pleasant hearth JUNIPER Manual de usuario
30-10-206 Rev. 08/05/2020
Serial Number Purchase Date
ATTACH YOUR RECEIPT HERE
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST, Monday – Friday, or
34" JUNIPER SLATE FIRE PIT
MODEL #OFW707RI
Français p. 17
Español p. 9
1
A
H
I
J
K
A
D
C
B
E
F
G
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Poker Bracket 1
B Mesh Cover 1
C Table Lid 1
D Cooking Grid 1
E Wood Grate 1
F Fire Bowl 1
PART DESCRIPTION QUANTITY
G Ash Catcher 1
H Slate Top 1
I Leg 4
J Support Ring 1
K Poker 1
2
Please read and understand this entire manual before attempting to assemble, operate or install the
product. If you have any questions regarding the product, please call customer service at 1-877-447-4768,
8:00 a.m. – 4:30 p.m. CST, Monday – Friday.
WARNINGS:
• DO NOT allow children or pets near the re pit without supervision.
• DO NOT touch surface of re pit while in use.
• FOR OUTDOOR USE ONLY! Burning wood or charcoal indoors can kill you. It gives off carbon
monoxide, which has no odor.
• NEVER burn in vehicles, tents, garages, other enclosed areas or indoors. CARBON MONOXIDE
HAZARD.
• NEVER LEAVE FIRE UNATTENDED!
• NEVER place a storage cover on the re pit when in use. Ensure the re pit and mesh cover have
cooled before placing a storage cover over the re pit.
• When the re pit is in use, the poker bracket on the mesh cover can reach extreme temperatures
that can cause serious injury to an unprotected hand. Use a poker when handling.
• DO NOT use under overhead cables or power lines.
CAUTIONS:
• Adequate re extinguishing material should be readily available.
• Always ensure that the mesh cover is secured over re bowl while in use.
• Burn only seasoned hard wood or re logs in the re pit.
• DO NOT attempt to move the re pit while it is hot or in use.
• DO NOT use gasoline or kerosene to start the re in your re pit.
• DO NOT use this outdoor re pit under any overhead or near any unprotected combustible
constructions. Avoid using near or under overhanging trees and shrubs. DO NOT use this unit on
long or dry grass and/or leaves.
• Always use this outdoor re pit on a hard, level, non-combustible surface such as concrete, rock or
stone. An asphalt or blacktop surface may not be acceptable for this purpose. DO NOT use on
wooden decks.
• Place the re pit no closer than 10 feet / 3.05 meters from walls or combustibles during use.
• Poker bracket may become hot during and after use.
• Use heat-resistant gloves to handle hot tools.
• Burn only 5LBs/2.27KG of charcoal, wood or re logs in the re pit.
SAFETY INFORMATION
M5 x 10mm
Bolt
Qty. 3
M5 Nut
Qty. 3 M6 x 18mm
Bolt
Qty. 4
M6 Nut
Qty. 8 Wrench
Qty. 1
HARDWARE LIST
AA BB CC DD EE FF
3
This product and the fuels used to operate this product (charcoal or wood), and the products of
combustion of such fuels, can expose you to chemicals including carbon black, which is known
to the State of California to cause cancer, and carbon monoxide, which is known to the State of
California to cause birth defects or other reproductive harm.
For more information go to www.p65Warnings.ca.gov
WARNING
M6 Flange
Nut
Qty. 1
DD
AA
1
2
FF
BB
FF
DD
B
A
F
G
AA
BB
PREPARATION
ASSEMBLY INSTRUCTIONS
1. Insert the poker bracket (A) into the hole in the
mesh cover (B). Use the wrench (FF) to secure
the M6 ange nut (DD) to the underside of the
mesh cover (B).
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents above. If any part is missing or damaged, do not attempt to
assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 15 minutes
Tools Required for Assembly: Phillips Screwdriver (Not Included) and Wrench (Included)
EE
Hardware Used
M6 Flange Nut x 1
2. Attach the ash catcher (G) to the re bowl (F)
using three M5 x 10mm bolts (AA) and three
M5 nuts (BB). Tighten with the wrench (FF)
and a screwdriver.
EE
Hardware Used
M5 x 10mm Bolt x 3
Wrench
M5 Nut x 3
Wrench
4
3
4
5
I
CC
J
EE
I
H
F
K
B
E
CC
EE
FF
3. Attach the support ring (J) to the legs (I) using
four M6 x 18mm bolts (CC). Secure with a
screwdriver but do not tighten at this time.
4. Lay the slate top (H) upside down on the oor
on a carpet or blanket to avoid scratching. Attach
the legs (I) to the slate top (H), using eight M6
nuts (EE). Tighten all screws (including screws
from step 3) with a screwdriver and the wrench
(FF).
5. Turn the slate top assembly right side up. For
repit use, put the bowl (F) onto the slate
top assembly, then put the wood grate (E) into
the bowl (F). Put the mesh cover (B) onto the
bowl (F). Keep the poker (K) near the re pit
for use anytime.
ASSEMBLY INSTRUCTIONS
Hardware Used
M6 x 18mm Bolt x 4
Hardware Used
M6 Nut x 8
Wrench
5
6
7
F
D
F
C
B
D
E
J
K
ASSEMBLY INSTRUCTIONS
6. For barbeque use, remove the mesh cover and
put the cooking grid (D) onto the bowl (F). Keep
the poker (K) near the re pit for use anytime.
Replace the mesh cover (B) using the poker
(K) when re is lit.
7. For table (leisure) use, place the mesh cover
(B) upside down onto the support ring (J). Put
the bowl (F) onto the slate top assembly, put the
wood grate (E) into the bowl (F), and put the
cooking grid (D) into the bowl (F). Set the table
lid (C) on top of the bowl (F).
6
CARE AND MAINTENANCE
• Allow the re pit to cool completely before moving the re pit.
• To extend the life of your re pit, clean it after each use.
• To protect the re pit nish, use a soft cloth to wipe the re pit and poker.
• Do not attempt to clean while hot.
• Store in a cool, clean, dry place.
• Use gloves in lieu of bare hands while handling.
• Place a storage cover over the re pit once it has cooled.
• Clean ash catcher after each use once ashes have cooled.
1-YEAR LIMITED FRAME WARRANTY
If within one year from the date of original purchase, this item fails due to a defect in material or
workmanship, we will replace or repair at our option, free of charge. To order parts or to obtain
warranty service, call 1-877-447-4768, Monday - Friday, 8:00 a.m. - 4:30 p.m. CST. This warranty
does not cover defects resulting from improper or abnormal use, misuse, accident, or alteration.
Failure to follow all instructions in the owner's manual will also void this warrranty. The
manufacturer will not be liable for incidental or consequential damages, or common erosion of
outdoor products. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you. This warranty gives you
specic legal rights, and you may also have other rights which vary from state to state.
7
GHP Group, Inc.
6440 W. Howard St.
Niles, IL 60714-3302
877-447-4768
A
H
I
J
K
A
D
C
B
E
F
G
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m.,
CST, Monday – Friday.
Printed in China
8
PART DESCRIPTION PART #
A Poker Bracket 40-07-453
B Mesh Cover 30-06-376
C Table Lid 30-05-002
D Cooking Grid 30-01-254
E Wood Grate 30-01-002
F Fire Bowl 30-01-317
G Ash Catcher 40-08-116
H Slate Top 30-01-320
I Leg 30-01-005
J Support Ring 30-06-001
K Poker 40-04-409
AA - FF Hardware Pack 30-09-001
N/A Instruction Manual 30-10-206
30-10-206 Rev. 08/05/2020
