Planet Audio P9740 Manual de usuario
1.Welcome
2.Warning
3.Note
4.Features
5.Basic Operation
6.Panel Arrangement
7.Basic Functions
8.Main Menu Touch Operation
9.OSD Setup
10.Remote Control Function
11.Disc Play Touch Operation
12.DVD Mode
13.RDS User Operation
14.Radio Operation
15.DVD Basic Operation
16.VCD Basic Operation
17.CD Basic Operation
18.MP3/USB/SD Operation
19.Other Play Mode
20.CCD/Trouble Shooting
21.Wiring Diagram
22.Specifications
23.Accessory
2
3
3
4
5
6
7
8
10
11
13
15
17
19
21
22
32
35
37
38
39
40
41
42
And
P9740
1.WELCOME
1. Please keep the disc slot clean, wipe it off when there is some dirt on it. You should
wipe off any dirt on the disc before you place it into the unit. If the disc is dirty and you
place it inside the unit, it will cause the unit to go into an error and will not play the
disc. Please ask professional to clean the laser.
2. Playing the radio at higher volumes for a long period of time may cause hearing
issues. You should play this unit at a moderate listen level.
3. This unit is set up by precision parts. If you open up this unit, you will void any and
all of your warranty.
4. Please do not touch LCD display with any hard object so that you prevent it from
getting scratched or damaged.
5. To avoid an accident caused by watching the LCD screen. This unit has a vehicle
lock out wire so that you will not be allowed to watch a video while driving down the
road.
6. This unit is meant for a 12V power and negative ground system from a vehicle.
NOTE:
We keep improving this product all the time. There may be some changes in it that are
not in this manual.
23.ACCESSORY
Accessory Quantity
User Manual 1PC
Wire
USB Cable
Warranty card
1PC
1PC
2PCS
3
42
INSTRUCTIONS INSTRUCTIONS
Thank you for enjoying our serirs of digital car A/V product.
To properly use this product, please go through this instruction manual for installation
and operation, put it in a safe place for future use!
2.WARNING
Remote Controller 1PC
3.NOTE
● This unit can play the following disc
Power supply
Power range
Max operate current
Dimensions
Ground system
FM tuner
European frequency range
Signal/Noisse ratio
Stereo separation
Search station volt
Distortion rate
AM tuner
Limit noise sensitivity
DVD PLAYER
Signal/Noise ratio
Frequency response
DC 12V
10.8-16.0V DC
10A
178X153X101MM
Negative ground
87.5-108MHz
55dB
30dB
20-30dBuv
1.5%
522-1620KHz
32dB
70dB
20Hz-20KHz
22.SPECIFICATIONS:
USA frequency range 87.5-107.9MHz
European frequency range
USA frequency range 530-1710KHz
Amp Rating 85 Watts x 4 Channels
4 41
INSTRUCTIONS INSTRUCTIONS
4.FEATURES
INSTRUCTIONS INSTRUCTIONS
DVD PLAYER
1. MPEG-4 Decoder Technology
2. Compatible with MP4 (AVI/5.X), DVD (DVD-R/DVD-RW), VCD,
SVCD, CD-RW, WMA, MP3, JPG
3. Supporting Multiple Subtitles, Angles, Languages
4. Child lock function
5. 4-Channel Audio Output
6. Pause, Play, Up/Down, Stop, Zoom, PBC Function
RADIO
1. AM/FM Radio Tuner
2. 30 Radio Preset Stations (18FM, 12AM)
LCD DISPLAY
1. 7” - 16:9 TFT LCD Display
2. Touchscreen
21.WIRING DIAGRAM
5
40
Blue/white-Remote Amp Turn On
VOL BAS TRE L/R
F/R
5.BASIC OPERATION 20.CCD(Back-Up Camera)
INSTRUCTIONS INSTRUCTIONS
6.PANEL ARRANGEMENT
7
38
19.OTHER PLAY MODE
1.SOURCE Button
2.Mute Button
3.VOL- Button
4.VOL+ Button
5.DN Button
6.UP Button
7.Menu Button
8.OPEN Button
9.RESET Button
10.Remote Control Receiver
11. AUX IN
12.MINI USB Port
INSTRUCTIONS INSTRUCTIONS
7.BASIC FUNCTION
8 37
1.SOURCE Button
press this button to power on,press this button longer to power off.In normal situation,
press this button can switch the playing mode.
2.
3.VOL- Button
Press this button shortly increase volume level one step by one step.
Press this button longer increase volume level continuously.
4.VOL+ Button
Press this button shortly decreasa volume level one step by one step.
Press this button longer decreasa volume level continuously.
5.
6.
7.MENU Button
press this button to back to the main menu in any made.
8.OPEN Button
Press this button can eject the disc.
9.RESET Button
Press this button and this unit will be restored to the initial state.
