Page 5
Pre-Installation Check
Assuming that before your purchase of RangeMinder™you visited our
Compatibility Data Base at preventcookingfires.com or performed the
Quick Compatibility Check referenced above, you are now ready to
proceed with the pre-installation check. With one of the magnetized rings
and the sheet of adaptors from your RangeMinder™box, please follow
these two quick steps.
Note: We encourage you to review the Installation Reference Video for
RangeMinder™, which is also available at: preventcookingfires.com
Step 1 – Magnetized Sensor Ring Check
Pull a knob off your existing stove and without removing the paper
backing on the magnetized sensor ring slide it over the exposed shaft
ensuring that the arrow is pointing up. Check that the magnetized ring is
centered on the shaft and that it sits flat against the stove face. The
centre of each magnetized sensor ring has been designed with “cut-outs”
to fit around most screws or washers that may be around the shaft
opening (hole).
Important: Proceed to Step 2 before installing any of the magnetized
sensor rings.
Step 2 – Shaft Adaptor Check
Ten (10) sets of four (4) dial shaft adaptors have been included with your
RangeMinder™. Ensure that one (1) of the sets fits the shaft on your stove
properly. Select the shaft adaptor that fits snugly on the shaft and has the
square flange sitting approximately 3 mm or 1/8” from the stove face.
