug. Always
hold the plug, but never pull the the mains power cable.
11. Do not cover CRUMB TRAY or any part of the oven with metal foil.
This may cause overheating of the oven.
12. Do not clean with metal scouring pads. Pieces can break o the pad and
touch electrical parts, creating a risk of electric shock.
5
13. Oversized foods or metal utensils must not be inserted in the electric
oven as they may create a fire or risk of electric shock.
14. A fire may occur if the oven is covered or touching flammable material,
including curtains, draperies, walls, and the like, when in operation.
Do not store any item on the oven during operation.
15. Extreme caution should be exercised when using containers constructed
if anything other than metal or glass.
16. Do not place any of the following materials in the oven: cardboard,
plastic, paper, or anything similar.
17. Do not store any materials, other than manufacturer’s recommended
accessories, in this oven when not in use.
18. Always wear protective, insulated oven mitts when inserting or removing
items from the hot oven.
19. This appliance has a tempered, safety glass door. The glass is stronger
than ordinary glass and more resistant to breakage. Tempered glass can
break, but the pieces will not have sharp edges. Avoid scratching door
surface or nicking edges. If the door gas a scratch or nick, contact our
consumer relations line before using the oven.
20. Do not use outdoors.
21. Do not use appliance for any other use than intended use.
22. This appliance is for HOUSEHOLD USE ONLY.
23. The temperature of the door or the outer surface may be higher when the
appliance is working.
24. Protect against hurt by sharp edge when action.
25. Temperature of accessible surfaces may be high when the appliance is
operating.
26. Do not rest cooking utensils or baking dishes on glass door.
27. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction c
oncerning use of the appliance by a person responsible for their safety.
GB
6
28. Children should be supervised to ensure that they do not play with the
appliance.
29. The weight of the food which is put on the Food Tray/Grill Rack can not
be over 3.0kg.
30. For appliance with type Y attachment, if the supply cord is damaged, it
must be replaced by the manufacturer, its services agent or similarly
qualified persons in order to avoid a hazard.
31. Rear surface of appliances should be placed against a wall.
32. WARNING: This appliance includes a heating function. Surfaces, other
than the functional surfaces may develop high temperatures. Since
temperatures are perceived dierently by dierent people, this device
should be used with CAUTION. Hold the appliance exclusively to grip
surfaces intended to hold and use such heat protection measures as
heat protection Gloves or pot holders. Areas which are not intended to
grips must be given sucient time to cool.
33. Do not place on or near a hot gas or electric burner, or in a heated oven.
34. Extreme caution must be used when moving an appliance containing
hot oil or other hot liquids.
35. Turn the timer control to “OFF” position to shut o the appliance.
36. Appliances are not intended to be operated by means of an external
timer or separate remote-control system
37. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
38. Children shall not play with the appliance.
39. Cleaning and user maintenance shall not be made by children without
supervision.
40. Keep the appliance and its cord out of reach of children less than 8 years
old.
CAUTION: APPLIANCE SURFACES ARE HOT AFTER USE.ALWAYS wear
7
COMPONENTS(for model PMO16BL):
Before Using Your Electric Oven
Before using your convection electric oven for the first time, be sure to:
1. Unpack the unit.
2. Remove all racks and pans. Wash the racks and pans in hot sudsy water.
( N0 DISHWASHER! ).
3. Thoroughly dry all accessories and re-assemble in oven. Plug oven into
outlet and you are ready to use your new Electric Oven.
4. After re-assembling your oven, we recommend that you run it at MAX
temperature for approximately 15 minutes to eliminate any packing oil
that may remain after shipping.
Function control
Timer control
Thermostat control
Indicator
COMPONENTS(for model PMO20BL):
Thermostat control
Function control
Indicator
Timer control
GB
protective, insulated oven gloves when touching hot oven or hot dishes
and food, or when inserting or removing rack, pans or baking dishes.
Heating element
Glass door
Door handle
Heating element
Glass door
Door handle
Crumb tray
Food tray handle
Wire rack
Food tray
Crumb tray
Food tray handle
Wire rack
Food tray
8
Using Your Electric Oven
Please familiarize yourself with the following oven functions and accessories
prior to first use:
1) Glass Door: For front viewing of food.
2) Heating Element: For heating food.
3) Wire rack：For carrying food to be cooked.
