Pioneer PRO-710HD Manual de usuario

ORDER NO.

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.

PIONEER EUROPE N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936

PIONEER CORPORATION 2000

Model No. Order No. Remarks

PRO-610HD ARP3047 and ARP3051

PROJECTION MONITOR RECEIVER

ARP3065

T–ZZA FEB. 2000 Printed in Japan

PRO-710HD

Parts of the exploded views are all mentioned in this manual.

For other items, refer to the service manual of PRO-610HD (ORDER NO. ARP3047 and

ARP3051) .

KUXC/CA AC120V

THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).

RemarksPower RequirementType Model

PRO-710HD

¶This service manual should be used together with the following manual(s).

PRO-710HD

EXPLODED VIEWS AND PARTS LIST

NOTES : Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List.

The mark found on some component parts indicates the importance of the safety factor of the part.

Therefore, when replacing, be sure to use parts of identical designation.

÷Parts marked by are important parts which relate in X-rays radiation.

If any of these parts need to be replaced, always replace with specified parts.

Screws adjacent to mark on the product are used for disassembly.

PACKING

Remove

Attach

Side View

Screen Frame

22 (×12)

25 to 28, 32

29 to 31

33 34

Accessory

PRO-710HD

NSP 1 Upper Carton AHD3065

2 Under Carton AHD2995

3 Upper Pad L AHA2222

4 Upper Pad R AHA2223

5 Under Pad L AHA2224

6 Under Pad R AHA2225

NSP 7 Vinyl Sheet Upper AHG1288

NSP 8 Packing Sheet AHG1230

NSP 9 Packing Sheet Under AHG1290

10 Vinyl Sheet Under AHG1289

11 Remote Control Unit AXD1448

(CU–SD110)

12 Battery Cover AZN2401

NSP 13 Alkarine Dry Cell Battery AEX1018

(LR6,AA)

14 CU Packing Case AHC1032

15 Special Screw ABA1239

16 CONV. Attention Card ARM1173

17 Operating Instructions (English) ARB1527

NSP 18 Caution Card ARM1057

NSP 19 Warranty Card ARY1026

NSP 20 Poly Bag AHG1285

21 .................................

22 Special Screw ABA1226

(Panel Frame Attaching Screw)

NSP 23 Wrapper Bag AHG1076

NSP 24 Literature Bag AHG1222

25 Panel Case AHB1202

26 .................................

27 Contrast Screen AAK2763

28 Acrylic Caution Card ARH1167

29 Frame Cover H AAP1593

30 Frame Cover V Assy AAP1594

31 Panel Frame H AND1163

32 Panel Frame V AND1164

NSP 33 Under Cushion A AHA2228

NSP 34 Under Cushion B AHA2229

PACKING PARTS LIST

Mark No. Description Part No.

PRO-710HD

17 16

16 19

24 18

21 24

19 24

FRONT VIEW (1/2)

PRO-710HD

1 Grille AMM2939

2 Badge AAM1081

NSP 3 Catcher A ANZ–241

4 Magic Tape AEC1394

5 Screw ABA1271

6 Side Cover AMR3107

7 Special Screw ABA1240

8 Side Panel Assy L AMB2627

9 Side Panel Assy R AMB2676

10 Door Assy AAN1461

11 Blind Plate AMM2933

12 Catcher F2M AEC1609

13 Front Panel Assy AMB2666

14 Catch B AEC1507

15 Power Knob AAD4105

16 Screw ABZ40P080FZK

17 FRONT INPUT Assy AWZ6466

18 POWER SW Assy AWZ6467

19 FRONT CONTROL Assy AWZ6462

20 Screw ABA1239

NSP 21 Switch Holder ANG2313

22 .................................

23 Screw AMZ30P060FZK

24 Screw APZ30P080FZK

25 LED DPO Assy AWZ6463

26 .................................

27 .................................

28 .................................

29 .................................

NSP 30 Front Shield ANK1502

FRONT VIEW (1/2) PARTS LIST

Mark No. Description Part No.

