EP4650/EP5550 RS232

User Manual

Contents of this publication may not be reproduced in any form without permission of Planar

Systems, Inc.

Trademark Credits

Windows™ is a trademark of Microsoft Corp.

All other names are trademarks or registered trademarks of their respective companies.

Disclaimer

The information contained in this document is subject to change without notice. Planar

Systems, Inc. makes no warranty of any kind with regard to this material. While every

precaution has been taken in the preparation of this manual, the Company shall not be liable

for errors or omissions contained herein or for incidental or consequential damages in

connection with the furnishing, performance, or use of this material.

Part Number: 020-1227-00A

EP4650 and EP5550 RS232 User Guide 1

RS232 Codes

RS232 control is not necessary for operation, but is a convenient way to control

displays from a computer at a distance. Most things you can do with the remote, you

can do with RS232 commands. Plus, you can send inquiries to the displays and find

out the current settings and values.

1RS232 Command Format

STX (1 byte) + IDT (1byte) + Type (1byte) + CMD (3bytes) + [Value/Reply (1byte)] +

ETX (1 byte)

STX: Start byte = 07

IDT: 00 (Hex Num) for broadcast mode (no announcing, only for video wall),

01~19 (Hex Num) for single control mode.

Type: Read or Write command, 01: read/action, 02: write; 00: return to host (from

monitor)

CMD: As shown in the table on the following pages

Value: Setting Value of Write Command

Reply: Return Value of monitor

ETX: End byte = 08

Transmit from PC (Host)

Read/Action command: 07 IDT 01 CMD 08 (7bytes)

Write/Setting command: 07 IDT 02 CMD VAL 08 (8 bytes)

Return from Monitor: Return CMD is the same with received CMD, the return

command will be sent after action. In broadcast mode, no return will be sent.

Return command: 07 IDT 00 CMD REP 08 (8 bytes)

2Serial Port Setting

Note: Baud rate can be set to 38400, 19200 or 9600 to match the monitor baud rate setting.

Baud Rate Data Bit Parity Bit Stop Bit

115200 8 None 1

RS232 Codes

2 EP4650 and EP5550 RS232 User Guide

Main Item Control

Item CMD Type Value

(DEC)

(DEC) Content CMD

(HEX) Notes

Power

Control and

Input Source

Power

Control

POW W/R

00 00 Off (soft power)

50 4F 57

See

Note 1

01 01 On (soft power) See

Note 1

Input

Source MIN W/R

00 00 VGA

4D 49 4E

01 01 Digital DVI

02 02 S-Video

03 03 Composite 1

04 04 Component 1

05 05 HDSDI 1

06 06 HDSDI 2

09 09 HDMI 1

10 10 HDMI 2

13 13 Displayport

Display

Adjustment

Display

Adjustment

BRI

W/R

0~100 Current value Back Light Brightness 42 52 49

BRL 0~100 Current value Digital Brightness Level 42 52 4C

BLC

00 00 Off (Back Light) 42 4C 43

01 01 On (Back Light)

CON

W/R

0~100 Current value Contrast 43 4F 4E

HUE 0~100 Current value Hue 48 55 45

SAT 0~100 Current value Saturation 53 41 54

COT W/R

00 00 User

43 4F 54

01 01 6500K

02 02 9300K

03 03 3200K

06 06 5000K

07 07 7500K

RS232 Codes

EP4650 and EP5550 RS232 User Guide 3

Main Item Control

Item CMD Type Value

(DEC)

(DEC) Content CMD

(HEX) Notes

Display

Adjustment

Display

Adjustment

GAC W/R

00 00 Off (Gamma)

7 41 43

01 01 2.2 (Gamma)