4) Food Tray: For carrying food to be cooked.
5) Food Tray Handle：For removing rack or tray.
6) Crumb Tray: For collecting fallen oil or crumb.
7) Thermostat knob: choose desired temperature from Low- 90°C- 230°C(Low is
cooking at the room temperature)
8) Timer knob: turn control to the left: "Stay On"(counter - clockwise) and the
oven will STAY ON until manually shut o. To activate timer, turn to right
(clockwise) for other use. A bell will sound at end of programmed time.
9) Function knob: there are three modes( standby mode, upper heating
elements, lower heating elements, upper and lower heating elements).
Control Panel
9
OPERATION INSTRUCTIONS
1. FUNCTION &
This function is ideal for cooking cake in general.
Operation
(1) Place the food to be cooked on the grill rack. Insert the rack into the middle
support guide of the oven.
(2) Turn the function knob to or as needed.
(3) Set the Thermostat knob to 230°C.
(4) Set the Timer knob to the desired cooking time.
(5) To check or remove food ,use the handle to help side food in and out.
(6) When toasting is complete, a bell will sound and the Timer knob will back to
o position automatically. Open door completely and remove the food
immediately or the heat remaining in the oven will continue to toast and dry
out your toast.
CAUTION: Cooked food, metal rack, and door can be very hot, handle with care.
2. FUNCTION
This function is ideal for cooking bread, pizza, and fowl in general.
Operation
(1) Place the food to be cooked on the grill rack / food tray. Insert the rack/tray
into the middle support guide of the oven.
(2) Turn the Function knob to .
(3) Set the Thermostat knob to the desired temperature as needed or recipe.
(4) Set the Timer knob to the desired cooking time.
(5) To check or remove food ,use a handle to help side food in and out.
(6) When toasting is complete, a bell will sound the Timer knob will back to o
position automatically. Open door completely and remove the food
immediately or the heat remaining in the oven will continue to toast and dry
out your toast.
CAUTION: Cooked food, metal rack, and door can be very hot, handle with care.
USE MAINTENANCE INSTRUCTIONS
This appliance requires little maintenance. It contains no user serviceable parts.
Do not try to repair it yourself. Contact a qualified appliance repair technician if
the product requires servicing.
CLEANING INSTRUCTIONS
CAUTION: To protect against electrical shock, DO NOT IMMERSE THE OVEN IN
WATER OR ANY OTHER LIQUIDS.
GB
10
Your toaster oven should be cleaned regularly for best performance and long life.
Regular cleaning will also reduce the risk of fire hazard.
Step 1. Remove plug from electrical outlet. Allow it to cool.
Step 2. Remove the Removable Crumb Tray, Rack, Tray by pulling out of the oven.
Clean them with damp, soapy cloth. Make sure to only use mild, soapy
water.
Step 3. To clean inside of oven, wipe the oven walls, bottom of oven, and glass
door with a damp, soapy cloth. Repeat with a dry, clean cloth.
Step 4. Wipe outside of oven with a damp cloth.
CAUTION: DO NOT USE ABRASIVE CLEANERS OR METAL SCOURING PADS.
Make sure to only use mild, soapy water. Abrasive cleaners, scrubbing brushes
and chemical cleaners will damage the coating on this unit. Pieces can break o
the coating and touch electrical parts involving a risk of electrical shock.
Step 5. Allow the appliance to cool and dry completely before storing. If storing the
oven for long periods of time, make certain that the oven is clean and free
of food particles. Store the oven in a dry location such as on a table or
countertop or cupboard shelf. Other than the recommended cleaning, no
further user maintenance should be necessary.
Any other servicing should be performed by an authorized service representative.
TO STORE
Unplug unit, allow it to cool, and clean before storing. Store the Electric Oven in its
box in a clean, dry place. Never store appliance while it is hot or still plugged in.
Never wrap cord tightly around the appliance. Do not put any stress on the cord
where it enters the unit, as it could cause the cord to fray and break.
SPECIFICATION:
Model
PMO16BL
PMO20BL
Rated voltage
220-240V 220-240V
Rated frequency
50-60Hz 50-60Hz
Rated power
1200W 1400W
Oven capacity
16 Litres
20 Litres
Household use only , DO NOT IMMERSE IN WATER
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Idiomas:
Otros manuales de Horno de point
