PNI Safe House IDB12 Manual de usuario
PNI Safe House IDB12
EN User manual .................................................. 2
BG Ръководство за употреба ......................... 14
DE Benutzerhandbuch ....................................... 26
ES Manual de usuario ......................................... 38
FR Manuel utilisateur ......................................... 50
HU Használati utasítás ........................................ 62
IT Manuale utente ............................................. 74
NL Handleiding ................................................... 86
PL Instrukcja obsługi .......................................... 98
RO Manual de utilizare ........................................ 110
User manual - 2
PNI Safe House IDB12
WiFi video doorbell with chime
User manual - 3
Safety warnings
• To power the two units, do not use a
voltage other than that recommended by
the manufacturer.
• The battery is factory-installed in the
outdoor unit. Connect the USB cable
included in the package to the USB-C port
on the unit to charge the battery.
• The chime can be powered by a DC5V 1A
phone charger or directly into a computer’s
USB port.
• Protect the outdoor unit from direct rain,
snow or sun.
• The outdoor unit only supports 2.4GHz
WiFi connection, it does not support
5GHz.
User manual - 4
Product presentation
1
2
3
4
5
7
6
8
9
10
11
12
13
1. Microphone
2. Lens
3. Light sensor
4. LED indicator
5. Call key
6. IR LEDs
7. Loudspeaker
8. USB C port
9. LED indicator
10. Pairing key
11. Volume +/-
12. Ringtone
13. Loudspeaker
User manual - 5
Tuya Smart app
Warning: due to Tuya Smart application
updates, there could be dierences
between the images and information
presented in this manual.
1. Download the Tuya Smart app from
Google Play or the App Store or scan the
QR code below:
Android iOS
2. Open the application, create an account
and log in.
Automatic configuration
1. Awake the doorbell by pressing the call
User manual - 6
button on the external unit. The indicator
LED on the external unit blinks, indicating
that the device is in pairing mode. If the
LED does not blink, press the pairing key
for 10 seconds.
2. In your phone, activate the Bluetooth
and GPS Location functions.
3. Open the Tuya Smart application. The
application will automatically scan nearby
Bluetooth devices.
4. After your device has been identified,
press “Add”.
5. Select the WiFi network you want to
connect to and add the network password.
6. Wait for the device to be added to the
application. To finish, press “Done”.
User manual - 7
User manual - 8
Manual configuration
1. Awake the doorbell by pressing the call
button on the external unit. The indicator
LED on the external unit blinks, indicating
that the device is in pairing mode. If the
LED does not blink, press the pairing key
for 10 seconds.
2. In your phone, activate the Bluetooth
and GPS Location functions.
3. Press the “+” - “Add Device” button.
4. Select “Camera & Lock” - “Doorbell
Camera”.
5. If the LED indicator on the camera
blinks, press “Next”. The application will
scan nearby devices.
6. Select the WiFi network you want to
connect to and add the network password.
7. Wait for the device to be added to the
application. To finish, press “Done”.
User manual - 9
User manual - 10
Technical specifications
Camera resolution 640x360px/15fps
Sensor 480P CMOS
Lens 1.7 mm
View angle 75°
Power supply
Camera: Li-Ion
3.7V 800mAh
battery
Buzzer: 5V
Current In standby: 30mA
Max.: 70mA
WiFi frequency 2.4GHz
WiFi transmission
power 100mW
RF frequency 433MHz
