Planar PT1985P Manual de usuario
PT1975R / PT1911MX /
PT1975S / PT1985P
Touch Screen LCD Monitors
USER’S GUIDE
www.planartouch.com
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright. All rights
are reserved. No part of this document may be reproduced, translated to another lan-
guage or stored in a retrieval system, or transmitted by any means, electronic,
mechanical, photocopying, recording, or otherwise, without prior written permission.
Windows is a registered trademark of Microsoft, Inc.
Other brand or product names are trademarks of their respective holders.
Important Recycle Instructions:
Lamp(s) inside this product contains mercury. This product may contain other
electronic waste that can be hazardous if not disposed of properly. Recycle or dispose in
accordance with local, state, or federal Laws. For more information, contact the Electronic
Industries Alliance at WWW.EIAE.ORG. For lamp specific disposal information check
WWW.LAMPRECYCLE.ORG.
For more information on how to recycle your product, please visit
WWW.PLANARSYSTEMS.COM/GREEN.
1
Table of Contents
Usage Notice ...........................................................................3
Precautions .........................................................................................3
Introduction .............................................................................4
About PT1957R / PT1911MX / PT1975S / PT1985P ..........................4
Touch Screen for PT1975R..........................................................5
Touch Screen for PT1911MX .......................................................5
Touch Screen for PT1975S..........................................................5
Touch Screen for PT1985P..........................................................6
Package Overview ..............................................................................7
Installation ...............................................................................8
Product Overview................................................................................8
Front View......................................................................................8
PT1975R / PT1911MX / PT1975S Bottom View............................8
PT1985P Bottom View...................................................................8
Start Your Installation ..........................................................................9
Connecting the Display (Figure 12.1)................................................ 11
Kensington Security Slot ...................................................................13
VESA Mount your monitor.................................................................14
Remove the Deskstand..............................................................15
User Controls ........................................................................16
Side Panel Controls ..........................................................................16
How to Use the OSD Menus .............................................................17
On-Screen
Display
Menus
.............................................................19
2
Appendix................................................................................20
Troubleshooting ...........................................................................................20
Warning Signal.............................................................................................21
No Signal ................................................................................................21
Going to Sleep.........................................................................................21
Out of Range ...........................................................................................21
Product Dimensions.....................................................................................22
Compatibility Modes.....................................................................................24
Touch Screen Driver Installation..................................................................25
Product Registration and Technical Support ...............................................31
3
0
Usage Notice
Warning-To prevent the risk of fire or shock hazards, do not
expose this product to rain or moisture.
Warning-Please do not open or disassemble the product as
this may cause electric shock.
5
Precautions
Follow all warnings, precautions and maintenance as recommended
in this user’s manual to maximize the life of your unit.
Do:
Turn off the product before cleaning.
Touch screen surface may be cleaned using a soft clean cloth
moistened with mild window glass commercial cleaners or 50/50
mixture of water and isopropyl alcohol.
Use a soft cloth moistened with mild detergent to clean the display
housing.
Use only high quality and safety approved AC/DC adapter.
Disconnect the power plug from AC outlet if the product is not going
to be used for an extended period of time.
Don’t:
Do not touch the LCD Display screen surface with sharp or hard
objects.
Do not use abrasive cleaners, waxes or solvents for your cleaning.
Do not operate the product under the following conditions:
- Extremely hot, cold or humid environment.
- Areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic field.
- In direct sunlight.
4
1
Introduction
6
About PT1975R / PT1911MX / PT1975S /
PT1985P
The PT1975R / PT1911MX / PT1975S / PT1985P is a 19” flat panel
screen with an active matrix, thin-film transistor (TFT) liquid crystal
display (LCD).
Features include:
Direct Analog signal input
Direct Digital signal input
Active matrix TFT LCD technology
1280x1024 SXGA resolution
19” viewable display area
31.47 ~ 80 kHz horizontal scan
56 ~ 75 Hz high refresh rate
0.294mm x 0.294mm Pixel pitch
Auto adjustment function
Multilingual OSD user controls
VESA DPMS power saving
Kensington security slot
75 mm / 100 mm VESA mount
Removable base for flexible mounting solutions.
PT1975R – 5-wire resistive touch screen with dual RS-232 Serial/USB
controller
PT1911MX – Capacitive touch screen with dual RS-232 Serial/USB
controller
PT1975S – SAW touch screen with dual RS-232 Serial/USB controller
PT1985P – Projected capacitive touch screen with USB controller
Built-in speakers-1W X 2
5
7
Touch Screen for PT1975R
5-wire resistive touch screen for finger and stylus input
Surface: Anti-glare treatment
Interface: Dual RS-232 Serial/USB controller
Durability: 35 million touches at a single point
Hardness of surface: 3H Typical
Operating force: 40g~200g when using a silicon rubber tipped pen with a
1 mm diameter minimum and a hardness of 60 degree.
Transmittance: 82%±5%
Driver: Windows®7, VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded,
Linux, Apple®Mac OS
8
Touch Screen for PT1911MX
Capacitive touch screen for finger input
Surface: Anti-glare treatment
Interface: Dual RS-232 Serial/USB controller
Durability: 225 million touches at a single point
Hardness of surface: Mohs’ Hardness rating of 7
Transmittance: 85%±5%
Driver: Windows®7, VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded,
Linux, Apple®Mac OS
9
Touch Screen for PT1975S
Surface Acoustic Wave (SAW) touch screen for finger and stylus input
Surface: Anti-glare treatment
Interface: Dual RS-232 Serial/USB controller
Durability: 50 million touches at a single point
Hardness of surface: Mohs’ Hardness rating of 7
Operating force: Typically less than 85 g
Transmittance: 92%±5%
Driver: Windows®7, VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded,
Linux, Apple®Mac OS
6
10
Touch Screen for PT1985P
Project capacitive touch screen for finger input only
Surface: Glare treatment
Interface: USB controller
Transmittance: 90%±5%
Driver: Windows®7, VISTA 64/32 bits, XP, 2000, XP Embedded Express,
Linux, Apple®Mac OS
7
11
Package Overview
LCD Display Power Cord VGA Signal Cable
DVI Signal Cable Audio-in Cable RS-232 Cable
(PT1975R/PT1911MX/PT1975S only)
User’s Manual
USB Cable - Type A to B Touch Screen Driver
Installation CD-ROM
User’s Guide
Landing Strip DC Power Supply
(sold separately)
Cable Cover
Screw
8
2
Installation
12
Product Overview
Front View
PT1975R/PT1911MX/PT1975S PT1985P
PT1975R/PT1911MX/PT1975S Bottom View (Without Stand)
PT1985P Bottom View (Without Stand)
