Plantronics Blackwire C435-M Manual de usuario

Blackwire®C435-M

Headset

User guide

ContentsContentsContents

Welcome 3

System requirements 3

Registering your product online 3

Technical assistance 3

What’s in the box 4

Headset features 5

Accessories 6

Using your headset 7

Connecting the headset 7

Wearing the headset 7

Checking audio settings 9

In-line controls 10

Useful tips 11

Clothing clip 11

Stereo cable tidy 11

Hook and eye cable tidy 12

Troubleshooting 13

Welcome

Congratulations on purchasing your new Plantronics product. This guide contains instructions

for using your Blackwire C435-M headset.

Please refer to the safety instructions found in the Quick Start Guide for important product

safety information prior to installation or use of the product.

System requirements

Computer

• Supported operating systems: Windows XP®, Windows Vista®, Windows® 7

• Processor: 400 MHz Pentium® processor or equivalent (Minimum); 1 GHz Pentium processor or

equivalent (Recommended)

• RAM: 96 MB (Minimum); 256 MB (Recommended)

• Hard disk: 280 MB (Minimum); 500 MB (Recommended)

• Microsoft Windows XP - Service Pack 3 (SP3) or later (Recommended)

Microsoft Windows Vista - Service Pack 1 (SP1) or later (Recommended)

Display

• At least 800 x 600, 256 colours

• We recommend: 1024 x 768 high colour, 32-bit (Recommended)

Browser

• Internet Explorer® V6 or better must be on the user’s system (Required)

Registering your product online

Visit plantronics.com/productregistration to register your product online

so we can provide you with the best possible service and technical support.

Technical assistance

Visit our web site at plantronics.com/support for technical support including frequently asked

questions, compatibility and accessibility information.

Large and small ear gels and mono connector cover

Carrying caseBlackwire C435-M headset

What’s in the box

Headset features

1 Noise-cancelling microphone

2 Right speaker

3 Right ear loop

4 Ear gel (ﬁtted)

5 Left ear loop

6 Ear gel (ﬁtted)

7 Left speaker

8 Stereo cable tidy

9Mono/stereo connection

10 In-line control

11 Mute/unmute

12 Volume up/volume down

13 Call answer/end

14 USB connector

2 3 4 5 6 7

131198 1210

Accessories

(Sold separately)

Headband and case For those who would prefer a neckband wearing style. An accessory (with

its own larger case) is available as an option.

Connecting the headset

Simply plug the headset into the USB port on your PC.

Wearing the headset

The headset comes ﬁtted with the ear loop and medium ear gel.

1 To wear the headset, simply place the ear gel in your ear with the loop at the top of your ear

and rotate the microphone boom forwards. The microphone should be pointed to the corner of

your mouth. If it cannot be comfortably positioned there, you can rotate the ear loop and gel to

ﬁt your ear.

Using your headset

2 The headset comes conﬁgured with the microphone on the left but it’s very simple to switch

the microphone to your right ear if you prefer that conﬁguration. Simply pull the ear loops off

the speaker, rotate them and replace.

3 The headset comes with medium ear gels already ﬁtted. If you ﬁnd that the headset is

uncomfortable or unstable, you can easily change the gel to suit. Simply unpeel the gel that is

on the speaker and replace with a different one.

Large Small

4 Once the headset is positioned on your head, adjust the ﬂexible boom to place the tip closer to

the corner of your mouth. The boom can be shaped to follow the curvature of your face.

50.8

5 For those users who do not want speakers in both ears (all the time or just occasionally),

you can disconnect the second speaker at the connection point shown below. This will

automatically change the headset from stereo to mono (and vice versa when reconnecting)

*The headset is supplied with a cover for the connector when conﬁgured as a mono headset.

Checking audio settings

1 Ensure Microsoft®Lync™/Microsoft® Ofﬁce Communicator is running on PC.

Check that the C435-M is set as the audio device in audio device settings under tools.

2 Place a call using Microsoft Lync/Ofﬁce Communicator.

3 For non-Lync/Communicator applications, conﬁrm the speaker and microphone settings for the

PC softphone are set to Plantronics C435-M.

• To check in Windows 7:

Go to Control Panel -> Sound -> Playback tab, and set the Plantronics C435-M device as both

the Default Communications Device and the Default Audio Device. In the Playback tab, this is

indicated by the green tick mark.

• To check in Windows XP:

Go to Control Panel -> Sounds and Audio Devices, and in the Audio tab set the Plantronics C435-M

for both the Sound playback and Sound recording sections. In the Voice tab, select the

Plantronics C435-M item for both the Voice playback and Voice recording sections.

IMPORTANT For your safety, do not use headset at high volumes for extended periods

of time. Doing so can cause hearing loss. Always listen at moderate levels. For more

information on headsets and hearing visit: plantronics.com/healthandsafety.

1010

In-line controls

Call answer/end Can be used to answer or end a call directly from the headset with a single press.

LED will ﬂash green when a call is coming in and be solid green when on a call.

Volume Volume up and down are available.

Mute A single press of the mute button will mute the microphone. A red LED will be

on when you are muted. Pressing this button again will take the microphone off

mute.