10.REMOTE CONTROL RECEIVER
It is able of receiving infrared signals launched by the remote control matching the unit.
MUTE / TFT on/off Button
Press this button to shut off the sound output, re-press this button can resume the sound
output, long press this button can turn off the TFT LCD display.
DN Button
Short press this button to make the monitor glide down steply; Long press this button to
make the monitor glide down to the lowest position.
UP Button
Short press this button to make the monitor glide up steply; Long press this button to
make the monitor glide up to the top position.
10. CD Program Play
In CD mode, you can set the sequence of playing by the program function, the operation
is as follows:
When CD is playing, press ST/PROG button, then the display shows:
Input the number of the song you want to program by the remote control, program the
first song, input your desired song, for example, the sixth song, and press number button
6 on the remote control. Program the second song, press button move the cursor to
2 . Input your desired song, for example, the ninth song, press number button 9 on
the remote control. Press button to program play.
Back to the normal mode, press the ST/PROG button, then press button.
Note: This function can only be worked by the remote control.
PROG
TC
3__:__
4__:__
TC
7__:__
8__:__
5__:__
6__:__
TC
11__:__
12__:__
9__:__
10__:__
TC
15__:__
16__:__
13__:__
14__:__
PLAY DELETE
1__:__
2__:__
9
36
11.AUX IN
External connected audio input.
12.MINI USB PORT
Connect the USB memory to this socket,and the unit can play music format files supported
by this unit in the USB memory.
BASE
13.Disc Slot
14.Slot indicator light
15.SD Slot
13 14 15
INSTRUCTIONS INSTRUCTIONS
8.MAIN MENU TOUCH OPERATION
RADIO
AUX INPUT
DVD
BLUETOOTH
USB/SD
GPS
POWER
OSD SET
TV CDC
*This unit without CDC/TV/GPS/BLUETOOTHfunction.
Slide in CD/MP3 disc, unit will play it automatically. If disc is in slot, press DVD touch
button on main menu can to play.
1. Repeat Play
In CD/MP3 mode, press AMS/RPT button on remote control, to startup following, repeat
CD disc: Single song repeat→ Repeat play off.
MP3 disc: Single song repeat→Directory repeat→ Repeat play off.
2. Fast Forward/Fast Rewind
Press SEEK + / SEEK - button on remote control, or / touch button on display to
speed forward or backward playing.
Note: Hold above button a bit longer to operate.
3. Previous/Next Song Play
In playing mode, press SEEK + / SEEK - on remote control, or / touch button on
display to choose previous/next song.
4. Pause Play
In play mode, press button on remote control, or button on display to pause.
Press again to go back to normal play.
5. Stop Play
In play mode:
1) Press button on remote control to enter the pause mode, the position will be stored
in unit. At that time, press button on remote control or touch button on display to
resume playing at the stored position.
2) Press button on remote control twice to enter into stop mode, here, press
button on remote control or touch button on display, unit will play from the first song.
6. OSD
In playing mode, short press OSD on remote control to show all information of present
disc.
7. Randomly Play
In CD mode, press LOC/RDM button on remote control, to instantly play each song.
Press again to back to the normal play.
8. EQ Mode
1) This function can only be worked by remote control.
2) When playing CD/MP3, press the “ZOOM” button on the remote control, you can
choose the sound mode.
3) When enter this function, press the button / / / to move the course to select
sound mode which in the system menu, after your selection position will show red color
to indicate the confirmation.
9. OPEN
Press OPEN button on panel to eject disc.
17.CD BASIC OPERATION
10 35
PROG
TC
3__:__
4__:__
TC
7__:__
8__:__
5__:__
6__:__
TC
11__:__
12__:__
9__:__
10__:__
TC
15__:__
16__:__
13__:__
14__:__
PLAY DELETE
1__:__
2__:__
14. PBC (MENU) Play
In VCD mode, press this button then play the PBC and display will show whole menu
in disc, work with number button to choose song. When you are playing either song
of the PBC, and you want to stop to select another song, press the button to turn off.
Note:
1) This function can be worked by the control.
2) PBC is suitable for the SVCD and VCD 2.0 disc.
3) In PBC mode, you can not press number button only to choose song.
15. VCD Program Playing
In VCD mode, you can set playing sequence of songs by program play function.
The program playing operation steps are as follows:
In VCD mode, press ST/PTOG button, display will show:
Input the songs which you want to programmed by the number buttons on remote control.
For example: Program the first song, input your desires song, for example, the fourth song,
and press number button 4 on the remote control. Program the second song, press
button move the cursor to 2 . Input your desired song, for example, the eighth song,
press number button 8 on the remote control. Press button to program play. Back to
the normal mode, press the ST/PROG button, then press button.
Note: This function can only be worked by the remote control.
11
34
9.OSD SETUP