PHA

W/R

0~63

Current value

Phase 50 48 41

CLO 0~100 Clock 43 4C 4F

HOR

RCurrent value

Horizontal Position 48 4F 52

VER Vertical Position 56 45 52

ADJ W00 00 Auto Adjust 41 44 4A

Video

Mode

SHA W/R 0~24 Current value Sharpness 53 48 41

Other

Control

PIP Adjust PSC W/R

00 00 PIP OFF

50 53 43

01 01 PIP Small

02 02 PIP medium

03 03 PIP large

04 04 PIP side-by-side

PIP source

selection

PIN W/R

00 00 VGA

50 49 4E

01 01 Digital DVI

02 02 S-Video

03 03 Composite 1

04 04 Component 1

05 05 HDSDI 1

06 06 HDSDI 2

09 09 HDMI 1

10 10 HDMI 2

13 13 Displayport

PIP position PPO W/R

00 00 PIP Position Bottom-left

50 50 4F

01 01 PIP Position Bottom-

right

02 02 PIP Position Top-left

03 03 PIP Position Top-right

RS232 Codes

4 EP4650 and EP5550 RS232 User Guide

Main Item Control

Item CMD Type Value

(DEC)

(DEC) Content CMD

(HEX) Notes

Other

Control

PIP/Main

Swap

SWA W00 00 Swap main and PIP 53 57 41

Scaling ASP W/R

00 00 Native

41 53 50

01 01 Fill

02 02 PILLAR Box

03 03 Letter Box

ZOM W

00 00 Zoom in

5A 4F 4D

01 01 Zoom out

Baud Rate

Adjustment

BRA W/R

00 00 115200

42 52 41

01 01 38400

02 02 19200

03 03 9600

Other

Control

RCU W

00 00 MENU Key

52 43 55

01 01 INFO Key

02 02 UP Key

03 03 DOWN Key

04 04 LEFT Key

05 05 RIGHT Key

06 06 ENTER Key

07 07 EXIT Key

ALL W00 00 Reset all 41 4C 4C

KLC W/R

00 00 Un-lock keys 4B 4C 43

01 01 Lock keys

SER

13 bytes Read Serial Number 53 45 52

MNA 13 bytes Read Model Name 4D 4E 41

GVE 6 bytes Read Firmware Version 47 56 45

RTV Current value Read RS232 table

Version

52 54 56

RS232 Codes

EP4650 and EP5550 RS232 User Guide 5

Main Item Control

Item CMD Type Value

(DEC)

(DEC) Content CMD

(HEX) Notes

Other

Control

Wake Up

From Sleep

WFS W/R

0 0 Set VGA_ONLY

57 46 53

1 1 Set

VGA_DIGITAL_RS232

2 2 Set Never_Sleep

Audio

VOL

W/R

0~100 Current value volume 56 4F 4C

MUT

00 00 Mute Off 4D 55 54

01 01 Mute On

Scheme

Selection

SCM W/R

00 00 User

53 43 4D

01 01 Sport

02 02 Game

03 03 Cinema

04 04 Vivid

Multi-

Display

VWS

W/R

00 00 Video Wall Switch Off

56 57 53

01 01 Video Wall Switch On

VWF

00 00 Video Wall Frameless

Off 56 57 46

01 01 Video Wall Frameless

MAT X: 1-5

Y: 1-5

Current value

Matrix X, Y value

High quarter is X: 7-4

bit

Low quarter is Y: 3-0 bit

4D 41 54

DIV X: 1-5

Y: 1-5

Current value

Divisions X, Y value

High quarter is X: 7-4

bit

Low quarter is Y: 3-0 bit

44 49 56 Note 1

DID

00 00 DVI Indemnity Off

44 49 44

01 01 DVI Indemnity On

POD 0-30 Current value Integral part of Power

On Delay (0-30 sec.)

