Plantronics Calisto 610 Manual de usuario

Calisto 610

Corded USB Speakerphone

User Guide

Contents

Welcome 3

System Requirements 3

What's in the box 4

Speakerphone Controls 5

Connect PC and Call 6

Plantronics Hub Software 7

Devices Tab 7

Applications Tab 7

Troubleshooting 8

Congratulations on purchasing your new Plantronics Calisto 610 corded USB speakerphone. This

user guide contains instructions for setting up and using your Calisto 610 speakerphone.

Calisto 610 highlights and features

• Personal corded speakerphone peripheral device.

• Connects to your PC.

• Full duplex audio, hear and be heard as naturally as speaking face-to-face.

• 360° microphone coverage.

• Integrated call control and other features via Plantronics Hub software.

• Softphone and Uniﬁed Communications client call control features - call answer/end, volume up/

down, microphone mute/un-mute, call reject.

• Small and portable, includes carrying case.

NOTE Please refer to the separate safety instructions for important product safety information

prior to installation or use.

Computer

• Supported operating systems: Windows XP SP3 or later, Windows Vista SP1 or later, Windows 7

SP1, Windows 8 and Windows 10

• Processor: 400 MHz Pentium processor or equivalent (minimum); 1 GHz Pentium processor or

equivalent (recommended)

• RAM: 96 MB (minimum); 256 MB (recommended)

• Hard disk: 1.5GB (minimum); 3GB (recommended)

Welcome

System Requirements

Carrying case Corded speakerphone

What's in the box

1Volume Up/Volume Down Buttons

Increase/decrease volume Press up/down volume buttons to desired volume

Maximum or minimum volume Hold up/down buttons until max/min reached

Ringer volume Press up/down volume buttons while no call is active

2Mute Button

Mute microphones (far-end cannot hear

you)

1 short button press mutes mics; Mute LED turns

solid red

Un-Mute microphones 1 short button press un-mutes microphones; Mute LED turns off

Reject an incoming call 1 long button press (2 seconds); call rejected

3Call Button

Answer or end a call 1 button press

Answer a 2nd call while on a call 1 button press ends ﬁrst call, 2nd 1 short button press answers

2nd call

Speakerphone Controls

1The speakerphone will power on once it is connected to the PC.

NOTE Do not insert directly into a docking station or hub.

2The Plantronics logo will illuminate once the speakerphone is ready for a call.

3Press the Call button to begin or end a call.

Connect PC and Call

Plantronics Hub software (optional) for Windows enhances your

speakerphone's capabilities, and, enhances your user experience when used

with your PC.

For example, Plantronics Hub software provides:

• Integrated call control for popular softphones and Uniﬁed Communications (UC) clients

• Enhanced UC presence capabilities - more granular availability status means fewer interruptions

• Useful Preferences settings

• Automated software and ﬁrmware updates

Hub software loads when your PC is booted up and runs discretely in the background, requiring

no user intervention except via the following:

•Plantronics Control Panel — a one stop utility for all device, application, preferences and

conﬁguration options, and product information

•Plantronics Update Manager — provides notiﬁcation and facilitates installation for your

speakerphone's ﬁrmware and Hub software updates

To launch any of these utilities, go to: Start > Programs > Plantronics

• Displays active Plantronics devices supported by Plantronics Hub software.

• Audio Settings — Provides a convenience shortcut to Windows audio conﬁguration options.

• Device Settings — No Device settings are available for Calisto 610 in Plantronics Control Panel.

• Displays all applications enabled by Plantronics Hub software and supported for Calisto 610.

• All supported applications which are currently running are in designated with a "check mark".

• Allows you to conﬁgure the behavior of supported media players when a softphone call is

received, and when the call has ended.

• Provides opt-in conﬁrmation to allow Plantronics to capture usage statistics to help improve our

software.

• Allows conﬁguration of presence information sharing with supported applications.

Plantronics Hub Software

Devices Tab

Applications Tab

How do I know Calisto 610 is turned

on? Pressing the volume +/- buttons while the unit is ON emits a

volume adjustment tone.

Is there a visual indicator on the

Calisto 610 that shows volume

level?

No. There is no visual indication of volume level or volume

adjustments on the Calisto 610.

NOTE The Calisto 610 has a mid-range default volume setting. It

provides audible indications as you adjust the volume and when you

have reached the maximum or minimum volume level.

What size room and how many

participants does Calisto 610

support for group conference calls?

There are 2 variables to consider for this answer, and both involve

the perceived audio by 8 listeners on the other (far) end of a

Calisto 610 call:

1The acoustic properties of the room: Not all rooms are created

equal, and room acoustics can vary signiﬁcantly.

2The subjective opinion (or hearing abilities) of the far-end listener(s)

which can also vary signiﬁcantly

With these variables considered, in general Calisto 610 can be

used in up to a 12x12 foot room with up to 8 participants.

Troubleshooting

NEED MORE HELP?

plantronics.com/support

Plantronics, Inc. Plantronics B.V.

345 Encinal Street

Santa Cruz, CA 95060

United States

Scorpius 171

2132 LR Hoofddorp

Netherlands

is owned by Bluetooth SIG, Inc. and any use of the mark by Plantronics, Inc. is under license. Microsoft, Lync, Windows, and Windows XP are registered

trademarks of Microsoft Corporation in the US and other countries.

Patents US 5,210,791; Patents Pending

209576-06 (06.17)