PRO-710HD

FRONT VIEW (2/2)

10 9

928

22 22

PRO-710HD

1 Lenticular Sheet AMR3115

2 Screen Holder Top ANG2312

3 Fresnel AMR3116

NSP 4 Upper Cabinet Metal ANG2000

NSP 5 Mirror Upper Stay L ANG2004

NSP 6 Mirror Upper Stay C ANG2006

NSP 7 Mirror Upper Stay R ANG2005

8 Screw BYC40P160FMC

NSP 9 Screen Side Fitting ANG1993

10 Special Screw ABA1240

11 Screw ACZ40P080FMC

12 .................................

13 Cone Speaker APV1021

14 Caster AMR2547

NSP 15 VR Holder ANG1956

FRONT VIEW (2/2) PARTS LIST

Mark No. Description Part No.

16 Special Screw ABA1273

NSP 17 CRT Front Holder ANG2118

18 Screw M5 ABA1189

NSP 19 Under Screen Metal B ANG2009

20 Mirror Frame V ANG2392

21 Mirror AMR3113

NSP 22 Upper Screen Metal B ANG2002

NSP 23 Under Screen Metal A ANG2003

24 Mirror Frame H ANG2391

NSP 25 Upper Screen Metal A ANG2001

26 Screen Frame Assy AAP1592

27 Screen Holder Low AAP1601

28 Screw BYC35P160FZK

29 Focus VR (VR1) ACX1096

30 Screw BBZ30P080FZK

Mark No. Description Part No.

229

1 Mirror Case 51 AME2296

2 Screw ABA1240

3 Screw PYC40T140FZB

4 Rear Cover AMM2929

5 Blind Sheet AEC1622

6 .................................

REAR VIEW (1/2) PARTS LIST

Mark No. Description Part No.

REAR VIEW (1/2)

7 Screw ABZ30P100FZK

8 Screw ABA1269

NSP 9 Cabinet Wire Holder AEC1263

10 Screen Cushion AEC1778

11 Rear Cover (DTV) AMM3000

12 Rear Cover Sheet AMR3190

13 Screw PMB40P250FZB

Mark No. Description Part No.

PRO-710HD

REAR VIEW (2/2)

313

26 27

25 38

38 34 31

Refer to " DEFLECTION

BLOCK".

Refer to " POWER

SUPPLY BLOCK".

Refer to " CONV.

AMP BLOCK".

Refer to "VIDEO

BLOCK".

13 Back Cover Panel

PRO-710HD

1 CRT Service Assy B AWY1415

2 CRT Service Assy G AWY1413

3 CRT Service Assy R AWY1414

4 Lens Assy AMR3121

5 Screw FBT40P120FZK

6 Screw ABA1168

7 Screw AMZ40P080FZK

NSP 8 CRT Front Frame ANA1541

NSP 9 CRT Rear Frame ANA1542

10 Screw ACZ40P080FMC

NSP 11 CRT Front Holder ANG2118

NSP 12 CRT Rear Holder ANG2119

13 Screw ABA1240

14 Cord Holder AEC1257

NSP 15 Tube Label AAX2497

16 Rivet AEC–441

NSP 17 CRT Stand Holder R ANA1497

NSP 18 CRT Stand Holder L ANA1496

19 Screw PMB50P250FZB

20 Special Screw ABA1121

NSP 21 Back Cover Panel AMM3079

22 .................................

23 Screw ABA1241

NSP 24 Cabinet Wire Holder AEC1856

25 Screw ABA1279

NSP 26 Fixing Metal ANG1958

27 SR Assy AWZ6465

NSP 28 Tray AMR2563

NSP 29 Solder Warning Label AAX2672

NSP 30 Warning Label (KC) AAX1797

NSP 31 AC Cord Holder A ANG2307

NSP 32 Bind Holder AEC1785

33 Ferrite Core ATX1033

34 AC Power Cord ADG1180

NSP 35 AC Cord Holder B ANG2311

36 Wire Harness C (J14) ADX2491

37 AC Power Cord ADG1185

38 Screw BBZ30P080FZK

39 Screw ABA1271

40 Ferrite Core ATX1031

REAR VIEW (2/2) PARTS LIST

Mark No. Description Part No. Mark No. Description Part No.

NSP 41 Nylon Clamp 18N AEC1789

42 Nylon Binder AEC–093

43 1P Lead Wire (J1) ADX2505

44 Screw PMB40P250FZB

PRO-710HD

CRT BLOCK

Anode Cable