50 4F 44

RS232 Codes

6 EP4650 and EP5550 RS232 User Guide

Main Item Control

Item CMD Type Value

(DEC)

(DEC) Content CMD

(HEX) Notes

RTC

Current

Time

Adjustment

RTY

W/R

0~99 0~99 Year 52 54 59

RTM 0~12 0~12 Month 52 54 4D

RTD 1~31 1~31 Day 52 54 44

RTH 0~23 0~23 Hour 52 54 48

RTN 0~59 0~59 Minute 52 54 4E

Timer

Mode

TMS W/R

0 0 All

54 4D 53

1 1 Work Days

2 2 User

Alarm

Mode AEN W/R

1 1 Sunday

41 45 4E

2 2 Monday

4 4 Tuesday

8 8 Wednesday

16 16 Thursday

32 32 Friday

64 64 Saturday

Alarm

Disable

AEF W/R

1 1 Sunday

41 45 46

2 2 Monday

4 4 Tuesday

8 8 Wednesday

16 16 Thursday

32 32 Friday

1 1 Sunday

Sunday

SNH

W/R

0~23 0~23 Sunday On Hour 49 4E 48

SNM 0~59 0~59 Sunday On Minute 53 4E 4D

SFH 0~23 0~23 Sunday Off Hour 53 46 48

SFM 0~59 0~59 Sunday Off Minute 53 46 4D

Monday

NNH

W/R

0~23 0~23 Monday On Hour 4E 4E 48

NNM 0~59 0~59 Monday On Minute 4E 4E 4D

NFH 0~23 0~23 Monday Off Hour 4E 46 48

NFM 0~59 0~59 Monday Off Minute 4E 46 4D

RS232 Codes

EP4650 and EP5550 RS232 User Guide 7

※: The RS232 transition will be blocked for around six seconds after a power on/off

command has been performed.

Note 1: In broadcast setting mode, this command is used to auto arrange the Division X/Y.

(The Value Byte needs to be 0x11.)

Main Item Control

Item CMD Type Value

(DEC)

(DEC) Content CMD

(HEX) Notes

RTC

Tuesday

ENH

W/R

0~23 0~23 Tuesday On Hour 45 4E 48

ENM 0~59 0~59 Tuesday On Minute 45 4E 4D

EFH 0~23 0~23 Tuesday Off Hour 45 46 48

EFM 0~59 0~59 Tuesday Off Minute 45 46 4D

Wednesday

DNH

W/R

0~23 0~23 Wednesday On Hour 44 4E 48

DNM 0~59 0~59 Wednesday On Minute 44 4E 4D

DFH 0~23 0~23 Wednesday Off Hour 44 46 48

DFM 0~59 0~59 Wednesday Off Minute 44 46 4D

Thursday

UNH

W/R

0~23 0~23 Thursday On Hour 55 4E 48

UNM 0~59 0~59 Thursday On Minute 55 4E 4D

UFH 0~23 0~23 Thursday Off Hour 55 46 48

UFM 0~59 0~59 Thursday Off Minute 55 46 4D

Friday

INH

W/R

0~23 0~23 Friday On Hour 49 4E 48

INM 0~59 0~59 Friday On Minute 49 4E 4D

IFH 0~23 0~23 Friday Off Hour 49 46 48

IFM 0~59 0~59 Friday Off Minute 49 46 4D

Saturday

TNH

W/R

0~23 0~23 Saturday On Hour 54 4E 48

TNM 0~59 0~59 Saturday On Minute 54 4E 4D

TFH 0~23 0~23 Saturday Off Hour 54 46 48

TFM 0~59 0~59 Saturday Off Minute 54 46 4D

Accessing Planar’s Technical Support Website

8 EP4650 and EP5550 RS232 User Guide

Accessing Planar’s

Technical Support

Website

1Go to www.planarpartners.com

2Once you enter your login and password, you can access downloadable utility

software, new firmware and user manuals.

Downloading Utility Software

1Go to www.planarpartners.com.

2Enter your login and password information.

3Navigate to the section that contains software updates and then look for

EP4560/EP5550.

4From the list of available software, click on the tool you need.
