Plantronics LX1 Manual de usuario

LX1 adapter

User Guide

Contents

Overview 3

Set up 4

Support 5

3.5 mm

LED

Red = Mute

Blue = Balanced mode

Green = Independent mode

EQ settings (short press)

Single tone = Pure EQ maintains high frequencies

Double tone = Intensify EQ emphasizes mid-range sounds

Triple tone = Seismic EQ boosts bass

Mode settings (press and hold for 4 seconds)

Balance mode = The top dial controls master volume and the bottom dial controls game and chat

volume

Independend mode = The top dial controls game volume and the bottom dial controls chat

volume

Tap to mute your mic (LED turns red)

Top dial

Balance mode = Controls master volume

Independent mode = Controls game volume

Bottom dial

Balance mode = Balances game and chat volume

Independent mode = Controls chat volume

Headset port

3.5mm stereo AUX input

NOTE Balance mode is the default setting.

Overview

The adapter is compatible with the Xbox One first and second generation wireless controllers.

1Plug the adapter into a compatible Xbox One controller.

2Power on the Xbox One controller. It may take the adapter up to 10 seconds to boot up. The LED

turns on for 2 seconds to indicate power.

00:00:10

3Connect a headset to the adapter in the 3.5 mm jack.

4Choose how you want the dials to be configured. By default, the adapter is set to Balance mode.

Press the EQ button for 2 seconds to switch between Balance and Independent mode.

•Balance mode In Balance mode (blue LED) the top dial controls master volume and the bottom dial

balances game and chat.

•Independent mode In Independent (green LED) mode the game and chat channels are split; the top

dial controls game volume and the bottom dial controls chat volume.

5Choose an EQ setting. Cycle through the EQ modes by tapping the EQ button.

Tap the EQ button and hear EQ mode

one tone Pure EQ maintains high frequencies.

two tones Intensify EQ emphasizes mid-range sounds.

three tones Seismic EQ boosts bass.

6Optional Plug a device into the 3.5 mm jack, if you want to listen music while gaming.

Set up

Tel: 0800 410014

Tel: 0800 117095

Tel: 80011336

Tel: +44 (0)1793 842443*

Tel: 0800 945770

Tel: +44 (0)1793 842443*

Tel: 1800 551 896

Tel: 0800 84 45 17

Tel: 80 88 46 10

Tel: +44 (0)1793 842443*

Deutschland 0800 9323 400

Österreich 0800 242 500

Schweiz 0800 932 340

Tel: +44 (0)1793 842443*

Tel: 8-800-100-64-14

Tel: +44 (0)1793 842443*

Tel: 800 950934

Tel: 0200 21 46 81

Tel: 900 803 666

NL 0800 7526876

BE 0800 39202

LUX 800 24870

Tel: +44 (0)1793 842443*

*Support in English

For warranty details, go to plantronics.com/warranty.

Support

NEED MORE HELP?

plantronics.com/support

Plantronics, Inc. Plantronics BV

345 Encinal Street

Santa Cruz, CA 95060

United States

South Point Building C

Scorpius 140

2132 LR Hoofddorp, Netherlands

Plantronics, Inc. All other trademarks are the property of their respective owners.

Patents pending.

205961-06 (10.15)
